4K 18x Optical Zoom Block Camera

Technical Manual

skoopia 85Z18H

85Z18H

Compliments of Phase 1 Technology

phase1vision.com

4K 18x Zoom Block Camera Technical Manual

Revision History

Version Date Description Remarks

1.00 First Release

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER.

ACCESSORIES SOLD DEPARATELY. CONTACT QUALIFIED SERVICE PERSONNEL FOR

INFORMATION ACCESSIBLE ACCESSORIES.

The lightning arrowhead symbol in a triangle means to watch out for live wires that might

cause an electrical shock.

The exclamation symbol in a triangle indicates an important operational and service

instruction.

WARNING

Please note that the user is liable for any incidents in operating the unit if it is altered or modified without

manufacturer’s approval.

CAUTION

To prevent electric shock and risk of fire hazards:

Do not use power sources except for that specified.

Do not expose this appliance to rain or moisture.

This installation should be made by a qualified service person and should abide to all local

codes.

85Z18H

Compliments of Phase 1 Technology

phase1vision.com

4K 18x Zoom Block Camera Technical Manual

1. SAFETY INSTRUCTIONS

Read Instructions

Read all of the safety and operating instructions before using the product.

Retain Instructions

Save this instructions for later use.

Cleaning

Unplug this appliance form wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.

Use a damp cloth for cleaning.

Water and Moisture.

Do not use this product near water or moisture.(For example. Near a bathtub, wash bowl, kitchen

sink, or laundry tub, in a wet basement, or near swimming pool, etc.)

Installation

Do not place this product on an unstable cart, stand, or table. The product may fall causing serious

injury to a child or adult, and damage to the product. Use only with a cart or stand recommended by

the manufacturer, or sold with the product. Mounting should follow the manufacturer’s instructions,

and should use a mounting accessory recommended by manufacturer.

Power source

This Product should be operated only form the type of power source indicated on marking label.

If you are not sure of the type of power supplied to your home, consult your dealer or local power

company.

2. PRECAUTIONS

Do not use the camera in extreme temperature conditions.

Do not use or store the camera in humid environment

It may cause poor image quality.

Do not use the camera in unstable lighting conditions.

Inconsistent lighting or flickering may cause poor image.

Never use the camera close to gas or oil leak.

It may not operate properly.

Do not disassemble the camera.

There is no user serviceable part inside.

Do not drop the camera or apply force on it.

It may cause a malfunction.

Never face the camera to strong light for long periods of time.

It may damage the CMOS sensor.

Do not expose the camera to rain or any types of liquid

If wet, wipe the moisture out immediately.

Liquids can contain minerals that corrode the electronic components.

When this camera is installed near wireless communication devices that emits strong

electromagnetic field, irregularity such as noise may appear in the image.

85Z18H

Compliments of Phase 1 Technology

phase1vision.com

4K 18x Zoom Block Camera Technical Manual

INDEX

1. SAFETY INSTRUCTIONS.....................................................................................................................3

2. PRECAUTIONS ....................................................................................................................................3

3. FEATURES ...........................................................................................................................................5

4. SPECIFICATION ..................................................................................................................................6

5. OPERATING CAMERA..........................................................................................................................7

5.1. Camera OSD menu......................................................................................................................7

5.2. WHITE BALANCE .........................................................................................................................9

5.3. EXPOSURE ...................................................................................................................................9

5.4. FOCUS .......................................................................................................................................10

5.5. BACK LIGHT ..............................................................................................................................11

5.6. IMAGE CONTROL ......................................................................................................................11

5.7. DISPLAY CONTROL....................................................................................................................11

5.8. SYSTEM SETUP..........................................................................................................................12

5.9. RESET........................................................................................................................................12

6. Video Output.....................................................................................................................................13

6.1. Video Mode................................................................................................................................13

