WARNING & CAUTION
ØPlease handle the equipment with care. Physical Damage to the system is not covered
under warranty.
ØDo not power on the system without reading this manual. Ensure proper power supply
with Earthing.
ØNote down the serial number and model no. of the device for future reference and quote in
all support and service requests.
ØTo connect or interface the Card reader to the Smart XS NG unit please refer to the
Hardware Installation Guide or Manual and carefully follow the instructions. A trained
technician must make the connections.
Any negligence on your part may damage the Card reader interface on the Smart XS NG
terminal.
ØDo not use this unit near water.
ØDo not open system or places it near other heavy electrical equipment. The system is
sensitive to Electro Static Discharge (ESD)
ØNever insert objects of any kind into the unit or through the cabinet slots as they may
touch voltage points and/or short circuit parts possibly resulting in fire or electric shock.
Never spill liquid of any kind on the unit.
ØWhen connecting up the Controller Access Controller ensure that the mains power supply
is safely isolated. Power up the controller only when installation is complete.
ØOperating conditions: 0 to 55 deg Celsius and 50 deg Celsius at 90% RH.
Fire Safety and accountability Notice
When connecting card or Biometric readers to any emergency entry, exit door, barrier or elevator
must provide an alternative exit in accordance with all fire and life safety codes pertinent to the
installation. These fire and safety codes vary from city to city and you must get approval from
local fire officials whenever using an electronic product to control a door or other barrier.
Important Instructions
Care should be taken identifying the wires. Improper wiring may render permanent
damage to the device or personal injury.
Refer the color code on the Reader to connect the external weigand reader on the
controller.
Check the earthing at the site before installing the controllers. Normally the earthing
should be between 1V to 2V only. Earthing on the higher side may damage the controller
or its various other components.
Before Installation delete all data (Factory reset) using keypad menu * 90
Disclaimer
Changing of default user password is mandatory to avoid tampering of the device.
In case of user password not changed; smart I will not be responsible for any tampering on
the device.
