Snapper PRO HYDRO SPA361 Manuel utilisateur

Parts Manual fo

Revision IR,

PRO HYDRO WALK BEHIND MOWERS

SERIES 3

2005

McDonough, GA, 30253 U.S.A.

TP 400-5073-IR-CW-N

7/8/2005 Manual No. 7006936

SNAPPER PRODUCTS, INC.

MID-SIZ

POWER UNIT

MODELS MOWER

MODELS

SPLH153K

SPA361

SPLH173K

SPA481

SPA521

SPA611

Table Of Content

TP 400-5073-IR-CW-N

Manual No. 7006936PRO HYDRO WALK BEHIND MOWERS

SERIES 3 3

PAGE GROUP

4LOOP HANDLE & CONTROL ASSEMBLIES

6TRACKING CONTROL ASSEMBLY

8OIL TANK ASSEMBLY

10 FUEL TANK ASSEMBLY

12 REAR DECK ASSEMBLY

14 RH PUMP ASSEMBLY

16 LH PUMP ASSEMBLY

18 POWER UNIT IDLER ASSEMBLY

20 ENGINE GROUP

22 TRACTION, REAR WHEEL ASSEMBLY

24 CASTER, WHEEL & TIRE ASSEMBLY

26 36" MOWER DECK ASSEMBLY (Adjustable Height)

30 48", 52" & 61" MOWER DECK ASSY (Frame)

34 48", 52" & 61" MOWER DECK ASSY (Deck)

38 36" DECK IDLER ASSEMBLY

40 48" & 61" DECK IDLER ASSEMBLY

42 52" DECK IDLER ASSEMBLY

44 CUTTER HOUSING ASSEMBLY

46 DECAL GROUP

48 ELECTRICAL WIRING (Manual Start)

50 WIRING SCHEMATIC (Manual Start)

LOOP HANDLE & CONTROL ASSEMBLIES

TP 400-5073-IR-CW-N

Manual No. 7006936 PRO HYDRO WALK BEHIND MOWERS

SERIES 3

LOOP HANDLE & CONTROL ASSEMBLIES

Footnotes

TP 400-5073-IR-CW-N

Manual No. 7006936PRO HYDRO WALK BEHIND MOWERS

SERIES 3 5

Part No Descri

tionItem Qty Note

1 7011138 1 IGNITION KEY, Pair

2 7012685 1 NUT, 5/8-32 Hex (Ignition Switch)

3 7012686 1 NUT, 1/2-27 Hex (Special)

4 7014341 2 RETAINING RING Truarc #5133-50

5 7017817 1 SWITCH, Ignition, 2-Pole, Recoil Start

6 7022166 1 ROD, Pivot, 1/2” Dia. x 18.542 w/2 retaining Ring Grooves

7 7027141 2 SWIVEL

8 7027225 1 SWITCH, OPC, Single Pole (NC)

9 7028856 2 CONTROL ROD, Traction (5/16-24 threads)

10 7028857 4 BEARING, Nyliner

11 7074648 1 ROD, Operator Presence Control

12 7029139 1 SPRING, OPC- Loop Handle

13 7029715 1 SWITCH, Toggle

14 7034827 1 PANEL, Left

15 7034828 1 PANEL, Right

16 7041748 1 BAIL, Operator Presence Control (Weldment)

17 7091303 4 BOLT, 5/16-18 x 1” Short Neck Carriage, GR 5

18 7090977 2 NUT, 1/4-20 Hex Jam

19 7091003 2 BOLT, 1/4-20 x 1-3/4” Hex Head Cap, GR 5 was 7091222

20 7091030 2 BUSHING, 1/2” Machine

21 7091122 8 SCREW, 1/4-20 x 1/2” Hex Washer Self-Tap

22 7091297 2 NUT, 5/16-24 Hex, GR 5

23 7091299 4 NUT, 3/8-16 Hex Nyloc

24 7077873 2 SCREW, #12-14 x 1/2” Hex Flange Self-Tap

25 7091594 2 COTTER PIN, 1/2” Self-Locking

26 7091686 2 SCREW, 1/4-20 x 3/4” Hex Washer Self-Tap

27 7034820 1 WELDMENT, Traction Lever, RH

28 7034821 1 WELDMENT, Traction Lever, LH

29 7043869 1 HANDLE, Loop (Weldment)

30 7072597 1 THROTTLE CONTROL, 51.50/0.90

31 7012080 4 CABLE TIE, 7”

32 7073118 1 *WIRE HARNESS not shown

33 7074852 1 *HARNESS, Wiring Pigtail not shown

34 7073141 1 SWITCH, Interlock, Sealed (NC)

35 7073139 1 BRACKET, Interlock Switch

36 7090376 2 NUT, #10-32 Hex Nyloc

37 7091240 2 SCREW, #10-32 x 5/8” Hex Machine

*NOTE: See Electrical Wiring pages for Illustration.

