Snapper 500TRC Manuel utilisateur

Parts Manual fo

Revision 6,

FRONT TINE TILLERS

SERIES 0 & 1

2006

McDonough, GA, 30253 U.S.A.

TP 400-5174-6-RT-N

3/7/2006 Manual No. 7006003

SNAPPER PRODUCTS, INC.

MODEL

300

301

401TCR

500

500T

500TR

501

501T

Table Of Content

TP 400-5174-6-RT-N

Manual No. 7006003FRONT TINE TILLERS

SERIES 0 & 1 3

PAGE GROUP

4Handles, Controls

6Frame Skid Arm

8Transport Wheels & Arms

10 Chain Case

12 Drive - Belt Guard

14 High Torque Drive Kit #60264

16 Tines

Handles, Controls

TP 400-5174-6-RT-N

Manual No. 7006003 FRONT TINE TILLERS

SERIES 0 & 1

Handles, Controls

Footnotes:

TP 400-5174-6-RT-N

Manual No. 7006003FRONT TINE TILLERS

SERIES 0 & 1 5

Part No Descri

tionItem Qt

Note

1 7011870 2 GRIP, Handle

2 7029560 HANDLE BAR, Left Hand Was 36216

3 7018073 CONTROL, Throttle (B&S Shown)

7018092 CONTROL, Throttle (Tec.)

4 7037321 BRACE, Cross

5 7019295 DECAL, SNAPPER Was 18593

6 7031192 2 TIE-BAR

7 7057481 ASSM'Y., Handle (Includes items 8 thru 10 & 14)

8 7036217 HANDLE BAR, Right Hand

9 7040604 LEVER, Clutch Was 40366

10 7023792 PIN Was 11886

11 7091294 WASHER, 1/4 Flat (Discontinued) Was 90055

12 7011187 SPRING (Discontinued)

13 7011715 PIN (Discontinued)

14 7091020 NUT, Push Was 90489

15 7090111 7 SCREW, 1/4-28x1-3/4" Hex Hd. Cap

16 7090053 7 WASHER, 1/4 Internal Tooth

17 7090095 7 NUT, 1/4-28

18 7011709 2 CLIP, Throttle Control

19 7090222 4 NUT, 5/16-24 Hex Lock

20 7090238 2 SCREW, 5/16-24x1" Hex Hd. Cap

21 7090572 2 SCREW, 5/16-24x4" Hex Hd. Cap

22 7011708 GUIDE, Cable

23 7050344 CABLE, Clutch Assm'y. (Includes chain)

24 7011706 SPRING, Clutch Cable

Frame Skid Arm

TP 400-5174-6-RT-N

Manual No. 7006003 FRONT TINE TILLERS

SERIES 0 & 1

Frame Skid Arm

Footnotes:

TP 400-5174-6-RT-N

Manual No. 7006003FRONT TINE TILLERS

SERIES 0 & 1 7

Part No Descri

tionItem Qt

Note

1 7011192 2 HITCH

2 7047339 SKID-ARM

3 7021186 * ARM, Idler

4 7031167 * BRACKET, Idler

5 7031168 * LINK, Idler

6 7037323 RAIL, Left Hand

7 7037324 RAIL, Right Hand

8 7090222 6 NUT, 5/16-24 Hex Center Lock

9 7090289 2 * NUT, 3/8-24 Hex Center Lock

10 7011193 SPRING, Pin Release

11 7090245 SCREW, 5/16-24 x 2" Hex Head Cap, Gr. 2

12 7012591 PIN, Skid Arm Release

13 7010948 * PULLEY, Idler

14 7090233 2 SCREW, 5/16-24 x 3/4" Hex Head Cap, Gr. 5

15 7090122 * WASHER, 3/8 SAE

16 7091630 2 * NUT, 3/8-24 Hex Gr. 2 Was 90155

17 7091297 NUT, 5/16-24 Hex Was 90223

18 7090187 4 WASHER, 5/16 Split Lock

19 7090188 8 WASHER, 5/16 SAE

20 7090244 4 SCREW, 5/16-24 x 1-3/4" Hex Head Cap, Grade 2

21 7090358 3 SCREW, 5/16-24 x 2-1/2" Hex Head Cap, Grade 5

7050340 ASY, Idler Arm (Incl. items 3, 4, 5, 9, 13, 15 and

16)

NOTE: * Included in Idler Arm Assembly

Transport Wheels & Arms

TP 400-5174-6-RT-N

Manual No. 7006003 FRONT TINE TILLERS

SERIES 0 & 1

Transport Wheels & Arms

Footnotes:

TP 400-5174-6-RT-N

Manual No. 7006003FRONT TINE TILLERS

SERIES 0 & 1 9

Part No Descri

tionItem Qt

Note

1 TRANSPORT ASSM'Y. (NA)

2 7040367 FRAME, Arm-Wheel Structure

3 7021184 PIN, Wheel Arm Lock

4 7011190 SPRING, Lock Pin

5 7091809 PIN, 1/8x1-1/4" Cotter Was 90042

6 7090250 WASHER, 1/2 SAE

7 7090289 3 NUT, 3/8-24 Hex Lock

8 7090171 SCREW, 3/8-24x2-3/4" Hex Hd. Cap

9 7018228 2 WHEEL, 10"x1-3/4"

10 7091526 2 BOLT, 3/8-24x2-5/16" Shoulder Was 11720

Chain Case

TP 400-5174-6-RT-N

Manual No. 7006003 FRONT TINE TILLERS

SERIES 0 & 1
