Smeg DD612SCA Manuel utilisateur

INSTRUCTION MANUAL

Contents

1. Description of the controls________________________________16

2. Troubleshooting _______________________________________25

Thank you for choosing one of our products.

You are advised to read this manual carefully; it contains all the

information you need about the right conditions for the proper, safe use

of your dishwasher.

The individual sections are laid out to provide you with a step-by-step

guide to all your appliance's functions; the texts are easy to understand

and are complete with detailed illustrations.

This user-friendly manual will provide answers to all your questions

about use of the dishwasher.

For any other information about use and maintenance of the dishwasher,

read the enclosed manual carefully.

USER INSTRUCTIONS: useful information is provided for the use of the

washing programs and all the dishwasher's functions.

User instructions

1. Description of the controls

1.1 Front panel

All the dishwasher control are grouped on the front panel. Programming

and option selection are only possible with the door closed.

1ON/OFF BUTTON

2START/PAUSE BUTTON

3SELECTION PROGRAMS BUTTON

4PROGRAMS LIGHTS

5"3/1" OPTION BUTTON (on some models only)

6"3/1" OPTION LIGHT (on some models only)

7DELAY PROGRAM BUTTON (on some models only)

8DELAY PROGRAM LIGHTS (on some models only)

9NO SALT LIGHT

68910 11 4

157 32

10 NO RINSE AID LIGHT

11 RECESSED DOOR HANDLE

User instructions

SETTING THE WASHING PROGRAM

To select the most suitable program for the dishes to be washed refer to

the table below, which indicates the most appropriate program according

to dish type and degree of soiling.

DURATION CONSUMPTION

PROGRAM SELECTION TYPE AND GRADE DIRT PROGRESS

PROGRAM MINUTES

(2)

WATER

LITRES (1)

POWER

KWh (2)

SOAK

PANS AND DISHES

IN WAITING OF

COMPLETING

THE LOAD

Cold prewash 15' 60,03

LIGHT DISHES

NOT VERY DIRTY

Wash at 45°C

Cold rinse

Rinse at 68°C

Dry

70' 15 1,15

BIO

(*) Bio

PANS AND DISHES

NOT VERY DIRTY BUT

WITH DRY RESIDUALS

Cold prewash

Wash at 50°C

Rinse at 64°C

Dry

170' 171,05

NORMAL

PANS AND DISHES

DIRTY AND WITH

DRY RESIDUALS

Cold prewash

Wash at 65°C

Cold rinse

Rinse at 68°C

Dry

100' 20 1,40

SUPER

PANS AND DISHES

VERY DIRTY AND

WITH DRY RESIDUALS

Prewash at 45°C

Wash at 70°C

2 cold rinses

Rinse at 70°C

Dry

115' 24 1,77

Only run the soak program with half loads.

The "3/1" option (5) is available for all programs except the soak program.

(*) Reference program as per EN 50242 standard.

(1) Average power consumption with the softener set on level 2.

(2) The cycle duration and power consumption may vary according to the water and room

temperatures, and the type and amount of dishes.

The washing cycle will not take place if the dishwasher door is left open

or not properly closed.

User instructions

1.2 Washing programs

The dishwasher is equipped with a control panel, described in chapter

"1. Description of the controls", from which it is possible to carry out all

the power switch-on, switch-off and programming operations.

Before starting a washing program make sure that:

•The water supply tap is open.

•The correct amount of detergent has been added to the

dispenser.

•The baskets have been correctly loaded.

•The spray arms are able to rotate freely and without

obstruction.

•The dishwasher door is securely closed.

SWITCHING ON

When the ON/OFF button (1) is pressed, the dishwasher switches on.

The indicator lights will display the dishwasher's "status".

6 8 9 10 11 4

1 5 7 3 2

User instructions

PROGRAMMING

Programming operations are only possible with the door closed.

As long as the door is open, the PROGRAMS (4) lights remain off.

PROGRAM SELECTION

Press the PROGRAM SELECTION

button (3) several times until the light of

the program required comes on.

STARTING THE PROGRAM

To start the dishwasher, press the START/PAUSE button (2) for a few

seconds, until the light of the selected program starts to flash

(confirmation beep).

The light will flash as long as the program is in progress, to indicate that

it is being performed.

END OF PROGRAM

At the end of the program the beeper

sounds briefly and the program lights 4

and 5(marked "end") flash.

