Chapter 1 - About this guide

Version EN-062018-1.01 5

1About this guide

The information contained in this document is subject to change without notice. If you find

any problems understanding the information and instructions in the documentation, please

report them to us in writing.

1.1 Read me first

Please read this guide carefully before using the device to ensure safe and proper use.

Softing does not assume any liability for damages due to improper installation or operation

of this product.

This document is not warranted to be error-free. The information contained in this

document is subject to change without prior notice. To obtain the most current version of

the hardware guide, visit the download center on our website at: http://

industrial.softing.com/en/downloads

1.2 Objective

This document explains how to connect and start mobiLink to configure and maintain field

devices via USB or Bluetooth communication using the application software comConf and

mobiLink DTM with FDT frame applications on PCs, tablets or smartphones.

1.3 Target audience

This hardware guide has been written for experienced operation personnel and network

specialists responsible for configuring and maintaining field devices in process automation

networks. Any person using a mobiLink must have read and fully understood the safety

requirements and working instructions in this guide.

1.4 Typographic conventions

The following conventions are used throughout our product documentation:

Keys, buttons, menu items, commands and

other elements involving user interaction

are set in bold font and menu sequences

are separated by an arrow

Open Start Control Panel Programs

Buttons from the user interface are

enclosed in brackets and set to bold

typeface

Press [Start] to start the application

Coding samples, file extracts and screen

output is set in Courier font type

MaxDlsapAddressSupported=23

Filenames and directories are written in

italic

Device description files are located in C:

\<Application name>\delivery\software

\Device Description files

mobiLink - Hardware Guide

6Version EN-062018-1.01

CAUTION

This symbol is used to indicate a potentially hazardous situation which, if not

avoided, may result in minor or moderate injury.

Note

This symbol is used to call attention to notable information that should be

followed during installation, use, or servicing of this device.

Hint

This symbol is used when providing you with helpful user hints.

1.5 Document feedback

We would like to encourage you to provide feedback to help us improve the documentation.

You can write your comments and suggestions to the PDF file using the editing tool in Adobe

Reader and email your feedback to support.automation@softing.com.

If you prefer to write your feedback directly as an email, please include the following

information with your comments:

document name

document version (as shown on cover page)

page number

1.6 Related documentation

The following documentation of the specific application software is part of the product:

Communication Configuration Tool - User Guide V2.23

MOBILINK dtm - User Guide V1.10

Chapter 2 - About mobiLink

Version EN-062018-1.01 7

2About mobiLink

mobiLink is a mobile communication device designed to configure and manage field devices

(HART, FOUNDATION fieldbus or PROFIBUS PA) in hazardous and non-hazardous areas from

PCs, tablet computers or smartphones by wired or wireless communication. Operation of

this communication device requires the use of suitable management tools like FDT frame

applications or configuration tools on Windows PCs or tablets or smartphones.

2.1 Intended use

mobiLink is used to interface with network segments to configure, commission and maintain

connected field devices (HART, FOUNDATION Fieldbus or PROFIBUS PA fieldbus). mobiLink may

be used both in field installations and in bench applications. As mobiLink does not supply

power to the connected devices, a powered HART loop or powered fieldbus segment is

required when using mobiLink in bench applications.

mobiLink is certified for hazardous areas and can be connected to intrinsically safe field

devices. See the section Functional Description for details.

Note

Avoid interference with the operation system. Exercise utmost care when using

mobiLink in operational plants.

2.2 Scope of delivery

Make sure that the following parts are included in the product package:

mobiLink unit

USB cable (2m)

set of testing cables red/black with clamp (1m)

3 AA batteries

USB memory stick with mobiLinkDTM, application programs and documentation

printed Getting Started Guide

mobiLink - Hardware Guide

8Version EN-062018-1.01

3Product overview

mobiLink combines a HART modem and a Manchester encoded bus-powered (MBP) fieldbus

interface in a single portable device. It features a full-blown HART master, a FOUNDATION

Fieldbus host and a PROFIBUS PA master and therefore supports all three major

communication protocols used with process field devices.

Host devices, tools and applications

mobiLink provides access to field devices from FDT frame applications and configuration

tools running on host devices (PCs, tablets or smartphones) connected via USB or Bluetooth.

