TigerStack 10/100

48-Port 10/100Mbps

Stackable Managed Switch

◆48 auto-MDI/MDI-X 10BASE-T/100BASE-TX ports

◆2 Gigabit RJ-45 ports shared with 2 SFP transceiver slots

◆2 Gigabit stacking ports that act as Ethernet ports in

standalone mode

◆Stacks up to 4 units

◆17.6 Gbps of aggregate bandwidth

◆Non-blocking switching architecture

◆Spanning Tree Protocol and Rapid STP

◆Up to four LACP or static 8-port trunks

◆RADIUS and TACACS+ authentication

◆Rate limiting for bandwidth management

◆CoS support for four-level priority

◆Full support for VLANs with GVRP

◆IP Multicasting with IGMP Snooping

◆Manageable via console, Web, SNMP/RMON

Installation Guide

SMC6248M

38 Tesla

Irvine, CA 92618

Phone: (949) 679-8000

TigerStack 10/100

Installation Guide

From SMC’s Tiger line of feature-rich workgroup LAN solutions

February 2005

Pub. # 150000017100H

Information furnished by SMC Networks, Inc. (SMC) is believed to be

accurate and reliable. However, no responsibility is assumed by SMC for its

use, nor for any infringements of patents or other rights of third parties

which may result from its use. No license is granted by implication or oth-

erwise under any patent or patent rights of SMC. SMC reserves the right to

change specifications at any time without notice.

SMC Networks, Inc.

38 Tesla

Irvine, CA 92618

Trademarks:

SMC is a registered trademark; and EZ Switch, TigerStack and TigerSwitch are trademarks of SMC

Networks, Inc. Other product and company names are trademarks or registered trademarks of their

respective holders.

IMITED

ARRANTY

Limited Warranty Statement: SMC Networks, Inc. (“SMC”) warrants its products to be

free from defects in workmanship and materials, under normal use and service, for the

applicable warranty term. All SMC products carry a standard 90-day limited warranty from

the date of purchase from SMC or its Authorized Reseller. SMC may, at its own discretion,

repair or replace any product not operating as warranted with a similar or functionally

equivalent product, during the applicable warranty term. SMC will endeavor to repair or

replace any product returned under warranty within 30 days of receipt of the product.

The standard limited warranty can be upgraded to a Limited Lifetime* warranty by registering

new products within 30 days of purchase from SMC or its Authorized Reseller. Registration

can be accomplished via the enclosed product registration card or online via the SMC web

site. Failure to register will not affect the standard limited warranty. The Limited Lifetime

warranty covers a product during the Life of that Product, which is defined as the period of

time during which the product is an “Active” SMC product. A product is considered to be

“Active” while it is listed on the current SMC price list. As new technologies emerge, older

technologies become obsolete and SMC will, at its discretion, replace an older product in its

product line with one that incorporates these newer technologies. At that point, the obsolete

product is discontinued and is no longer an “Active” SMC product. A list of discontinued

products with their respective dates of discontinuance can be found at:

http://www.smc.com/index.cfm?action=customer_service_warranty.

All products that are replaced become the property of SMC. Replacement products may be

either new or reconditioned. Any replaced or repaired product carries either a 30-day limited

warranty or the remainder of the initial warranty, whichever is longer. SMC is not responsible

for any custom software or firmware, configuration information, or memory data of

Customer contained in, stored on, or integrated with any products returned to SMC pursuant

to any warranty. Products returned to SMC should have any customer-installed accessory or

add-on components, such as expansion modules, removed prior to returning the product for

replacement. SMC is not responsible for these items if they are returned with the product.

Customers must contact SMC for a Return Material Authorization number prior to returning

any product to SMC. Proof of purchase may be required. Any product returned to SMC

without a valid Return Material Authorization (RMA) number clearly marked on the outside

of the package will be returned to customer at customer’s expense. For warranty claims within

North America, please call our toll-free customer support number at (800) 762-4968.

Customers are responsible for all shipping charges from their facility to SMC. SMC is

responsible for return shipping charges from SMC to customer.

