Skywalker SJG201 Instructions de montage
Jungle GYM Swing Set
Skywalker Holdings LLC
P.O. Box 574, Brigham City, UT 84302
Model SJG200 Traditional Jungle Gym
WARNING
!
Read all precautions and instructi-
ons in this manual before using this
equipment. Save this manual for
future reference.
Maximum occupancy 2 users.
Maximum weight capacity 162 lbs.
Ages 4 to 8
Assembly Installation, Care Maintenance
and User Instructions Manual
SKYWALKER
SPORTS
Model SJG201
CONTENTS
2
REPLACEMENT PARTS or QUESTIONS
If you have questions after reading this manual, please call our toll-free Customer Care Hot
Line. Our trained technicians will provide immediate assistance.
Customer Care Hot Line: 1-866-603-5867
Monday --- Friday, 8:00 am ---- 5 p.m. Mountain Time
WARNING
Read the assembly, installation, care, maintenance, and use instructions in this manual
prior to assembling and using this equipment. Save this manual for future reference.
!
Before you Begin..........................................................................................................................3
Important Precautions...................................................................................................................3
User Instructions...........................................................................................................................5
Jungle Gym Safety Information....................................................................................................6
Using The Jungle Gym Safely......................................................................................................6
Assembly......................................................................................................................................7
Parts List ........................................................................................................................................13
.....................................................................................................8
Pre-assembled part chart
Maintenance information ............................................................................................................16
Limited Warranty .........................................................................................................................17
Exploded Drawing.. .....................................................................................................................15
..................................................................................4
( ID label location)
(Warning label location)
WARNI
!
This product must be anchored. Anchors are sold separately
Playground surfacing materials information
Age Grading: 4-8 years, maximum weight of 81 lbs.
Maximum Occupancy
7 children
SJG200 3 children
SJG201 2 children
SJG202 1 children
SJG203 1 children
The total maximum weight not exceed of 567 lbs.
On-site adult supervision at all times
.
.
3
BEFORE YOU BEGIN
1. It is the responsibility of the owner and supervisors of this Jungle Gym Base Station to
make sure all users obey the safety instructions printed in this material.
2. This product is intended for use by children ages 4 to 8.
3. Use the Jungle Gym Base Station only as described in this manual.
4. Always use the jungle gym under adult supervision.
5. Total Weight capacity is 162 lbs.
6.
7.
8.
9.
Be sure that Jungle Gym Base Station is on a level surface, not less than 6 ft
(1.8m) from any structure or obstruction such as a fence, garage, house, overhanging
branches, laundry lines, or electrical wires.
10.
11.
INSTALLATION
WARNING! To reduce the risk of serious injury, read all important precautions and instructions
in this manual and all warnings on the Jungle Gym Base Station before assembly and use of
this product.
Do not let children use equipment until properly assembled and anchored.
It is recommended that the gym set be placed in concrete, or anchored to the ground. Be
certain that all anchoring devices are placed below the level of the playing surface or
below ground to prevent tripping. Anchors are sold separately.
Always inspect the Jungle Gym Base Station before it is used and replace any worn,
defective, or missing parts. (Users may be hurt if the Jungle Gym Base Station is used
when it is in poor condition.)
It is recommended that the Jungle Gym Base Station be placed on shock absorbing
surface. Shedded bark mulch, wood chips, fine sand or fine gravel are considered to be
acceptable shock absorbing surfaces when installed and maintained at a sufficient depth
under and around Jungle Gym Base Station.
Do not install over concrete, asphalt, packed earth, grass, carpet, or any other hard surface.
A fall onto a hard surface can result in serious injury or death. Jungle gym base should never
be placed on a hard surface such as concrete or asphalt.
Thank you for selecting a Skywalker Sports Jungle Gym. The Jungle Gym will provide many
years of backyard fun. Your Jungle Gym comes equipped with warnings and instructions for
the assembly, care, maintenance, and use. This information must be read by all Jungle Gym
supervisors and communicated to or read by all users before any person is allowed to use the
Jungle Gym.
