SMART-AVI VDX Manuel utilisateur

NOTICE

The information contained in this document

is subject to change without notice. SmartAVI

makes no warranty of any kind with regard to

this material, including but not limited to,

implied warranties of merchantability and

fitness for particular purpose.

SmartAVI will not be liable for errors con-

tained herein or for incidental or consequen-

tial damages in connection with the furnish-

ing, performance or use of this material.

No part of this document may be photocop-

ied, reproduced, or translated into another

language without prior written consent from

SmartAVI Technologies, Inc.

800.AVI.2131

Tel: (818) 503-6200 Fax: (818) 503-6208

11651 Vanowen St. North Hollywood, CA 91605

SmartAVI.com

Many industry-leading companies have recognized the innova-

tion and power of SmartAVI’s technologies and have success-

fully implemented them within their systems. Users of Smar-

tAVI technology include:

VDX

Designed and Manufactured in the USA

1080p HD VGA UXGA Video Signal

and Stereo Audio Extender

Quick Start Guide

Enhance VGA distribution and

extension via CAT5 cables at

distances up to 1000 feet

PART NO. QTY DESCRIPTION

VDX-TX-S 1 VGA UXGA/Audio Transmitter

VDX-RX-S 1 VGA UXGA/Audio Receiver

Power 1 5VDC

Quick Start

Guide

1 Parts and set-up guide

VIDEO

Bandwidth 400MHz

Analog Signal Level 1 Volt

Impedance 75 ohms

Connector High Density HD15

Format VGA (XGA/UXGA/RGBHV)

TECHNICAL SPECIFICATIONS

OTHER

Power 5V DC @ 500mA

Weight 0.1 lbs

CONTROL

RS-232 Bi-directional, RXD-TXD

WHAT’S IN THE BOX

System

CAT5 Connector RJ45

The VDX extends high definition video, audio, and

RS-232 control signals via a single CAT5 cable up to

1000 feet away.

FEATURES

 Easy to install

 Affordable CAT5 cable solution

 Supports 1080p HD (1920x1200) resolution

 HDTV compatible

 Extends up to 1000 feet

 Low bandwidth (300 MHz)

 VGA, XGA, Sun, Mac, and SGI signal compliant

 Bidirectional RS-232 control

 Built-in surge protector

 Secure metal case enclosure

RS-232 Control

The VDX extender sends bi-directional RS-232 con-

trol signals through either the transmitter or receiver

units. Here are some simple instructions on how to

et up your RS-232-enhanced extender.

1. Power down all devices.

2. Connect an RS-232 cables between your work-

station and the TX unit.

3. Connect RS-232 cables between end-point de-

vice and RX unit.

4. Connect TX and RX units via CAT5 cable.

5. Power up TX and RX units.

6. Turn on connected devices.

CONNECTING the VDX

1. Power down all connected devices.

2. Connect VGA cable between user workstation and VDX-TX.

3. Connect VGA cable between VDX-RX and output display device.

4. Connect RS-232 cable between workstation and TX.

5. Connect RS-232 cable between RX and output display device.

6. Connect CAT5 cable between TX and RX.

7. Power on TX and RX units.

8. Power on workstation and output display device.

INSTALLATION DIAGRAM
