Socomec NETYS RT Manuel utilisateur

7000 - 11000 VA

Hot swap RT version

NETYS RT

INSTALLATION AND OPERATING MANUAL EN

www.socomec.com/netys-manuals

NETYS RT Hot Swap 7 - 11 kVA - 551574B - SOCOMEC 3

https://www.socomec.com/netys-manuals

AR NL

CS PL

DE PT

ES RU

FI SL

FR TR

EN RO

Download last release of installation and operating manual from:

This Safety Information is to be retained for future reference.

Reference security information is in English.

For other languages please contact Socomec or local distributor.

The manufacturer will not be held liable for failure to follow the instructions in

this manual which is also available at www.socomec.com

NETYS RT Hot Swap 7 - 11 kVA - 551574B - SOCOMEC

4EN

WARRANTY CERTIFICATE AND CONDITIONS

This Socomec appliance is guaranteed against manufacturing and material defects

for a period of 12 months from the date of purchase (local warranty conditions are

applicable in addition to the general conditions). This warranty certicate should

NOT be e-mailed, but kept by the customer along with proof of purchase, for use

in the event of a claim being made for repairs or replacement under warranty.

The warranty period commences on the date the new product was purchased

by the end user at an authorised showroom (reference details are shown on the

receipt).

Return-to-base warranty is provided: components and labour for repairs supplied

free of charge, any products to be replaced must be returned to Socomec or

authorised service centres, at the customer’s own risk and expense.

The warranty is recognized within national territory. If the UPS is exported out of

national territory, the warranty shall be limited to the cover of the parts used to

repair the defect.

To claim service under the warranty please observe the following:

• The product must be returned in the original packing. Any damage caused during

shipping in packaging other than the original will not be covered by the warranty;

• The product must be accompanied by proof of purchase such as an invoice or

receipt indicating the date of purchase and product ID information (model, serial

numer). The sender must also attach the reference number issued to authorize

the return of the product, together with a detailed description of the defect. If

any of this information is missing the warranty will be invalid. The authorisation

number is issued by service centres over the telephone on receiving information

on the defect in question;

• If it is not possible to provide proof of purchase the serial number and date of

manufacture will be used to calculate the probable expiry date of the warranty;

this could result in a reduction of the original warranty period.

The warranty on the product does not cover damage caused by carelessness

(improper use: wrong input power, explosions, excessive humidity, temperature,

poor ventilation, etc.), tampering or any unauthorised repair work.

During the warranty period, Socomec reserves the right to decide whether the

product should be repaired, or whether to replace defective parts with new

parts, or used parts that are equivalent to new parts in terms of functionality and

performance.

In the case of batteries, the warranty is valid only if the battery has been recharged

regularly in accordance with the manufacturer’s instructions. On purchasing the

product it is advisable to check that the next recharge date indicated on the

packaging has not expired.

NETYS RT Hot Swap 7 - 11 kVA - 551574B - SOCOMEC 5

VRLA Battery

• Batteries are treated as consumable parts and the warranty only covers

manufacturing defects.

• Batteries must be stored in compliance with the supplier’s recommendations.

• The warranty is valid only if the battery has been recharged regularly in

accordance with the manufacturer’s instructions. On purchasing the product it is

advisable to check that the next recharge date indicated on the packaging has

not expired.

Options

A 12-month return-to-base warranty is provided on options.

Software products

Software products are guaranteed for 90 days. The software is guaranteed to

work as indicated in the manual accompanying the product. Hardware media or

accessories (e.g. diskettes, cables, etc.) used with appliances are guaranteed free

of material or manufacturing defects under normal conditions of use for a period of

12 months from the date of purchase.

Socomec will not be responsible for damages (including loss of income,

interruption of business activity, loss of information or other nancial losses, of any

nature) arising from the use of the product.

These conditions are subject to Italian law. Disputes shall come under the

jurisdiction of Court of Vicenza.

Socomec retains the full and exclusive ownership rights over this document. Only

a personal right to use the document for the application indicated by Socomec

is granted to the recipient of such document. All reproduction, modication or

dissemination of this document whether in part or whole and by any manner are

expressly prohibited except upon Socomec’s express prior written consent.

