Smiths Medical CADD-Solis Guide de référence

CADD®Ambulatory Tubing Sets

with Flow Stop

Quick Reference Card

Flow stop free-flow protection is an

integral set-based free-flow protection

device that has been added to CADD

administration sets and to the medication

cassette reservoirs.

Smiths Medical is part of the global technology business Smiths Group plc. Product(s)

described may not be licensed or available for sale in Canada and other countries. Please

see the Instructions for Use/Operator’s Manual for a complete listing of the indications,

contraindications, warnings and precautions. CADD and the Smiths Medical and CADD

design marks are trademarks of Smiths Medical. The symbol ® indicates the trademark is

registered in the U.S. Patent and Trademark Office and certain other countries.

Smiths Medical ASD, Inc.

6000 Nathan Lane North

Minneapolis, MN 55442, USA

Tel: 1-614-210-7300

Toll-Free USA: 1-800-258-5361

www.smiths-medical.com

Find your local contact information at www.smiths-medical.com/customer-support

Filling

The medication cassette

reservoir is designed to be

easily filled with the blue

flow stop clip in place.

Closing the fluid path

Remove the blue clip to

close the fluid path.

Opening the fluid path

Press the green button to

open the fluid path.

CADD®-Solis Pumps

MPAUCA-1161

Smiths Medical International Ltd.

Dubai Airport Free Zone

Building 6WA, Office No. 421

P.O. Box 54862 - Dubai - UAE

Phone: + 971 4 4190900

Smiths Medical International Ltd.

San Croy Office Park

Die Agora Road,

Croydon 1619 - South Africa

Phone: +27 (0)11 974 7134

Smiths Medical International Ltd.

1500 Eureka Park, Lower Pemberton

Ashford, UK TN25 4BF

Phone: +44 (0) 1233 722351

Step 1- Prime the Tubing 5. To lock the disposable, insert the pump key into the lock

and turn it clockwise into the locked position.

6. Open all clamps.

7. Prime the tubing using the pump’s priming feature.

Ensure that the entire fluid path is free of all air.

Maintain asepsis of the distal tubing end.

8. Close all tubing clamps.

For priming:

Remove the blue clip from the disposable.

WARNING: Leave the blue clip on the disposable in place

until ready to attach the disposable to the pump. Storing the

disposable with the blue clip removed may affect delivery

accuracy.

Step 2- Start the Infusion

1. Using aseptic technique, connect the tubing to the

patient’s access site.

2. Open all tubing clamps and begin the infusion.

WARNING: Ensure fluid path below filter is free of air

before connection to patient. Please refer to the detailed

Instructions for Use supplied with the administration

sets, medication cassette reservoirs and extension sets

for additional information, cautions, and warnings. For

pump priming, refer to the Operator’s Manual supplied

with the pump.

1. Clamp the tubing.

2. Make sure the pump latch is unlocked and open the

cassette latch to 90 degrees. Insert the cassette hooks

into the hinge pins on the bottom of the pump.

3. Without holding the pump latch, place the pump upright on

a firm, flat surface, and then press down on the latch side

of the pump until the disposable firmly clicks into place.

4. Lift the pump latch into the closed position. If you

experience resistance when lifting the pump latch, DO NOT

FORCE the latch. If you are unable to latch the disposable

to the pump with minimal-to-no resistance, the disposable

is not in the proper latching position, unlatch the disposable

and repeat the process. If unsuccessful on the second

attempt, do not use the pump and contact Smiths Medical

Customer Service for further assistance.