IMITED

ARRANTY

WARRANTIES EXCLUSIVE: IF AN SMC PRODUCT DOES NOT OPERATE AS

WARRANTED ABOVE, CUSTOMER’S SOLE REMEDY SHALL BE REPAIR OR

REPLACEMENT OF THE PRODUCT IN QUESTION, AT SMC’S OPTION. THE

FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN

LIEU OF ALL OTHER WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED,

EITHER IN FACT OR BY OPERATION OF LAW, STATUTORY OR OTHERWISE,

INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND

FITNESS FOR A PARTICULAR PURPOSE. SMC NEITHER ASSUMES NOR

AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER

LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION,

MAINTENANCE OR USE OF ITS PRODUCTS. SMC SHALL NOT BE LIABLE

UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THE

ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY

CUSTOMER’S OR ANY THIRD PERSON’S MISUSE, NEGLECT, IMPROPER

INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS TO REPAIR, OR

ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE, OR BY

ACCIDENT, FIRE, LIGHTNING, OR OTHER HAZARD.

LIMITATION OF LIABILITY: IN NO EVENT, WHETHER BASED IN CONTRACT

OR TORT (INCLUDING NEGLIGENCE), SHALL SMC BE LIABLE FOR

INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE

DAMAGES OF ANY KIND, OR FOR LOSS OF REVENUE, LOSS OF BUSINESS, OR

OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE

SALE, INSTALLATION, MAINTENANCE, USE, PERFORMANCE, FAILURE, OR

INTERRUPTION OF ITS PRODUCTS, EVEN IF SMC OR ITS AUTHORIZED

RESELLER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

SOME STATES DO NOT ALLOW THE EXCLUSION OF IMPLIED WARRANTIES

OR THE LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR

CONSUMER PRODUCTS, SO THE ABOVE LIMITATIONS AND EXCLUSIONS

MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL

RIGHTS, WHICH MAY VARY FROM STATE TO STATE. NOTHING IN THIS

WARRANTY SHALL BE TAKEN TO AFFECT YOUR STATUTORY RIGHTS.

* SMC will provide warranty service for one year following discontinuance from the active

SMC price list. Under the limited lifetime warranty, internal and external power supplies, fans,

and cables are covered by a standard one-year warranty from date of purchase.

SMC Networks, Inc.

38 Tesla

Irvine, CA 92618

iii

OMPLIANCES

FCC - Class A

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the instruction manual, may cause interference to radio

communications. It has been tested and found to comply with the limits for a Class A

computing device pursuant to Subpart B of Part 15 of FCC Rules, which are designed to provide

reasonable protection against such interference when operated in a commercial environment.

Operation of this equipment in a residential area is likely to cause interference, in which case the

user, at his own expense, will be required to take whatever measures may be required to correct

the interference. You are cautioned that changes or modifications not expressly approved by the

party responsible for compliance could void your authority to operate the equipment.

You may use unshielded twisted-pair (UTP) cable for RJ-45 connections—Category 3 or greater

for 10 Mbps connections, Category 5 or greater for 100 Mbps connections and Category 5, 5e

or 6 for 1000 Mbps connections. Use 50/125 or 62.5/125 micron multimode fiber optic cable,

or 9/125 micron single-mode cable, for SFP transceiver connections.

Warnings: 1. Wear an anti-static wrist strap or take other suitable measures to prevent elec-

trostatic discharge when handling this equipment.

2. When connecting this switch to a power outlet, connect the field ground lead

on the tri-pole power plug to a valid earth ground line to prevent electrical

hazards.

Industry Canada - Class A

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital

apparatus as set out in the interference-causing equipment standard entitled “Digital Apparatus,”

ICES-003 of the Department of Communications.

Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils

numériques de Classe A prescrites dans la norme sur le matériel brouilleur: “Appareils

Numériques,” NMB-003 édictée par le ministère des Communications.

Japan VCCI Class A

OMPLIANCES

CE Mark Declaration of Conformance for EMI and Safety

(EEC)

SMC contact for these products in Europe is:

SMC Networks Europe,

Edificio Conata II,

Calle Fructuós Gelabert 6-8, 2o, 4a,

08970 - Sant Joan Despí, Barcelona, Spain.

