Parts Manual fo
r
Revision 5,
LARGE FRAME REAR TINE TILLERS
SERIES 2
COPYRIGHT
©
2006
McDonough, GA, 30253 U.S.A.
TP 400-5202-5-RT-N
6/20/2006 Manual No. 7006033
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
MODEL
R5002B
R5002
R
R8002B
R8002B
E
RT5
RT5X
RT
8
RT8
S
Table Of Content
s
TP 400-5202-5-RT-N
Manual No. 7006033LARGE FRAME REAR TINE TILLERS
SERIES 2 3
PAGE GROUP
4Wheels, Tires, Rims
6Handle & Controls
8Handle & Controls 8 HP, RT5X
12 Engine & Drive Parts
14 Frame (5HP), Traction Drive
18 Frame (8HP), Traction Drive
22 Frame Components (Left Side) (5 HP)
24 Frame Components (Left Side) (RT5X & RT8)
26 Primary Chain Case
28 Shift Quadrant
30 Idler Bracket Assembly
32 Tiller Head
36 Main Chain Case
40 Tine Assembly
42 Electric Start Components
44 Decals
46 Garden Tool Kit (P/N 60559 Hauling Tray Kit)
48 Garden Tool Accessories (P/N 60730 Harrow Kit)
50 Garden Tool Accessories (P/N 60731 Hiller Furrower Kit)
Wheels, Tires, Rims
TP 400-5202-5-RT-N
Manual No. 7006033 LARGE FRAME REAR TINE TILLERS
SERIES 2
4
Wheels, Tires, Rims
Footnotes:
TP 400-5202-5-RT-N
Manual No. 7006033LARGE FRAME REAR TINE TILLERS
SERIES 2 5
Part No Descri
p
tionItem Qt
y
Note
1 7018579 ASSEMBLY, Right Wheel 13 x 5.00 - 6 (RT5) (Includes items 2, 3, & 4)
7018580 ASSEMBLY, Left Wheel 13 x 5.00 - 6 (RT5) (Includes items 2, 3, & 4)
2 7014511 TIRE, 13 x 5.00 x 6 (Chevron Lug)
3 7014512 RIM, 13 x 5 x 6
4 7012234 VALVE, Air (Snap-In)
5 7059646 ASSEMBLY, Left Wheel (8HP & RT5X) (Includes items 4, 6, & 7)
7050730 ASSEMBLY, Right Wheel (8HP & RT5X) (Includes items 4, 6, & 7)
6 TIRE, 16 x 4.80 x 8 (Chevron Lug) (Not Available) Was 12256
7 7017145 RIM, 4.80-4.00 x 8 (3 hole) Was 12162
8 7090244 2 SCREW, 5/16-24 x 1 5/8" Hex Head Cap, Grade 5 (RT5) Was 90359
9 7090391 2 WASHER, 5/16 Internal Tooth Lock (RT5)
10 7091297 2 NUT, 5/16-24 Hex (RT5) Was 90223
11 7091502 6 SCREW, 1/2-20 x 3/4" Hex Head Cap Was 90367 (8HP & RT5X)
12 7092062 6 NUT, 5/16-24 Hex Lock, GR C Was 11201 (8HP & RT5X)
13 7040434 HUB. Wheel Structure (8HP & RT5X)
14 7011035 2 BOLT, 5/16-24 x 1 5/8" Tapered (8HP & RT5X)
Handle & Controls
TP 400-5202-5-RT-N
Manual No. 7006033 LARGE FRAME REAR TINE TILLERS
SERIES 2
6
Handle & Controls
Footnotes:
TP 400-5202-5-RT-N
Manual No. 7006033LARGE FRAME REAR TINE TILLERS
SERIES 2 7
Part No Descri
p
tionItem Qt
y
Note
1 7035206 BAR, Handle Was 35025
2 7014681 2 BUSHING
3 BAIL (Not Available) Was 18577
4 7014682 CLIP, Cable
5 7036061 PANEL, 5 HP
6 LINK, Wire 2.25" (Not Available) Was 14719
7 7091122 2 SCREW, 1/4-20 x 1/2" Self-Tapping Was 90539
8 7014720 CLIP-SNAP
9 7090858 3 SCREW, 5/16-18 x 1/2" Self-Tapping
10 BRACKET (Not Available) Was 32284
11 2 PLATE, Tap (Not Available) Was 51462
