SMART-AVI UTX-500 Manuel utilisateur

Extend WUXGA Video, Stereo Audio

and USB 1.1 up to 300 feet over 2

CAT5 Cables

UTX-500

WUXGA, Audio and USB Extender

over 2 CAT5 Cables

www.smartavi.com

Installation

Manual

What’s in the Box?

PART NO. QTY DESCRIPTION

UTX-TX500 1 UTX-500 Transmitter

UTX-RX500 1 UTX-500 Receiver

PS5VDC2A 2 5 Volt 2 Amp Power Supply

CCUSBAB06 1 6ft USB MM AB cable

CCVGAMM06 1 6ft XVGA MM Cable

Technical Specications

VIDEO

Format RGBHV, RGsB, YUV, Y/C, CVBS

Resolution Up to 1920 x 1200 VGA, SVGA, XGA, SXGA,

UXGA, WUXGA

Input Interface (TX) (1) HD-15 Female

Output Interface (RX) (1) HD-15 Female

AUDIO

Signal Type Stereo Unbalanced

Input Interface (TX) 3.5 mm Jack Socket (Female)

Output Interface (RX) 3.5 mm Jack Socket (Female)

USB

Signal Type USB 1.1

Input Interface (TX) (1) USB Type B (Female)

Output Interface (RX) (4) USB Type A (Female)

OTHER

Power External 100-240 VAC/5VDC2A @10W

Dimensions 5.5 in W x 1 in H x 3.375 in D

Weight 1 lb

Operating Temp. 0-55 °C (32-131°F)

Storage Temp. -20-85 °C (-4-185 °F)

Humidity Up to 95%

NOTICE

The information contained in this document

is subject to change without notice. Smart-AVI makes

no warranty of any kind with regard to this material,

including but not limited to, implied warranties of

merchantability and fitness for any particular purpose.

Smart-AVI will not be liable for errors contained herein or for

incidental or consequential damages in connection with the

furnishing, performance or use of this material.

No part of this document may be photocopied, reproduced or

translated into another language without prior written consent

from Smart-AVI.

For more information, visit www.smartavi.com.

SmartAVI, Inc. / Twitter: smartavi

11651 Vanowen St. North Hollywood, CA 91605

Tel: (818) 503-6200 Fax: (818) 503-6208

http://www.SmartAVI.com

Rack Mountable Option

Our SmartRack is the perfect solution to allow

virtually all SmartAVI devices to be custom mounted

in a standard 19” server rack. The SmartRack is fully

adjustable and can secure/organize several devices.

Up to 275 ft over CAT5

UTX-TX500 UTX-RX500

USB HARD DRIVE USB KEYBOARD USB MOUSE USB PRINTER

SPEAKERS

MONITOR

COMPUTER

Introduction

The UTX-500 extends WUXGA, audio and transparent

USB 1.1 up to 300 feet over two CAT5 cables. The

recevier has an integrated 4-port USB hub. With fully

transparent USB the UTX-500 supports any USB devices

including USB keyboards, mice, cameras, ash drives,

hard drives and more.

Connecting the UTX-500

1. Power o all devices.

2. Connect the WUXGA video source (computer) to

the front of the UTX-TX500 (transmitter) using a

male-to-male VGA cable.

3. Connect the USB source (computer) to the USB

port on the front of the UTX-TX500 (transmitter).

4. Connect an audio source (computer) to the audio

port on the front of the UTX-TX500 (transmitter).

5. Connect the UTX-TX500 (transmitter) to the UTX-

RX500 (receiver) using 2 CAT5 cables up to 300

feet in length.

6. Connect a VGA monitor to the front of the UTX-

RX500 (receiver).

7. Connect up to four USB 1.1 devices to the

integrated 4-port USB hub on the front of the

UTX-RX500 (receiver).

8. Connect speakers to the front of the UTX-RX500

(receiver).

9. Connect the power supply to the UTX-RX500 and

the UTX-RX500.

10. Power on the computer, monitor, USB devices and

speakers.

Applications

• Security

• PC Networking

• Conference Center Systems

• Point of Sale

• Camera Surveillance

• Video Phone

• Control Room Systems

• Recording Studio

• PC KVM Extension

• MAC Keyboard Mouse ExtenderPC KVM Extension

• MAC Keyboard Mouse Extender

Features

• Plug and play, no software required

• Supports WUXGA video extension for resolutions

up to 1920 x 1200

• Fully compliant with USB 1.1 specications

• Supports 1.5 and 12 Mbps data rate

• Built-in skew compensation

• Uses a single CAT5 UTP cable

• External power adapter for transmitter and re-

ceiver unit

• Fully transparent to any type of USB 1.1 device

Product - Installation Diagram

UTX-RX500 Front

UTX-RX500 Rear

UTX-TX500 Front

UTX-TX500 Rear