This information technology equipment complies with the requirements of the Council

Directive 89/336/EEC on the Approximation of the laws of the Member States relating to

Electromagnetic Compatibility and 73/23/EEC for electrical equipment used within certain

voltage limits and the Amendment Directive 93/68/EEC. For the evaluation of the compliance

with these Directives, the following standards were applied:

Warning:

Do not plug a phone jack connector in the RJ-45 port. This may damage this device.

Attention: Les raccordeurs ne sont pas utilisés pour le système téléphonique!

RFI Emission:

• Limit class A according to EN 55022:1998

• Limit class A for harmonic current emission according to EN 61000-3-2/

1995

• Limitation of voltage fluctuation and flicker in low-voltage supply system

according to EN 61000-3-3/1995

Immunity:

• Product family standard according to EN 55024:1998

• Electrostatic Discharge according to EN 61000-4-2:1995

(Contact Discharge: ±4 kV, Air Discharge: ±8 kV)

• Radio-frequency electromagnetic field according to EN 61000-4-3:1996

(80 - 1000 MHz with 1 kHz AM 80% Modulation: 3 V/m)

• Electrical fast transient/burst according to EN 61000-4-4:1995 (AC/DC

power supply: ±1 kV, Data/Signal lines: ±0.5 kV)

• Surge immunity test according to EN 61000-4-5:1995

(AC/DC Line to Line: ±1 kV, AC/DC Line to Earth: ±2 kV)

• Immunity to conducted disturbances, Induced by radio-frequency fields:

EN 61000-4-6:1996 (0.15 - 80 MHz with

1 kHz AM 80% Modulation: 3 V/m)

• Power frequency magnetic field immunity test according to

EN 61000-4-8:1993 (1 A/m at frequency 50 Hz)

• Voltage dips, short interruptions and voltage variations immunity test

according to EN 61000-4-11:1994 (>95% Reduction @10 ms, 30%

Reduction @500 ms, >95% Reduction @5000 ms)

LVD:

• EN60950:2000

OMPLIANCES

Safety Compliance

Warning: Fiber Optic Port Safety

Avertissment: Ports pour fibres optiques - sécurité sur le plan optique

Warnhinweis: Faseroptikanschlüsse - Optische Sicherheit

Power Cord Safety

Please read the following safety information carefully before installing the switch:

WARNING

Installation and removal of the unit must be carried out by qualified personnel only.

• The unit must be connected to an earthed (grounded) outlet to comply with international

safety standards.

• Do not connect the unit to an A.C. outlet (power supply) without an earth (ground)

connection.

• The appliance coupler (the connector to the unit and not the wall plug) must have a

configuration for mating with an EN 60320/IEC 320 appliance inlet.

• The socket outlet must be near to the unit and easily accessible. You can only remove power

from the unit by disconnecting the power cord from the outlet.

• This unit operates under SELV (Safety Extra Low Voltage) conditions according to

IEC 60950. The conditions are only maintained if the equipment to which it is connected also

operates under SELV conditions.

France and Peru only

This unit cannot be powered from IT

†

supplies. If your supplies are of IT type, this unit must be

labelled Neutral, connected directly to earth (ground).

†

Impédance à la terre

When using a fiber optic port, never look at the transmit laser while

it is powered on. Also, never look directly at the fiber TX port and

fiber cable ends when they are powered on.

Ne regardez jamais le laser tant qu’il est sous tension. Ne regardez

jamais directement le port TX (Transmission) à fibres optiques et les

embouts de câbles à fibres optiques tant qu’ils sont sous tension.

Niemals ein Übertragungslaser betrachten, während dieses

eingeschaltet ist. Niemals direkt auf den Faser-TX-Anschluß und auf

die Faserkabelenden schauen, während diese eingeschaltet sind.

CLASS I

LASER DEVICE

DISPOSITIF LASER

DE CLASSE I

LASERGER

DER KLASSE I

ÄT

OMPLIANCES

Important!

Before making connections, make sure you have the correct cord set. Check it (read the

label on the cable) against the following:

Veuillez lire à fond l'information de la sécurité suivante avant

d'installer le Switch:

AVERTISSEMENT:

L’installation et la dépose de ce groupe doivent être confiés à un personnel

qualifié.