12 TUBE, Handle Bar Support (Not Available) Was 38066
13 7022295 GRIP, Handle Was 10681
14 7014380 SPRING
15 LATCH (Not Available) Was 40509
16 7010935 WASHER, Flat .77 x 1.13 x .06
17 7090620 2 NUT, 3/4-16 Hex Lock
18 7047854 BRACKET, Latch
19 7090361 6 SCREW, 5/16-18 x 5/8" Self-Tapping
20 7090289 NUT, 3/8-24 Hex Center Lock
21 7091588 4 BOLT, 3/8-16 x 3/4" Hex Flange Lock Was 90612
22 7036106 BRACKET, Handle
23 7090169 SCREW, 3/8-24 x 2 1/2" Hex Head Cap
24 7090864 WASHER, 13/16 Flat
25 7014840 RETAINER, Nut Locking
26 7091809 COTTER-PIN, 5/32 x 1 1/4" Was 90654
27 7015251 SPRING, Traction Cable
28 7018776 CABLE, Traction Control
29 7057415 CABLE, Tine Control (Includes items 6 & 8)
30 7015252 SPRING, Tine Cable
31 7091575 2 NUT, 5/16-18 Hex Lock Was 90184
32 7090188 4 WASHER, 5/16 Flat
33 7091830 2 SCREW, 5/16-18 x 3" Hex Head Cap Was 90553
* NOTE: This part may be available from DPNI 1-800-558-1848 (Todd Graff)
Handle & Controls 8 HP, RT5X
TP 400-5202-5-RT-N
Manual No. 7006033 LARGE FRAME REAR TINE TILLERS
SERIES 2
8
Handle & Controls 8 HP, RT5X
Footnotes:
TP 400-5202-5-RT-N
Manual No. 7006033LARGE FRAME REAR TINE TILLERS
SERIES 2 9
Part No Descri
p
tionItem Qt
y
Note
1 7035206 BAR, Handle Was 35025
2 7014681 2 BUSHING
3 * WIRE, Ground 40" (RT8 Manual Start) (Not Available) Was 14384
4 BAIL (Not Available) Was 18577
5 7011853 SWITCH, Ignition (RT8 Manual Start) Was 15211 (See "Electric Start
Components" Illustration & Parts
List)
6 7011138 KEY, Switch
7 7091084 2 SCREW, 1/4-20 x 3/8" Self-Tapping Was 90302
8 7014368 CONTROL, Throttle (8HP)
7015480 CONTROL, Throttle (RT5X)
9 7090858 9 SCREW, 5/16-18 x 1/2" Self-Tapping
10 7014682 CLIP, Cable
11 7091122 3 SCREW, 1/4-20 x 1/2" Self-Tapping Was 90539
12 7036062 PANEL (8HP)
7036062 PANEL (RT5X) Was 36176
13 TUBE, Handle Bar Support (Not Available) Was 38066
14 2 PLATE, Tap Nut (Not Available) Was 51462
15 7032292 BRACKET, Cable
16 7032291 SLIDE
17 * BRACKET (Not Available) Was 32290
18 7090222 NUT, 5/16-24 Hex Center-Lock
19 7090188 6 WASHER, 5/16 Flat
20 7010023 SPRING
21 7013872 STUD, Shift Was 14415
22 7012659 KNOB, 1.62" DIA 3/8-16
23 7040503 HANDLE, Clutch
24 7090240 SCREW, 5/16-24 x 1 1/4" Hex Head Cap (Grade 2)
25 7090187 WASHER, 5/16 Split Lock
26 7091511 NUT, 5/16-18 Hex Was 90196
27 7090820 2 NUT, 3/4-16 Hex Lock
28 7010935 WASHER, 3/4 Flat
29 LATCH (Not Available) Was 40509
30 7047854 BRACKET, Latch
31 7090289 NUT, 3/8-24 Hex Center-Lock
32 7036106 BRACKET, Handle
33 7014380 SPRING
34 7091588 4 BOLT, 3/8-16 x 3/4" Hex Flange Lock Was 90612
35 7090864 WASHER, 13/16 Flat
* NOTE: This part may be available from DPNI 1-800-558-1848 (Todd Graff)
Handle & Controls 8 HP, RT5X
TP 400-5202-5-RT-N
Manual No. 7006033 LARGE FRAME REAR TINE TILLERS
SERIES 2