This document is not a specication. Socomec reserves the right to make any

changes to data without prior notice.

NETYS RT Hot Swap 7 - 11 kVA - 551574B - SOCOMEC

6EN

1. SAFETY STANDARDS ...............................................8

1.1. Important ......................................................8

1.2. Description of the symbols used on the labels applied to the unit ..........11

1.3. Storage and installation ..........................................12

1.4. Installation ....................................................12

1.5. Electrical requirements ...........................................13

2. INTRODUCTION...................................................14

2.1. General Overview...............................................14

2.2. Exterior & Dimensions ...........................................14

2.3. Package list ...................................................15

3. OPERATION PANEL ................................................17

3.1. LED Indicators .................................................17

3.2. Multi-function Buttons ...........................................18

3.3. LCD Display...................................................21

4. REAR PANEL ....................................................23

5. COMMUNICATION INTERFACES ......................................26

5.1. Communication solutions.........................................26

5.2. Smart Slot ....................................................26

5.3. Dry Contacts ..................................................26

5.4. REPO Port ....................................................27

5.5. RS-232 Port and USB ...........................................27

5.6. WEB/SNMP Card (option) ........................................28

5.7. RS-485 Port ..................................................28

5.8. External Battery Connector .......................................29

5.9. Use of Warning Relay Interface (option) ..............................32

EN CONTENTS

NETYS RT Hot Swap 7 - 11 kVA - 551574B - SOCOMEC 7

6. INSTALLATION ....................................................35

6.1. Rack Mounting ................................................35

6.2. Tower Mounting ................................................37

6.3. Plug-in manual bypass Disassembly & Installation ......................39

6.4. Battery/ Battery Pack Replacement .................................42

7. CONNECTION AND WIRING .........................................44

7.1. UPS Connection Warnings........................................44

7.2. Input/ Output Connection ........................................45

7.3. External Battery Pack Connection ..................................48

8. OPERATION......................................................49

8.1. Start-up ......................................................49

8.2. Turn-off ......................................................51

8.3. Operating Mode ...............................................52

9. LCD DISPLAY & SETTINGS ..........................................53

9.1. Main Menu....................................................53

10. OPTIONAL ACCESSORIES .........................................66

10.1. Optional External Battery Pack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

11. TROUBLESHOOTING .............................................71

12. MAINTENANCE ..................................................75

12.1. UPS ........................................................75

12.2. Batteries ....................................................75

12.3. Fans........................................................75

13. TECHNICAL SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

14. APPENDIX: TOXIC AND HAZARDOUS SUBSTANCES AND ELEMENTS .......78

NETYS RT Hot Swap 7 - 11 kVA - 551574B - SOCOMEC

8EN

1. SAFETY STANDARDS

1.1. Important

This manual should be kept in a safe place near the UPS, so it can be consulted by

the operator at any time for information that may be needed regarding correct use

of the unit. Read the manual carefully before connecting the unit to the a.c. mains

supply and the downstream appliances. Before the UPS is put into commission the

user should be completely familiar with its operation, the position of all the controls

and the technical and functional characteristics of the unit, so as to ensure there

will be no risk to people or the appliance itself.

This is a product for commercial and industrial applications in an industrial

environment – installation restrictions or additional measures may be

needed to prevent electro-magnetic interferences.

• The product you have chosen is designed for commercial and industrial use only.

In order to be used for particular “critical applications” such as life support systems,

medical applications, commercial transportation, nuclear facilities or any other

application or systems where product failure is likely to cause substantial damage or

harm to persons or property, the products might require compliance with statutory

regulations and standards, specic local by-laws and be adapted accordingly.

For such uses we would advise you to contact Socomec beforehand to conrm

the ability of these products to meet the requested level of safety, performance,

reliability and compliance with applicable laws, regulations and specications.

• Use the UPS in accordance with the technical specications indicated in this manual.

• The electrical installation must be entrusted EXCLUSIVELY to a skilled engineer,

following exactly the instructions provided.