6.2. Output Timing Chart(3840x2160p@30/29.97).........................................................................14

6.3. Output Timing Chart(3840x2160p@25) ...................................................................................15

6.4. Output Timing Chart(3840x2160p@24/ 23.98)........................................................................16

6.5. Output Timing Chart(1920x1080p@30/60/29.97/59.94) .........................................................17

6.6. Output Timing Chart(1920x1080p@25/50)..............................................................................18

6.7. Output Timing Chart(1920x1080p@24/23.98) .........................................................................19

6.8. Output Timing Chart(1920x1080i@60/59.94) ..........................................................................20

6.9. Output Timing Chart(1920x1080i@50).....................................................................................21

6.10. Output Timing Chart(1280x720p@60/59.94).........................................................................22

6.11. Output Timing Chart(1280x720p@50) ...................................................................................23

6.12. Output Timing Chart(1280x720p@30/29.97/24) ...................................................................24

6.13. Output Timing Chart(1280x720p@25) ...................................................................................25

6.14. Video Data Start/Stop Format.................................................................................................26

7. Camera Interface..............................................................................................................................27

7.1. Camera Interface.......................................................................................................................27

7.2. Key Application recommended circuit .......................................................................................28

8. Dimensions .......................................................................................................................................29

9. APPENDIX A......................................................................................................................................30

10. APPENDIX B ............................................................................................................................57

85Z18H

Compliments of Phase 1 Technology

phase1vision.com

4K 18x Zoom Block Camera Technical Manual

3. FEATURES

1/1.8 inch 4K CMOS image sensor (8.41 million effective pixels)

Progressive scan

Video signals output

HDMI : Digital YCbCr 4:2:2 8bits, RGB4:4:4 8bits

QFHD : 3840x2160p@24/ 23.98/ 25/ 29.97/ 30

FHD : 1920x1080p@50/ 59.94/ 60

1920x1080p@24/ 23.98/ 25/ 29.97/ 30

1920x1080i@50/ 59.97/ 60

HD : 1280x720p@24/ 25/ 29.97/ 30/ 50/ 59.97/ 60

18x optical zoom lens with F1.61 aperture(optical zoom + digital zoom = 216x)

Day and Night

ICR for infrared cut filter

Privacy Zone Masking function

Communications protocol supported to be controlled remotely

- SONY-VISCA, PELCO-P/D, etc

High performance functions

-3D-DNR (Digital Noise Reduction)

- BLC (Back Light Compensation)

- Motion Detection

- Defog

- Image flip

- HLC (High Light Compensation)

85Z18H

Compliments of Phase 1 Technology

phase1vision.com

4K 18x Zoom Block Camera Technical Manual

4. SPECIFICATION

SPECIFICATIONS

Sensor

Image Sensor 1/1.8”4K Progressive CMOS (8.41 mega)

Scanning System 16:9 Progressive

Sync. System Internal

Effective Pixel 3840(H) x 2160(V)

Min. Illumination T.B.D

Horizontal Resolution T.B.D

Optics

Lens 18x optical Zoom, F=6.8~120 mm, F1.61(Wide) ~ F4.13(Tele)

Zoom 18x optical zoom + 12x digital zoom = 216x

Focus Near/Far, Auto/Manual/One Push

Angle of View(H) 58.5 degrees (wide end), 3.7 degrees (tele end)

Min. working distance 150mm(wide) 1500mm(tele)

Functions

Back Light Compensation DWDR, BLC, HLC(High Light compensation)

Exposure Auto / Manual

White Balance Auto(3,000°K~8,000°K) / ATW(1,900°K~11,000°K) / Manual

Day & Night System AGC / TDN(ICR)

Electronic Shutter NTSC: 1/30~1/10000, PAL: 1/25~1/10000, DSS( ~ 1/1sec)

Functions Privacy Mask, Image Mirror, 3DNR, Flicker-less, Sharpness, Defog,

NegArt, Freeze

Video

Outputs

Digital Output

(HDMI)