If you have any questions after reading this manual, please call our toll-free Customer Care
line at 1-866-603-5867, Monday through Friday, 8 a.m until 5 p.m. Mountain Time (excluding
holidays)
4
PLAYGROUND SURFACING MATERIALS
INFORMATION
The following information is from Section 4 of the United States Consumer Product
Safety Comission’s (USCPSC) Outdoor Home Playground Safety Handbook for
playground surfacing material.
X3. SECTION 4 OF THE CONSUMER PRODUCT SAFETY COMMISSION’S OUTDOOR HOME
PLAYGROUND SAFETY HANDBOOK
X3.1Select Protective Surfacing — One of the most important things you can do to reduce the likelihood of serious head
injuries is to install shock-absorbing protective surfacing under and around your play equipment. The protective surfac-
ing should be applied to a depth that is suitable for the equipment height in accordance with ASTM Specification F1292.
There are different types of surfacing to choose from; which ever product you select, follow these guidelines:
X3.1.1Loose Fill Materials:
X3.1.1.1 Maintain a minimum depth of 9 inches of loose-fill materials such as wood mulch/chips, engineered
woodfiber (EWF), or shredded/recycled rubber mulch for equipment up to 8 feet high; and 9 inches of sand or pea
gravel for equipment up to 5 feet high. NOTE: An initial fill level of 12 inches will compress to about a 9-inch depth of
surfacing over time.The surfacing will also compact, displace, and settle, and should be periodically refilled to maintain
at least a 9-inch depth.
X3.1.2Use a minimum of 6 inches of protective surfacing for play equipment less than 4 feet in height. If main-
tained properly, this should be adequate. (At depths less than 6 inches, the protective material is too easily displaced or
compacted.) NOTE: Do not install home playground equipment over concrete, asphalt, or any other hard surface. A fall
onto a hard surface can result in serious injury to the equipment user. Grass and dirt are not considered protective
surfacing because wear and environmental factors can reduce their shock absorbing effectiveness. Carpeting and thin
mats are generally not adequate protective surfacing. Ground level equipment such as a sandbox, activity wall,
playhouse or other equipment that has no elevated play surface does not need any protective surfacing.
X3.1.3 Use containment, such as digging out around the perimeter and/or lining the perimeter with landscape
edging. Don’t forget to account for water drainage.
X3.1.3.1 Check and maintain the depth of the loose-fill surfacing material. To maintain the right amount of
loose-fill materials, mark the correct level on play equipment support posts. That way you can easily see when to
replenish and/or redistribute the surfacing.
X3.1.3.2 Do not install loose fill surfacing over hard surfaces such as concrete or asphalt.
X3.1.4 Poured-In-Place Surfaces or Pre-Manufactured Rubber Tiles — You may be interested in using surfac-
ing other than loose-fill materials like rubber tiles or poured-in-place surfaces.
X3.1.4.1 Installations of these surfaces generally require a professional and are not “do-it-yourself” projects.
X3.1.4.2 Review surface specifications before purchasing this type of surfacing. Ask the installer/manufacturer
for a report showing that the product has been tested to the following safety standard: ASTMF 1292 Standard
Specification for Impact Attenuation of Surfacing Materials within the Use Zone of Playground Equipment. This report
should show the specific height for which the surface is intended to protect against serious head injury. This height
should be equal to or greater than the fall height – vertical distance between a designated play surface (elevated
surface for standing, sitting,or climbing) and the protective surfacing below – of your play equipment.
X3.1.4.3 Check the protective surfacing frequently for wear.
X3.1.5 Placement — Proper placement and maintenance of protective surfacing is essential. Be sure to:
X3.1.5.1 Extend surfacing at least 6 feet from the equipment in all directions.
X3.1.5.2 For to-fro swings, extend protective surfacing in front of and behind the swing to a distance equal to
twice the height of the top bar from which the swing is suspended.
X3.1.5.3 For tire swings, extend surfacing in a circle whose radius is equal to the height of the suspending
chain or rope, plus 6 feet in all directions.
This information has been extracted from the CPSC publications “Playground Surfacing — Technical Information
Guide” and “Handbook for Public Playground Safety.” Copies of these reports can be obtained by sending a postcard to
the: Office of Public Affairs, U.S. Consumer Product Safety Commission, Washington, D.C., 20207 or call the toll-free
hotline: 1-800-638-2772.