• The UPS houses a source of electrical energy, namely its batteries. The output of

the UPS may be under power even when the appliance is not connected to the

a.c. mains supply.

Installation Warnings

• Before installation and usage, please read this User Manual thoroughly. This helps

you to use the product correctly and safely.

• Install the UPS in a well-ventilated area, away from excess moisture, heat, dust,

ammable gas or explosives.

• To avoid re accidents and electric shock, please install the UPS in a temperature

and humidity-controlled indoor area free of conductive contaminants. For the

temperature and humidity specications, please refer to Appendix 1: Technical

Specications.

• Leave adequate space (at least 50cm) around all sides of the UPS for proper ventilation.

NETYS RT Hot Swap 7 - 11 kVA - 551574B - SOCOMEC 9

Connection Warnings

• Before being started up, the unit must be equipotentially bonded, in accordance

with current safety regulations. The earth wire of the UPS must then be

connected to an efcient earth system.

• If the earth connection is not made, the appliances connected to the UPS will not

be equipotentially bonded. In this situation, the manufacturer declines all liability for

any damage or accidents that could derive from failure to observe the requirements.

• The UPS must be well grounded due to a possible risk of current leakage current

greater than 3.5mA

• The installation of upstream and downstream protective devices is highly

recommended when the UPS is connected to the mains and the loads.

• The protective devices connected to the UPS must be installed near the UPS and

must be easily accessible for operation.

• If you need to move the UPS or perform re-wiring, please turn off the AC input

power and ensure that the UPS has been safely shutdown. Otherwise, the output

end might still be energized and cause electric shock.

• Avoid connecting the output neutral to earth. The UPS does not alter the function

of the mains neutral in any way; if the neutral needs to be modifed downstream of

the UPS, an isolation transformer must be used.

• In the event that the equipment has no automatic backfeed protection contactor

device, make certain that:

- the user/installer attaches warning labels to all mains isolating switches located

remotely from the area where the UPS is sited, in order to inform service

personnel that the circuit is connected to a UPS.

- an external isolating device is installed, as indicated in gure 7.1.

Usage Warnings

• This is a class-A product. In a domestic environment, this product may cause

radio interference, in which case, the user is required to take adequate measures.

• The UPS can be used to power computers and associated peripheral devices,

such as monitors, modems, cartridge tape drives, external hard drives, etc.

• It is strictly forbidden to connect the UPS with:

- Any regenerative loads.

- Any asymmetrical loads.

• To ensure reliable operation of the UPS and to protect the UPS from overheating,

the slits and openings in the UPS must not be blocked or covered.

• Before usage, you must allow the UPS to adjust to room temperature for at least

one hour to avoid moisture condensing inside the UPS.

• Do not pour and splash any liquid on the UPS. Do not insert any object into the slits

and openings of the UPS. Do not put beverage containers on or around the UPS.

NETYS RT Hot Swap 7 - 11 kVA - 551574B - SOCOMEC

10 EN

• When an emergency occurs, (1) press and hold the ON/ OFF button ( ) for

3 seconds, (2) release it after you hear one beep, (3) use the Scrolling Up or

Down button ( / ) to select 'Yes', and (4) press the Enter button ( ) to

conrm your selection to turn off the UPS. After that, cut off the input power to

completely shut down the UPS.

• Do not use any cleaning liquid or cleaning spray to clean the UPS. Before cleaning,

please make sure that the UPS has been completely shut down, that the input

power to the UPS has been cut off, and the batteries have been disconnected.

• All maintenance services must be performed by qualied service personnel

or by authorised service engineers. The UPS generates high internal voltages

that could be hazardous for a maintenance operative not in possession of the

appropriate skills and training for this type of work.

• Forbid opening or removing the cover of the UPS yourself to avoid high voltage

electric shock.

• You must contact qualied service personnel if either of the following events occurs:

- Liquid is poured or splashed on the UPS.

- The UPS does not run normally after having carefully followed the instructions

given in this User Manual.

Battery Warnings

• Keep the batteries away from heat sources. Do not open or damage the batteries.

• Do not dispose of batteries in a re. The batteries may explode.