• Ne branchez pas votre appareil sur une prise secteur (alimentation électrique) lorsqu'il n'y a pas

de connexion de mise à la terre (mise à la masse).

• Vous devez raccorder ce groupe à une sortie mise à la terre (mise à la masse) afin de respecter

les normes internationales de sécurité.

• Le coupleur d’appareil (le connecteur du groupe et non pas la prise murale) doit respecter

une

configuration qui permet un branchement sur une entrée d’appareil EN 60320/IEC

320.

• La prise secteur doit se trouver à proximité de l’appareil et son accès doit être facile. Vous ne

pouvez mettre l’appareil hors circuit qu’en débranchant son cordon électrique au niveau de

cette prise.

• L’appareil fonctionne à une tension extrêmement basse de sécurité qui est conforme à la

norme IEC 60950. Ces conditions ne sont maintenues que si l’équipement auquel il est

raccordé fonctionne dans les mêmes conditions.

Power Cord Set

U.S.A. and Canada The cord set must be UL-approved and CSA certified.

The minimum specifications for the flexible cord are:

- No. 18 AWG - not longer than 2 meters, or 16 AWG.

- Type SV or SJ

- 3-conductor

The cord set must have a rated current capacity of at least 10 A

The attachment plug must be an earth-grounding type with NEMA

5-15P (15 A, 125 V) or NEMA 6-15P (15 A, 250 V) configuration.

Denmark The supply plug must comply with Section 107-2-D1, Standard

DK2-1a or DK2-5a.

Switzerland The supply plug must comply with SEV/ASE 1011.

U.K. The supply plug must comply with BS1363 (3-pin 13 A) and be fitted

with a 5 A fuse which complies with BS1362.

The mains cord must be <HAR> or <BASEC> marked and be of

type HO3VVF3GO.75 (minimum).

Europe The supply plug must comply with CEE7/7 (“SCHUKO”).

The mains cord must be <HAR> or <BASEC> marked and be of

type HO3VVF3GO.75 (minimum).

IEC-320 receptacle.

Autres manuels pour SMC6248M

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels SMC Networks Changer

SMC Networks

SMC Networks TigerSwitch SMC8126PL2-F Manuel utilisateur

SMC Networks

SMC Networks D-F7NJL Series Mode d’emploi

SMC Networks

SMC Networks D-M9NAV Mode d’emploi

SMC Networks

SMC Networks EZSwitch SMCGS24C-Smart Manuel utilisateur

SMC Networks

SMC Networks PF3AmH Series Manuel utilisateur

SMC Networks

SMC Networks PF3A-H Series Manuel utilisateur

SMC Networks

SMC Networks ZSE40A Manuel utilisateur

SMC Networks

SMC Networks EZ Net 16SW EZNET-16SW Manuel utilisateur

SMC Networks

SMC Networks SMC6724L3 Manuel utilisateur

SMC Networks

SMC Networks SMC6924VF Manuel utilisateur

SMC Networks

SMC Networks ZSE3 Manuel d'installation

SMC Networks

SMC Networks TigerSwitch SMC8708L2 Manuel utilisateur

SMC Networks

SMC Networks TigerSwitch SMC8124PL2 Manuel utilisateur

SMC Networks

SMC Networks ZSE80(F) Manuel utilisateur

SMC Networks

SMC Networks SMC EZ Switch 10/100/1000 SMCGS8P-Smart Manuel utilisateur

SMC Networks

SMC Networks EZ Connect USB 2.0 7-Port Hub MCUSBH7 Manuel utilisateur

SMC Networks

SMC Networks ISE40A Manuel utilisateur

SMC Networks

SMC Networks 8724M INT - annexe 1 Manuel utilisateur

SMC Networks

SMC Networks 6152L2 Manuel de programmation

SMC Networks

SMC Networks GS16 Manuel utilisateur

SMC Networks

SMC Networks SMC EZ Switch 10/100/1000 SMCGS8P-Smart Manuel utilisateur

SMC Networks

SMC Networks PFMC7501-L Manuel utilisateur

SMC Networks

SMC Networks SMC EZ Switch 10/100/1000 SMCGS8P-Smart Manuel utilisateur

SMC Networks

SMC Networks TigerSwitch 10/100 SMC6750L2 Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