5
USER INSTRUCTIONS
1. The Jungle Gym Base Station is designed for up to 2 persons and not to exceed 162 lb.
total weight limit.
2.
3.
Instruct children not to walk close to, in front of, behind, or between moving items.
Instruct children to keep a safe distance away to keep from being struck by items in play.
4.
5.
Instruct children to avoid swinging empty seats. These may strike other children or come
back and strike you.
6.
7.
8.
9.
10.
Observing the following statement and warnings reduces the likelihood of serious or
fatal injury.
Instruct children not to twist swing chains or ropes or loop them over the top support bar
since this may reduce the strength of the chain rope.
Teach children to sit in the center of the swings with their full weight on the seats. DO
NOT allow children to stand on the seats and DO NOT allow children to lean to the side
or collide with other playmates.
Instruct children not to use the equipment in any manner other than intended.
Instruct children not to get off equipment while it is in motion. Do not allow children to
jump from moving play items.
Dress children in appropriate clothing while playing on and around the equipment. Do not
allow the children to wear loose fitting clothing, hood and neck drawstrings, scarves,
cord-connected items, capes, and ponchos. These items can cause death by strangula-
tion.
On-site adult supervision for children of all ages at all times is required.
Make sure that suspended climbing ropes, chain, or cable are secured at both ends and
cannot be looped back on itself.
Do not allow children to play on equipment when it is wet. Injury due to slips or falls may
occur.
Instruct children not to attach items to the playground equipment that are not specifically
designed for use with the equipment, such as, but not limited to, jump ropes, clothesline,
pet leashes, cables and chain as they may cause a strangulation hazard.
11.
12.
13.
Check the openings between rollers and sliding surfaces of rollers slides for materials that
could be potentially hazardous.
14.
15. Instruct children to remove their bike or other sports helmets before playing.
16.
Dress children with well-fitting and full foot enclosing footwear. Don not wear clogs, flip
flops, and sandals.
17. WARNING: Lawn swings are designed for use by children two years of age and older.
The use by children under the age of two can result in entrapment between the seat and
back rest because the child’s body may pass through the opening, causing entrapment of
the child’s head. Such entrapment may result in strangulation. NEVER place children in a
rearward facing positon or with legs between the seat and backrest.
Instruct children to always grasp the Jungle Gym Base Station frame rails while playing.
Instruct children to step on and off of the Jungle Gym Base Station, do not jump.
18.
6
JUNGLE GYM SAFETYINFORMATION
A Jungle Gym is a recreational product.
The information on this manual identify important safety precautions. The precautions are not
all-inclusive, because a Jungle Gym can be used in ways that this manual cannot cover
completely.
USING THE JUNGLE GYM SAFELY
Adult Supervision of Children
Children using the Jungle Gym must be supervised by adults at all times.
Adults may pay particular attention to:
• Entering and exiting the Jungle Gym safely
• Appropriate clothing, No loose-fitting clothing, scarf’s, ponchos or clothing that is potentially
hazardous.
• Do not attach items to the Jungle Gym that are not specifically designed for use with the
equipment, such as but not limited to, jump ropes, clothesline, pet leashes, cables, extension
cords, garden hose and chains as they may cause a strangulation hazard
• Darkness increases the chances of a fall. Do not use the Jungle Gym unless there is plenty
of lighting provided
Electrocution Hazard Associated with the Metal Frame of the
Jungle Gym
The Jungle Gym frames are made of metal. They are not grounded and will conduct
electricity. For this reason, an electrocution hazard exists. No Light, Electric heaters,
extension cords or household electrical appliances are to be permitted in or on the Jungle
Gym at any time.
Placing the Jungle Gym in a Safe Place
To avoid injury, the Jungle Gym must be kept away from objects and possible hazards
including electric power wiring, tree limbs, and fences. Do not place the Jungle Gym near any
other recreational device or structures such as a swimming pool or hot tub.
The Jungle Gym must be placed on a level surface before use. The area around the
Jungle Gym must always have plenty of light.
For the Supervisor
Be familiar with the information in this manual and enforce all of the safety rules. Help new
users and all user to the Jungle Gym. All Jungle Gym users must have someone watch them,
regardless of the skill or age of the user. Keep the Jungle Gym free of any objects that could
interfere with the proper use of the Jungle gym such as but not limited to, jump ropes,
clothesline, pet leashes, cables, extension cords, garden hose and chains as they may cause
a strangulation hazard.
