SMC Networks 7901WBRA2 FICHE Manuel utilisateur

EZ Connect N

Draft 11n Wireless USB2.0 Adapter

ADSL2 BARRICADE ™

1-Port Wireless Annex A ADSL/ADSL2 Modem Router

SMC7901WBRA2

Fast Ethernet Router with

built-in ADSL2/2+ Modem

From SMC’s line of award-winning connectivity solutions

March 2009

R.01 f/w 1.0

Information furnished is believed to be accurate and reliable. However, no responsibility is assumed

by our company for its use, nor for any infringements of patents or other rights of third parties which

may result from its use. No license is granted by implication or otherwise under any patent or patent

rights of our company. We reserve the right to change specifications at any time without notice.

SMC Networks, Inc.

20 Mason

Irvine, CA 92618

Trademarks:

SMC is a registered trademark; and Barricade is a trademark of SMC Networks, Inc. Other product

and company names are trademarks or registered trademarks of their respective holders.

Warranty and

Prodcut Registration

To register SMC products and to review the detailed warranty statement, please refer to

the Support Section of the SMC Website at http://www.smc.com

SMC Networks, Inc.

20 Mason

Irvine, CA 92618

iii

Compliances

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can radiate radio frequency

and, if not installed and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined

by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more

of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the distance between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

FCC Caution:To assure continued compliance, (example - use only shielded interface cables when

connecting to computer or peripheral devices) any changes or modifications not expressly approved by the

party responsible for compliance could void the user’s authority to operate this equipment.

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.

This equipment should be installed and operated with a minimum distance of 20cm between the radiator

and your body. This transmitter must not be co-located or operating in conjunction with any other

antenna or transmitter..

FCC - Part 68

This equipment complies with Part 68 of the FCC rules. This equipment comes with a label attached to

it that contains, among other information, the FCC registration number and ringer equivalence number

(REN) for this equipment. If requested, this information must be provided to the telephone company.

This equipment uses the following jacks: RJ-11.

The REN is used to determine the quantity of devices that may be connected to the telephone line.

Excessive RENs on the telephone line may result in the devices not ringing in response to an incoming

call. In most, but not all areas, the sum of the RENs should not exceed five (5.0). To be certain of the

number of devices that may be connected to the line, as determined by the total RENs, contact the

telephone company to determine the maximum REN for the calling area

IMPORTANT NOTE:

IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to channels 1 through 11.

Industry Canada Statement

Operation is subject to the following two conditions:

1. This device may not cause interference and

2. This device must accept any interference, including interference that may cause undesired operation of

the device

To prevent radio interference to the licensed service, this device is intended to be operated indoors and

away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed

outdoors is subject to licensing.

This device has been designed to operate with an antenna having maximum gain of 1.5dBi.

Any antenna having a higher gain is strictly prohibited per regulations of Industry Canada. The required

antenna impedance is 50 ohms.

To reduce potential radio interference to other users, the antenna type and its gain should be so chosen

that the EIRP is not more than required for successful communication.

EC Declaration of Conformity

SMC contact for these products in Europe is:

SMC Networks Spain, S.L.

Edificio Conata II,

Group CTSG

Fructuos Gelabert 6-8 2o2a

08970 Sant Joan Despi, Barcolona,Spain

This product indicates compliance with the Essential Requirements of the R&TTE Directive of the

European Union (1999/5/EC). This equipment meets the following conformance standards.

EN 55022:2006 Class B EN55024:1998 +A1:2001 +A2:2003

EN 61000-3-2: 2006 IEC61000-4-2: 1995 +A1 : 1998 +A2 : 2000

IEC61000-4-3: 2002 +A1 :2002

EN 61000-3-3:1995 +A1: 2001+A2:2005 IEC61000-4-4: 2004

IEC61000-4-5: 1995 + A1 : 2000

IEC61000-4-6: 2003 + A1: 2004

IEC61000-4-8: 1993 + A1 : 2000

IEC61000-4-11: 2004

EN 60950-1:2001+A11:2004 IEC60960-1:2001

NCC Statement

依據低功率電波幅射性電機管理辦法

第十二條經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者不得擅自變更頻

率、加大功率或變更原設計之特性及功能

第十四條低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，

應立即使用，並改善至無干擾時方得繼續使用。

前項合法通信，指依電信規定作業之無線電信。低功率射頻電機須忍受合法通信或工業、科學

及醫療用電波幅射性電機設備之干擾。

Countries of Operation & Conditions of Use in the European Community

This device is intended to be operated in all countries of the European Community.

Requirements for indoor vs. outdoor operation, license requirements and allowed channels of operation

apply in some countries as described below.

Note: The user must use the configuration utility provided with this product to ensure the channels of

operation are in conformance with the spectrum usage rules for European Community countries as

described below.

．This device requires that the user or installer properly enter the current country of operation in the

command line interface as described in the user guide, before operating this device.

．This device will automatically limit the allowable channels determined by the current country of

operation. Incorrectly entering the country of operation may result in illegal operation and may cause

harmful interference to other system. The user is obligated to ensure the device is operating according

to the channel limitations, indoor/outdoor restrictions and license requirements for each European

Community country as described in this document.

．This device may be operated indoors or outdoors in all countries of European Community using the

2.4GHz band: Channel 1-13.

Declaration of Conformity in Languages of the European Community