• The released electrolyte is harmful to the skin and eyes and may be toxic.

• A battery can present a risk of electric shock and high short-circuit current.

• Servicing of batteries and battery packs must be performed or supervised by qualied

service personnel who are familiar with batteries, battery packs and the required

precautions. Keep unauthorized personnel away from batteries and battery packs.

• The risk of electric shock and short-circuit current is possible when the batteries

are connected to the UPS. Before maintenance, disconnect all batteries to cut off

the battery power.

• For battery replacement, only use the same number and type of batteries.

• There is a danger of explosion if the batteries are replaced with others of the

wrong type.

• Replaced batteries must be disposed of at authorised waste disposal centres.

• Never force, break or attempt to open the batteries. These batteries are sealed,

maintenance-free components containing substances that are harmful to health

and a source of environmental pollution. If liquid can be seen leaking from the

battery, or a white powdery residue is noticeable, do not switch the UPS on.

• Observe the following before replacing the batteries:

- Remove watches, rings, or other metal objects.

- Use tools with insulated handles.

- Wear rubber gloves and boots.

- Do not lay tools or metal parts on the top of batteries.

Autres manuels pour NETYS RT

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels socomec UPS

socomec

socomec MASTERYS BC+ 10 kVA Manuel utilisateur

socomec

socomec NETYS RT Manuel utilisateur

socomec

socomec NETYS RT Manuel utilisateur

socomec

socomec NETYS RT Series Manuel utilisateur

socomec

socomec PDU 16 Manuel utilisateur

socomec

socomec Masterys BC+ Series Manuel utilisateur

socomec

socomec ITYS Manuel utilisateur

socomec

socomec Green Power 2.0 10 Manuel utilisateur

socomec

socomec MASTERYS BC 60 kVA Manuel utilisateur

socomec

socomec NETYS PR 1000 Rack 1U Manuel utilisateur

socomec

socomec MODULYS Green Power Manuel utilisateur

socomec

socomec MODULYS GP 25 kVA Manuel utilisateur

socomec

socomec Modulys GP 2.0 Series Manuel utilisateur

socomec

socomec NETYS PL Manuel utilisateur

socomec

socomec Masterys Green Power 10 Manuel utilisateur

socomec

socomec Green Power 2.0 Manuel utilisateur

socomec

socomec NETYS PE Manuel utilisateur

socomec

socomec MASTERYS EM Manuel utilisateur

socomec

socomec Masterys BC Manuel utilisateur

socomec

socomec NeTYS PE 1000 VA Manuel utilisateur

socomec

socomec ITYS PRO 10 Manuel utilisateur

socomec

socomec NETYS RT 5000 Manuel utilisateur

socomec

socomec Green Power 2.0 60 Manuel utilisateur

socomec

socomec Green Power 2.0 Manuel utilisateur

Manuels UPS populaires d'autres marques

Pylontech

Pylontech Victron & Pylontech US5000 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuel utilisateur

Mecer

Mecer ME-1000-WTU Manuel utilisateur

Mustek

Mustek PowerMust 530(B) Plus Manuel d'installation et d'exploitation

Emerson

Emerson Liebert NXL series Manuel utilisateur

MAKELSAN

MAKELSAN BOXER SERIES Manuel utilisateur

Block

Block PC-0524-400-0 Manuel utilisateur

CyberPower

CyberPower CP585LCD Manuel utilisateur

Eaton

Eaton 3S Instructions de montage

CyberPower

CyberPower Office Tower Series UPS 1000 Manuel utilisateur

CyberPower

CyberPower BM100 Manuel utilisateur

Best Power

Best Power 610 Manuel utilisateur

Best Power

Best Power Unity/I UT3K Manuel utilisateur

Mustek

Mustek PowerMust 400 Offline Manuel utilisateur

Xantrex

Xantrex Trace 512 UR-UPS Manuel utilisateur

Forza

Forza SL-1501UL Manuel utilisateur

LEGRAND

LEGRAND keor 310081 Manuel utilisateur

ABB

ABB Conceptpower DPA 500 Manuel utilisateur