For the Jungle Gym User
Do not use the Jungle Gym when under the influence of drugs or alcohol.
Do not attempt to jump onto or off of the Jungle Gym.
Wear clothing that does not have drawstrings, hooks, loops or anything lese that can get
caught in the Jungle Gym.
PART IDENTIFICATION CHART
7
Before beginning assembly, refer to the drawings below to identify all the parts used in assembly. The
number in parentheses by each drawing is the key number of the part, from the PART LIST on page
13 and 14.
Top Tube
(1) - 1
“U” Frame1 (2) - 1 “U”Frame
2 (3) - 1
Upright 1 (4) -1
Upright 2 (5) -1
Cross Bar (6) -1
Plastic Protector (15) - 2
D50 Inner Cap
(
19 ) - 2
Flying Rings (8) -1
Swing Set (7) - 1
ASSEMBLY
8
PRE-ASSEMBLED PART CHART
Top Tube
assembly (
1,19) - 1
Before beginning assembly, refer to the drawings below to identify all the pre-assembled parts.
Swing Set
assembly (
7,9,10) - 1
Flying Rings
assembly (
8,9,10) - 1
ASSEMBLY
9
Make Things Easier for Yourself!
This manual is designed to ensure that the Jungle GYM Swing Set can be assembled
successfully by anyone. Most people find that by setting aside plenty of time, assembly
will go smoothly.
Before beginning assembly, carefully read the following information and
insruction:
* One people can assembly. Two people is recommended.
* For help indentifying parts, use the PART IDENTIFICATION CHART on page 7, page 8
and PART LIST on page 13.
* Place all parts in a cleared area and remove the packing materials. Do not dispose of
the package materials until assembly is completed.
* Tighten all parts as you assemble them, unless instructed to do otherwise.
1
4
5
6
9
9
14
14
15
15
16
16
17
17
18
18
1. First find the upright 1 (4) and the Upright 2
(5) with marked 4,5.
Attach two plastic Protectors (15) to the
Cross Bar (6) with two M6X40mm Button
Bolts (17), two M6 Washers (16) and two M6
Locknuts (18).
Then fix the upright 1 (4) and the Upright 2
(5) with two M8 Arc Washers (9) and two
M8X35mm Button Bolts (14).
Do not tighten the Bolts.
hole
hole
10
2. First find the “U” Frame 1 (2) with marked 2.
Attach the “U” Frame 1 (2) to the Upright 1
(4) and the Upright 2 (5) with four M8X60
Button Bolts (13), eight M8 Arc Washers (9)
and four M8 LockNuts (10).
Tighten all the Bolts.
4
5
9
9
9
9
9
9
99
10
10
13
13
2
2
2
99
9
10
12
20
3
1
3. Attach the Top Tube (1) to the “U” Frame 1
(2) with the M8X65 Button Bolt (20), the
M8X105mm Button Bolt (12), three M8 Arc
Washers (9) and two M8 LockNuts (10).
(Note: the round hole lies in this side).
Finally press the D50 Inner Cap (19) into
the Top Tube (1).
1
3
9
10
10
4
4. First find the “U” Frame 2 (3) with marked 3.
Attach the Top Tube (1) to the “U” Frame 2
(3) with the M8X65 Button Bolt (20), the
M8X105mm Button Bolt (12), three M8 Arc
Washers (9) and two M8 LockNuts (10).
(Note: the round hole lies in this side).
Finally press the D50 Inner Cap (19) into
the Top Tube (1).
99
12
20
round hole
round hole
19
19
Table des matières
Autres manuels Skywalker Salle de sport à domicile
Manuels Salle de sport à domicile populaires d'autres marques
Horizon Fitness
Horizon Fitness OXFORD 6 Manuel utilisateur
Energetics
Energetics Multi Trainer 5.1 Manuel utilisateur
Matrix
Matrix MG-PL Series Manuel utilisateur
Reebok
Reebok Tbr2i Manuel d'utilisation et d'entretien
Weider
Weider 8300 Hard Drive Manuel utilisateur
Pure Fitness
Pure Fitness 8526HE Manuel utilisateur
