SmarTrunk Systems ST-2112D Manuel utilisateur
UHF FM DIGITAL TRANSCEIVER
ST-2112D (450Mhz ~ 520Mhz)
ST-2112C (400Mhz ~ 470Mhz)
VHF FM DIGITAL TRANSCEIVER
ST-2112V (136Mhz ~ 174Mhz)
SmarTrunk Systems, INC.
ST-2112UM R1.1
Printed in Malaysia
Page 2
FEDERAL COMMUNICATIONS COMMISSION
INTERFERENCE STATEMENT
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and
receiver.
--Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
--Consult the dealer or an experienced radio/TV
technician for help.
FCC NOTICE
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
Page 3
THANK YOU!
We are grateful you chose SmarTrunk for your land mobile radio
applications. We believe this powerful, flexible and easy-to-use
transceiver will provide dependable and reliable communications to
keep personnel operating at peak efficiency.
SmarTrunk transceivers incorporate the latest in advanced SDR
technology. As a result, we feel strongly that you will be pleased with the
quality and features of this product.
NOTICES TO THE USER
GOVERNMENT LAW PROHIBITS THE OPERATION OF
UNLICENSED RADIO TRANSMITTERS WITHIN THE
TERRITORIES UNDER GOVERNMENT CONTROL.
ILLEGAL OPERATION IS PUNISHABLE BY FINE,
IMPRISONMENT, OR BOTH.
REFER SERVICE TO QUALIFIED TECHNICIANS ONLY.
SAFETY: It is important that the operator is aware of and understands
hazards common to the operation of any transceiver.
WARNING:
EXPLOSIVE ATMOSPHERES (GASES, DUST, FUMES, etc.)
Turn off your transceiver while taking on fuel, or while parked in gasoline
service stations.
Page 4
ATTENTION (U.S.A. Only):
The RBRC Recycle seal found on Smartrunk lithium-ion (Li-
Ion) battery packs indicates Smartrunk‘s voluntary
participation in an industry program to collect and recycle
Li-Io batteries after their operating life has expired. The
RBRC program is an alternative to disposing Li-Io batteries
with your regular refuse or in municipal waste streams,
which is illegal in some areas.
For information on Li-Ion battery recycling in your area, call
(toll free) 1-800-8-BATTERY (1-800-822-8837).
Smartrunk’s involvement in this program is part of our
commitment to preserve our environment and conserve
our natural resources.
PRECAUTIONS
Observe the following precautions to prevent fire, personal
injury, and transceiver damage.
- Do not modify this transceiver for any reason.
- Do not expose the transceiver to long periods of direct
sunlight, nor place it close to heating appliances.
- Do not place the transceiver in excessively dusty, humid,
and/or wet areas, or on unstable surfaces.
- If an abnormal odor or smoke is detected coming from
the transceiver, switch OFF the power immediately and
remove the optional battery pack from the transceiver.
Contact your SmarTrunk dealer.
Page 5
CONTENTS
Contents Page
APPENDIX I : TYPING……………………………….………………………….. 44
APPENDIX II : SELECTIVE CALLS............................................... 46
APPENDIX III: CONTACTS ........................................................ 48
APPENDIX IV: DEALER PROGRAMMED FUNCTIONS .............. 49
BATTERY CHARGER .................................................................. 11
CHARGING BATTERY FROM USB PORT.................................... 10
DISPLAY.................................................................................... 21
GETTING ACQUAINTED ............................................................ 18
ICONS ....................................................................................... 22
Installing the Antenna ST-FA0X............................................... 15
Installing the Belt Clip.............................................................. 15
Installing/ Removing the LI-Ion Battery Pack.......................... 15
LED INDICATOR ........................................................................ 26
MAKING A CALL ....................................................................... 20
MENU....................................................................................... 31
MENU ANNOUNCEMENTS .................................................. 38
MENU CONTACTS................................................................ 42
MENU DISPLAY.................................................................... 35
MENU E-MAIL...................................................................... 40
MENU GPS........................................................................... 39
MENU INFO ......................................................................... 43
MENU MESSAGES................................................................ 36
MENU RADIO ...................................................................... 33
PROGRAMMABLE BUTTONS FUNCTIONS ............................... 27
Page 6
ROTARY FUNCTIONS ................................................................24
SMARTRUNK ST-SBP18 ..............................................................8
SWITCH ON/OFF AND VOLUME SELECTOR .............................26
UNPACKING AND CHECKING EQUIPMENT ................................7
Page 7
UNPACKING AND CHECKING EQUIPMENT
Note: The following unpacking instructions are for use by your
SmarTrunk dealer, an authorized SmarTrunk service facility, or the
factory.
