SMC Networks EZ Connect SMC2662W Manuel utilisateur

SMC2662W

Model Number::

Features

• Wireless connectivity via USB port

• Up to 11 Mbps wireless LAN

• Up to 1,800 ft.operating range

• 2.4 GHz frequency band

• Direct Sequence Spread

Spectrum (DSSS)

• 64-bit or 128-bit encryption

Benefits

• Instant access to shared information

without the need to plug in

• Network managers can set up,move,or

expand a new LAN with no need for

installation or moving wires

• 11 Mbps performance will meet most

foreseeable networking needs

• Wireless LANs are tremendously conven-

ient,help to enhance productivity, and

provide a real cost benefit over traditional

wired networks (no installation or mainen-

nance expenses)

• Plug-and-play;no configuration needed

Compatibility

• IEEE 802.11b

• Windows

98/Me/2000

EZ ConnectTM

11 Mbps Wireless USB Adapter

Overview

wireless

This wireless USB adapter combines the ease-of-use

and convenience of USB-enabled PCs with the bene-

fits of 11 Mbps wireless operation in a full-featured

solution for the networked environment. It connects

instantly with an existing Ethernet installation to sup-

port mobile users, temporary work sites,sharing of

peripherals,and wireless multimedia.

Wireless solutions provide the ultimate in mobility,

simple and flexible installation options,a reduced cost

of ownership (no cabling costs or maintenance), and

excellent scalability in supporting additional PCs on

the LAN. 11 Mbps wireless LAN solutions are ideal for

use with cable or xDSL modems and SOHO applica-

tions.

In the typical wireless configuration, an Access Point

(SMC2655W) connects to a wired network.The Access

Point supports up to 64 users,with a maximum range

of 1,800 feet. Users access the LAN via SMC wireless

adapters in their notebooks or desktops.The wireless

LAN adapters interface between the client Network

Operating System and the Access Point. In a peer-to-

peer configuration, one wireless card is needed for

each computer,but no Access Point is required.

6 H u g h e s

Irvine, CA 92618

1-800-SMC-4YOU

www.smc.com

Product Description

EZ Connect

11 Mbps Wireless USB Adapter

SMC2662W

DataRates

11,5.5,2,1 Mbps

MaximumChannels

US & Canada:11

Europe:13

Japan:14

OperatingRange

Up to 1,800 ft

Network Configuration

Ad-hoc (peer-to-peer)

Infrastructure

RadioSignalType

Direct Sequence Spread Spectrum (DSSS)

Encryption

64-bit or 128-bit key

OperatingFrequency

US Canada: 2.400-2.483.5GHz

ETSI Japan: 2.400-2.497GHz

Sensitivity

Min.-76dBm for 11 Mbps @BER 10E-5;

Min.-80dBm for 5.5/2/1 Mbps @BER 10E-5

Modulation

QPSK,BPSK,CCK

OutputPower

13dBm (50 mW) (maximum)

OperatingSystems

Windows 98/Me/2000

InbandManagement

Windows 98/Me/2000 Configuration Utility

PowerConsumption

400 mA @5v transmit

300 mA @5v receive

Size

5.25 x 4.25 x 1.125 in

Weight

0.42 lbs

LEDIndicators

Power

Transmit

Receive

Antenna

External

Temperature

Operating:32° - 122° F

Storage:32° - 158° F

Humidity

0% – 95%,(non-condensing)

Compliances

FCC Part 15,Sec.15.247,Sec.15.107 and 15.109

(USA)

ETSI 300 328,ETSI 300 826

EN 55022 Class B,EN 60950

CE Mark

Standards

IEEE 802.11b

USB 1.1

Warranty

Limited lifetime

wireless

EZ ConnectTM

11 Mbps Wireless USB Adapter