YCbCr422 / RGB444

QFHD : 3840x2160p@24/23.98/25/29.97/30

FHD : 1920x1080p@24/23.98/25/29.97/30/50/59.94/60

1920x1080i@50/59.94/60

HD : 1280x720p@24/25/29.97/30/50/59.94/60

Control

Interface

UART(5V level) PELCO-P/D, SONY-VISCA protocol

8bits data, 1 stop bit, no parity, 2400~115200bps

General

Operation Temperature T.B.D

Power Input 12VDC (7V to 15VDC)

Power consumption Max 5.2W (3.5W Lens inactive, 4.7W Lens active)

Mass Approx. 310g (10.9 oz.)

Dimensions 96.8(D) x 50.0(W) x 60.0(H) mm

85Z18H

Compliments of Phase 1 Technology

phase1vision.com

4K 18x Zoom Block Camera Technical Manual

5. OPERATING CAMERA

5.1. Camera OSD menu

WB CONTROL MODE AWB / ATW / PUSH / INDOOR / OUTDOOR / MANUAL

PUSH

RED 0 ~ 100

BLUE 0 ~ 100

AE CONTROL MODE AUTO/SHUT PRI/IRIS PRI/AGC PRI/BRIGHT/MANUAL

SHUT /30/60/90/100/125/180/250/350/500/725/1000/1500/2K/3K/4K/

6K/10K

IRIS F1.6 ~ F16

AGC 0 dB ~

AGC LIMIT 0 ~ 15

SENS UP OFF ~ X15

EXP COMP 0 ~ 14

FLICKERLESS OFF/ AUTO/ ON

FOCUS CONTROL FOCUS MODE AUTO/ MANUAL

PUSH PRESS OK

AF MODE NORMAL/ INTERVAL/ ZOOM TRIG

WIDE LIMIT X1 ~X29

TELE LIMIT X2 ~X30

DZOOM OFF/ ON

ZOOM SPEED 0 ~ 7

NEAR LIMIT 0.5M/ 1M/ 2M/ 3M/ 5M/ 10M/ 30M

AF INTERVAL 0 ~ 255

BACK LIGHT BACKLIGHT BLC LEVEL 0~255

DISPLAY OFF/ ON

WIDTH 0~48

HEIGHT 0~33

MOVE HOR 0~48

MOVE VER 0~33

HLM AREA DISPLAY OFF/ ON

LEVEL 0~20

BLACK MASK OFF/ ON

WIDTH 0~48

HEIGHT 0~33

MOVE HOR 0~48

MOVE VER 0~33

SPOT AE DISPLAY OFF/ ON

WIDTH 0~48

HEIGHT 0~33

MOVE HOR 0~48

MOVE VER 0~33

DWDR STRENGTH 0 ~ 16

SATURATION 0 ~ 16

85Z18H

Compliments of Phase 1 Technology

phase1vision.com

4K 18x Zoom Block Camera Technical Manual

LOCAL RATIO 0 ~ 16

SAT. SYNC OFF/ ON

AUTO LEVEL LOW/ MID/ HIGH

DEFOG STRENGTH 0 ~ 16

THRESHOLD 0 ~ 3

AUTO LEVEL LOW/ MID/ HIGH

IMAGE CONTROL COLOR LEVEL 0 ~ 20

SHARPNESS 0 ~ 20

CONTRAST 0 ~ 20

HUE -10 ~ 0 ~ 10

IMAGE EFFECT OFF/ NEGA/ GRAY

IMAGE FLIP OFF/MIRROR/V-FLIP/ROTATION

DNR MODE OFF/ 2D/ 3D/ 2D+3D

3DNR LEVEL LOW/MID/HIGH/AUTO

2DNR LEVEL LOW/MID/HIGH/AUTO

APERTURE 0~4

GAMMA DEFAULT/1.0 ~ 0.4

GAMMA OFFSET -64 ~ 64

COLOR SUPPRESS OFF/ LOW/ MID/ HIGH

LENS SHADING OFF/ ON

DISPLAY DAY/NIGHT MODE AUTO/ DAY/ NIGHT

DELAY [SEC] 0 ~ 60

D->N LEVEL 0 ~ 28

N->D LEVEL 0 ~ 27

NIGHT COLOR OFF/ ON

COLOR BURST OFF/ ON

CAM TITLE OFF/ ON

ZOOM MAG OFF/ ON

PRIVACY MODE OFF/ ON

TYPE SQUARE/ POLYGON

MASK NO. MASK1 ~ MASK8

DISPLAY OFF/ ON

COLOR BLK/WHT/GRN/BLE/RED/CYAN/MAG/YEL/GRAY

1~6,MOSAIC

POLY SELECT L-TOP/ R-TOP/ L-BOT/ R-BOT

POSITION HOR 0~255

POSITION VER 0~216