Carefully unpack the transceiver. We recommend that you identify the
items listed in the following table before discarding the packing material.
If any items are missing or have been damaged during shipment, file a
claim with the carrier immediately.
Supplied Accessories
Item
Part number
Quantity
Battery pack
ST-SBP18
1
Belt clip
ST-2112BC
1
Screw set
ST-2112BCS
1
Accessory connector cap
ST-2112ACC
1
Instruction manual
ST-2112UM
1
Smartrunk ST-2112 Transceiver
ST-2112X
1
Desktop Battery Charger
ST-BC-D01
1
AC Power adaptor
ST-AC-D01
1
Antenna
ST-FA0X
1
Before to start, you must read carefully about the battery and the battery
charger operation, then assembly the radio as per the instructions
bellow.
Page 8
SMARTRUNK ST-SBP18
SMART BATTERY PACK
RECOMMENDATIONS
If not charged or used correctly, Lithium Polymer batteries
may ignite without warning and cause serious injury and
property damage. If you are unable to follow the safety
recommendations then do not use them
Do not charge Lithium Polymer cells on or near combustible
materials including paper, plastic, carpets, vinyl, leather, or
wood. Do not charge inside an automobile.
Do not forcefully discharge the Lithium Polymer battery.
Doing so will damage the pack.
Never exceed the charge or discharge current rating.
Do not expose Lithium Polymer cells to water or moisture at
any time.
Do not store or use Lithium Polymer batteries near an open
flame or heater.
Never use a Lithium Polymer battery that may have been
subjected to damage or harsh handling. Carefully inspect the
Page 9
battery and connectors for even the smallest damage.
CAUTION: cells may be hot!
Do not allow the electrolyte to get into eyes or on skin. Wash
affected areas immediately if they come into contact with
electrolyte.
Do not alter or modify connectors or wires of a Lithium
Polymer battery pack.
NEVER incinerate used batteries. This may cause an
explosion.
NEVER use the charger when it is covered by objects that
impede heat dispersal.
Make sure battery and charger contacts are always clean;
otherwise, batteries may not fully charge.
Lithium Polymer batteries are different from Ni-Cd batteries
in that it is not necessary to completely charge and discharge
them to extend the battery life. Therefore, charging the
battery when the remaining charge is under 10% and keep
charging up to the battery reaches 90% is recommended to
extend the battery life.
If your batteries seem to have no capacity even after being
fully charged, charge them again. If they do not retain a
charge (or very little), new batteries must be purchased.
Page 10
CHARGING BATTERY FROM USB PORT
Your radio includes a built-in battery charger trough the USB radio
connector. This feature allows the user to charge the battery with any
USB cable connected to a source that can supply current for example PCs,
USB ports, USB chargers, etc.
Take notice most of the USB chargers are not for radios and the current
supplied by these could be too low to charge the battery quickly. A radio
receiving with high volume can demand more current than the current
supplied by the USB charger meaning the battery will take long to be fully
charged.
To charge the battery just plug the USB cable into the USB connector in
the radio, the radio will play a sound confirming the USB is already
plugged. After unplug the cable, it is necessary to put again the USB
connector cap to protect the radio from dust and harmful substances or
gasses.