If you connect mobiLink to a host device on the USB port, the mobiLink automatically starts

USB communication. Conversely, if you switch on mobiLink without a wired USB connection,

the device automatically activates wireless Bluetooth communication. It is not possible to

use Bluetooth while the USB cable is connected. If the USB cable is disconnected during

operation, mobiLink is powered off. Connecting the USB cable during Bluetooth operation

will cause mobiLink to reboot.

Power supply and consumption

mobiLink uses three AA batteries. The battery lifetime depends on the mode of operation.

Using Bluetooth communication, one set of batteries can last several working days. USB

mode increases battery life time, but cannot be used in hazardous areas. mobiLink does not

supply power to connected field devices. A powered HART loop or powered fieldbus

segment is required. When connected to a fieldbus segment, the mobiLink fieldbus interface

draws 10 mA from the fieldbus as required by the specification. To improve the battery

lifetime of mobiLink in bench host applications, the host application may set the power

drawn from the fieldbus to 18 mA in USB mode.

Chapter 3 - Product overview

Version EN-062018-1.01 9

HART or fieldbus communication

mobiLink can operate as HART modem, FOUNDATION Fieldbus or PROFIBUS PA fieldbus

interface. The two different electrical interfaces for HART and fieldbus operation share a

common socket. The mode of operation is selected by the host application. mobiLink checks

whether the electrical conditions on the interface match the selected mode. mobiLink must

therefore be connected to a HART device or fieldbus segment before the host application is

started. An LED marking the HART or Fieldbus socket indicates in which communication

mode mobiLink is running.

mobiLink - Hardware Guide

10 Version EN-062018-1.01

3.1 Functional description

Connector

Foundation Fieldbus

PROFIBUS PA

HART

(1) FIELDBUS red

DATA +

PA +

(2) Common black

DATA -

PA -

HART N

(3) HART red

HART P

Connector / Button

Function

(4) USB

USB-C Type connector

(5) Bluetooth Button

Activate Visibility for Pairing

(6) Power On/Off Button

On/Off

LED

Function

(7) FIELDBUS

Fieldbus selected

(8) HART

HART selected

(9) Bluetooth

Bluetooth active. Flashing during Bluetooth

communication, steady light when in pairing mode

(10) Low battery

Low Battery

(11) Power

Power State

Autres manuels pour mobiLink

Table des matières

Autres manuels Softing Équipement d'enregistrement

Softing

Softing pnGate PA Manuel utilisateur

Softing

Softing mobiLink Manuel utilisateur

Softing

Softing dataFLOW mobiLink Manuel utilisateur

Softing

Softing PBpro ETH Manuel utilisateur

Softing

Softing pnGate PA Manuel utilisateur

Manuels Équipement d'enregistrement populaires d'autres marques

KV2 Audio

KV2 Audio 500 Series Manuel utilisateur

Robotics Technologies

Robotics Technologies microBus-Cam II Manuel utilisateur

Seca

Seca 460 Manuel utilisateur

Cognex

Cognex MVS-8000 Series Manuel utilisateur

Mect

Mect MPNC006 Series Manuel utilisateur

Bad Caf

Bad Caf THE LEASH Manuel utilisateur

Strymon

Strymon NIGHTSKY Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric 16CH DIGITAL RECORDER DX-TL5000U Manuel utilisateur

Tews Technologies

Tews Technologies TPMC465 Manuel utilisateur

Honeywell

Honeywell Excel 50 Manuel utilisateur

SeaLevel

SeaLevel COMM+8.LPCI Manuel utilisateur

Arturia

Arturia AUDIOFUSE STUDIO Manuel utilisateur

Rukra

Rukra RK-1240 Manuel utilisateur

Samson

Samson SCOM Manuel utilisateur

Dynacord

Dynacord DPS260 Manuel utilisateur

Nice

Nice Core Manuel utilisateur

Pyle Pro

Pyle Pro PSS8 Manuel utilisateur

RF-System

RF-System TinyGate Manuel d'utilisation et d'entretien

Softing mobiLink Instructions d'installation

Manuels Équipement d'enregistrement populaires d'autres marques