INTERRUPTION A PROGRAM

To interrupt a program in progress:

•press the

START/PAUSE button (2); the light of the program in

progress remains on (confirmation beep);

•you may now restart the program by pressing button (2) again until it

restarts, or change or annul the program (see "CHANGING A

PROGRAM", or "ANNULLING A PROGRAM").

Bio

end

Bio

end

User instructions

CHANGING A PROGRAM

To change the running program it is necessary:

•to interrupt the running program (see “INTERRUPTION A PROGRAM”);

•select the new program;

•start the program (see “STARTING THE PROGRAM”).

ANNULLING A PROGRAM

To annul the program, keep the START/PAUSE button (2) pressed until

the program is interrupted (light on and confirmation beep).

Press button (2) again and keep it

pressed until the lights 4 and 5(marked

"end") come on.

The water in the tank will be pumped out and the program will end at the

point where it was interrupted.

In case that the door is opened during the operation, to the next door

closing it is going to be necessary to start the program as shown in

paragraph “STARTING THE PROGRAM”. The program will resume from the

point in which it was interrupted.

In case that the tub temperature is higher than 50°C the program

will start about 30 seconds later.

"3/1" OPTION BUTTON (on some models only)

(available in all programs except the soak program)

By pressing the button (5)you activate the "3/1" option, confirmed when

the relative light comes on. This option has been studied for the use of

dishwashing powder or tablets with integrated substances in place of

regenerating salt or rinse-aid known on the market as “3 in 1” or “triple

action” products; in this case the dishwasher will use the product in an

optimal way avoiding salt and rinse-aid consumption, which could

already be found in the dishwasher.

Note: When selecting the "3/1" button, it is normal that the salt and

rinse-aid lights remain on, if their containers are empty.

Bio

end

User instructions

DELAYING THE PROGRAM (on some models only)

(available in all programs except the soak program)

The PROGRAM DELAY button (7)can be pressed to delay the start of

the washing program by 3,6or 9 hours. This function allows you to set

the dishwasher to work at your preferred time of day.

After selecting the delay, start the program (see relative section).

The appliance will prewash the dishes, after which the "program delay" set

previously will come into effect (light (8)indicating the time left before the

start of the program and light (4) indicating the program set flash).

If you wish to reset or change the delay once the program has started,

proceed as follows:

xpress the START/PAUSE button (2) for a few seconds, until the

PROGRAM DELAY light (8)and the light (4) of the program set stop

flashing and remain constantly on;

xpress the PROGRAM DELAY button (7)to change or annul the

delay set (lights 3, 6 and 9 off);

xpress the START/PAUSE button (2) to start the program. If a delay

has been set, the PROGRAM DELAY light (8)and the light (4) of

the set program start to flash; if the program delay has been

annulled, only the program light (4) will flash to indicate the start of

the program.

68910 11 4

157 32

User instructions

To set the delay once the program has started, proceed as follows.

If the program you wish to carry out is the same as the one already

in progress:

xpress the START/PAUSE button (2) for a few seconds, until the

program lights 4 and 5(marked "end") come on;

xannul the program in progress (see relative section) and wait for the

cycle to come to an end;

xselect the program again;

xselect the delay required;

xpress the START/PAUSE button (2) to start the new program.

If the program you wish to carry out is different from the one

already in progress:

xpress the START/PAUSE button (2) for a few seconds, until the

program lights 4 and 5(marked "end") come on;

xchange the program;

xselect the delay required;

xpress the START/PAUSE button (2) to start the new program. The

dishwahser will pump out the water and restart with the delay set

and the new program.

68910 11 4

157 32

Bio

end

User instructions

TO SAVE ON ENERGY! … AND PROTECT THE ENVIRONMENT

•Always try to run the dishwasher fully loaded.

•Do not wash the dishes in running water.

•Use the washing program that is most appropriate for each type of

load.

•Do not carry out any preliminary rinsing.

•If available, connect the dishwasher to a hot water supply up to

60°C.

TO CUT DOWN ON DETERGENT CONSUMPTION! … AND PROTECT

THE ENVIRONMENT

The phosphates contained in dishwasher detergents are harmful to the

environment. To avoid using excessive amounts of detergent and to

save on electricity, observe the following:

•separate the more delicate items from dishes that are more

resistant to aggressive detergents and high temperatures;

•do not pour the detergent directly on the dishes.

REMOVING THE DISHES

At the end of the washing program, wait at least 20 minutes before

removing the dishes, to allow them to cool down. To prevent any water

droplets on the upper basket from falling on the dishes in the lower

basket, it is advisable to unload the lower basket first, and then the

upper basket.

68910 11 4

157 32
