Key Features and Benefits

The EZ Connect™ N 150Mbps Wireless USB2.0 Adapter (SMCWUSBS-N3) enables

wireless connectivity to your desktop or notebook computer and provides improved

throughput and range while maintaining full backwards compatibility with the

Wireless-G (802.11g) and Wireless-B (802.11b) standards. It utilizes advanced

MIMO (Multiple-In, Multiple-Out) technology to deliver incredible speed and range.

With security being a key consideration, SMCWUSBS-N3 supports the latest WPA

and WPA2 wireless encryption standards, which prevent unauthorized access to

wireless networks and ensure data is secure. The SMCWUSBS-N3 includes an easy

installation wizard which guides you step-by-step through the process. Once installed

the WLAN utility allows you to scan for available wireless networks and manage

multiple network profiles so connecting becomes instantaneous.

Product Overview

SMCWUSBS-N3

150Mbps Wireless N USB Adapter

Faster Speeds

SMCWUSBS-N3 Wireless-N USB 2.0 Adapter delivers

amazing speeds of up to 150Mbps.

Advanced Security

SMCWUSBS-N3 supports WEP64/128, WPA/WPA2-

Pre-shared Key (PSK) and Enterprise (IEEE 802.1x) for

a comprehensive security selection.

Easy to Use

EZ ConnectTM quickly takes you step-by-step for easy

use of the SMCWUSBS-N3. An intuitive user interface

makes monitoring and configuration a breeze.

Application Diagram

PHYSICAL

USB 2.0

MODES

• Modes: Infrastructure and Ad-hoc

• Soft AP (Windows only)

SECURITY FEATURES

• WEP 64/128-bit encryption

• WPA/WPA2-PSK (Pre-shared Key, AES, TKIP)

• WPA/WPA2 Enterprise (IEEE 802.1x)

QUALITY-OF-SERVICE

• WMM (Wi-Fi Multimedia)

OUTPUT POWER (Typical)

• IEEE 802.11n: 16 +/-1dBm

• IEEE 802.11g: 16 +/-1dBm

• IEEE 802.11b: 18 +/-1dBm

STANDARDS

Based on IEEE 802.11n technology

IEEE 802.11g

IEEE 802.11b

OPERATING FREQUENCY

USA: 2412~2462MHz (Ch1~Ch11)

Canada: 2412~2462MHz (CH1~CH11)

Europe: 2412~2472MHz (CH1~CH13)

DIMENSIONS

•76.82 x 23 x 13.1mm (2.99 x 0.91 x 0.52in)

WEIGHT

•14g (0.5oz)

OPERATING TEMPERATURES

•0°C ~ 40°C (32°F ~ 104°F)

HUMIDITY

•5% ~ 95% Non-condensing

PACKAGE CONTENTS

• SMCWUSBS-N3 150 Mbps Wireless-N USB Adapter

• Quick Installation Guide

• Auto-run CD-ROM

• Warranty Information Card

SYSTEM REQUIREMENTS

• 2.4GHz 802.11n wireless network

or 2.4Ghz 802.11b/g wireless network

• OS Compatibility:

- Microsoft Windows 2000, XP, Vista, Windows 7

- MacOS v10.3, 10.4, 10.5

- Linux

• Notebook or Desktop with 300MHz CPU or better, 20MB of

available hard disk space, CD-ROM drive

COMPLIANCE

•EMC

- FCC: Part15 sub-part B

- CE: EN 301489-1 V1.8.1 /-17 V1.3.2 (2008-04)

•ERM

- FCC: Part15 sub-part C

- CE: EN 300328 V1.7.1 (2006-10)

- NCC: LP0002

• Safety: CE: EN 60950-1 (2006)

WARRANTY

Please check www.smc.com for the warranty

terms in your country/region.

Features

Contact

North America

20 Mason, Irvine,

CA 92618, U.S.A.

1-800-SMC-4YOU

24/7 Technical Support

Europe/Africa

Fructuos Gelabert 6-8

08970 Sant Joan Despi

Barcelona, Spain

SMC Networks Asia Pacific

1 Coleman Street

#07-09, The Adelphi

Singapore 179803

Tel : 65-63387667 Fax : 65-63387767

Taiwan

No. 1 Creation Rd, lll,

Science-based Industrial Park,

Hsinchu 30077, Taiwan, R.O.C.

Tel: +886 3 5770270 Fax: +886 3 5780764

Check www.smc.com for your local country contact information

Networks. Other trademarks or registered trademarks are the

property of their respective owners. Information is subject to