TRACKING CONTROL ASSEMBLY

TP 400-5073-IR-CW-N

Manual No. 7006936 PRO HYDRO WALK BEHIND MOWERS

SERIES 3

TRACKING CONTROL ASSEMBLY

Footnotes

TP 400-5073-IR-CW-N

Manual No. 7006936PRO HYDRO WALK BEHIND MOWERS

SERIES 3 7

Part No Descri

tionItem Qty Note

1 7011879 1 GRIP, Vinyl

2 7013550 1 PIN, 3/16 x 1” Roll

3 7011121 2 WASHER, 5/8” I.D., 1-1/4” O.D. Belleville

4 7027125 1 SPRING, Compression

5 7027168 2 SCREW, 5/16-18 X 1” Hex Head Cap, GR 5

6 7027169 1 SCREW, 3/8-16 x 5” Hex Head Cap, GR 5

7 7028859 1 LEVER

8 7028860 2 BUSHING

9 7029040 4 WASHER, Slipper

10 7034803 2 PIN, Shoulder

11 7034830 1 CAM, Track

12 7034877 2 PLATE, Speed, Accutrack

13 7091299 1 NUT, 3/8-16 Hex Nyloc

14 7091706 2 NUT, 5/16-18 Hex Top Lock, GR B

15 7019376 1 HANDLE, Shift Lever

16 7059115 1 WELDMENT, Neutral Latch

17 7041772 1 TRACK, Welded

18 7090517 3 WASHER, 3/8” Flat was 7091300

19 7091130 1 WASHER, .33 x .88 x .09 Flat

OIL TANK ASSEMBLY

TP 400-5073-IR-CW-N

Manual No. 7006936 PRO HYDRO WALK BEHIND MOWERS

SERIES 3

OIL TANK ASSEMBLY

Footnotes

TP 400-5073-IR-CW-N

Manual No. 7006936PRO HYDRO WALK BEHIND MOWERS

SERIES 3 9

Part No Descri

tionItem Qty Note

1 7072899 1 COVER, Oil Tank Bracket

2 7015761 2 SHOULDER BOLT, 5/16-18

3 7091495 2 SCREW, 1/4-20 x 3/4” Hex Head Cap, GR 5

4 7091294 4 WASHER, .28 x .63 x .06 Flat

5 7072895 1 BRACKET, Reservoir, Hydro

6 7011079 2 WASHER, 3/8” Curved

7 7091298 6 NUT, 5/16-18 Hex Nyloc

8 7023295 2 U-NUT 1/4-20

9 7091705 2 NUT, 1/4-20 Hex Top Lock, GR B

10 7091303 4 BOLT, 5/16-18 x 1” Short Neck Carriage, GR 5

11 -- 2 GROMMET Dapco p/n 10672

12 -- 2 *ELBOW Dapco p/n 11021

13 -- 1 GROMMET Dapco p/n 12078

14 7073238 1 *ELBOW Dapco p/n 12183

15 7058610 1 OIL TANK (Includes Cap)

16 7035512 1 CAP, Oil Tank, Vented

17 7072896 1 RETAINING ROD, Reservoir (1/4-20 threads)

18 7012222 2 CLAMP, Fuel Hose

19 7016130 1 CLAMP, 13/16” Hose

20 7078029 2 HOSE, Return, 15-1/4” (7/16-20 Fitting on One End)

21 7072897 1 HOSE, 1/2 x 19-1/2” Supply (3/4-16 Fitting on One End)

22 7042584 1 WELDMENT, Tank Bracket- Hydro

*NOTE: Fittings must withstand pull test of 35 lbs. min.

FUEL TANK ASSEMBLY

TP 400-5073-IR-CW-N

Manual No. 7006936 PRO HYDRO WALK BEHIND MOWERS

SERIES 3
