QUICK START GUIDE
SoMo 655
Handheld Computer
This document pertains to the following family of SoMo 655 models:
• SoMo 655 Standard
• SoMo 655Rx (Anmicrobial)
• SoMo 655DXS (Security: No wireless radio or microphone)
• SoMo 655 Handheld Computer
• Stylus
• Lithium-ion Baery
• USB Sync Cable
• USB Power Cable*
• AC Adapter*
• Cercate of Authencity
NOTE: The oponal Sync-Charge Cradle (SKU# HC1700-
1394) or Four Bay Charging Cradles (SKU# HC1702-1396,
SKU# HC1703-1397) can be purchased separately.
PACKAGE CONTENTS
© 2012 Socket Mobile, Inc. All rights reserved. Socket, the Socket logo, SoMo, and
Business Mobility Now! are registered trademarks or trademarks of Socket Mobile, Inc.
The Bluetooth word mark and logo are registered trademarks of the Bluetooth SIG, Inc.
USA, and any use by Socket Mobile, Inc. is under license. All other trademarks and trade
names contained herein may be those of their respecve owners.
Thank you for choosing SocketMobile!
Let’s get started!
*Conguraon dependent
Front
PRODUCT INFORMATION
3
Back
PRODUCT INFORMATION
4
Boom
PRODUCT INFORMATION
5
Stylus
Use the stylus in three ways:
• Tap item to select (similar to le-clicking a mouse).
• Tap and hold reveals a submenu if available (similar to
right-clicking a mouse).
• Hold and drag the stylus against the screen to
reposion an item or to highlight mulple items (similar
to le-clicking and dragging a computer mouse).
Using anything other than the stylus may damage
the screen.
PRODUCT INFORMATION
6
1. To remove the baery cover, press the release buon
on the boom of the baery cover with your thumb.
Use your opposite hand to slide the cover o.
Do not press the baery cover directly down or the
baery door/sensor could be damaged.
INSTALL BATTERY
7
2. Place the Lithium-ion baery into the baery
compartment with the contacts side rst (the bar code
label facing up).
INSTALL BATTERY
8
3. To replace the baery cover, align the top end of the
cover carefully, leaving a small gap. Then slide the cover
on ll it clicks.
Do not press the baery cover directly down or the
baery door/sensor could be damaged.
INSTALL BATTERY
9
OPTION 1: Charge the SoMo directly from an outlet
using the AC adapter.
Li ap to
access port.
Charge the baery for at least 4 hours.
CHARGE THE SOMO
10