WIDTH 0~120

HEIGHT 0~68

MOTION AREA 1 ~ 4

AREA ACTIVE OFF/ ON

AREA DISPLAY OFF/ ON

SIZE POSITION

SENSITIVITY 0 ~ 40

MOTION VIEW OFF/ ON

85Z18H

Compliments of Phase 1 Technology

phase1vision.com

4K 18x Zoom Block Camera Technical Manual

DEFECT PIXEL OFF/ON/STATI

C/FIXED

IMAGE STABILIZER OFF/ ON

SYSTEM SETUP RS232C CAM ID 1~255

ID DISPLAY OFF/ON

BAUDRATE 2400/4800/9600/19200/38400/115200

SAVE

OUTPUT FORMAT 1080P60/50/30/25/ 1080I60/50 720P/60/50/30/25

VER.

RESET MODE FACTORY / USER

EXIT

5.2. WHITE BALANCE

AWB : Color temperature is automatically adjusted to 3,000°K ~ 8,000°K

ATW : Color temperature is automatically adjusted to 1,900°K ~ 11,000°K

INDOOR : Color temperature is manually adjusted to indoor

OUTDOOR : Color temperature is manually adjusted to outdoor

MANUAL WB : Color Temperature is manually adjustable to adjusting value.

RED and BLUE gain can be changed for better pictures.

PUSH WB : Color Temperature is manually adjustable to adjusting value.

The One Push White Balance mode is a fixed white balance mode that may be automatically

readjusted

only at One Push Trigger, while the camera is directed at a piece of white paper to obtain the

optimum state under current illumination.

One Push White Balance data is lost when the power is turned off. If the power is turned off,

reset One Push White Balance.

5.3. EXPOSURE

MODE :

AUTO –Iris, gain and shutter can be controlled automatically.

MANUAL –Manual control of Iris, gain and shutter.

SHUTTER Priority –Manual control of shutter. Iris and gain can be controlled automatically.

IRIS Priority - Manual control of IRIS. Shutter and gain can be controlled automatically.

BRIGHT –Iris and gain can be controlled by control of brightness

SHUTTER :

85Z18H

Compliments of Phase 1 Technology

phase1vision.com

4K 18x Zoom Block Camera Technical Manual

Auto –Shutter controls exposure automatically when iris is manual.

Manual - Shutter is fixed, and gives the exposure control priority to other resources.

IRIS :

Auto - Iris controls exposure automatically, and shutter is fixed.

Manual - Iris is fixed, and gives the exposure control priority to other resources.

AGC LIMIT: To select maximum automatic gain limit.

Camera raises up gain to selected gain limit when dark conditions.

EXP COMP :

The exposure compensation function adjusts gain and iris, to keep a brightness level.

SENS UP :

Minimum slow shutter limit is down to 1/1 second.

The value means seconds.

Camera make Shutter speed longer to selected shutter limit when dark conditions.

FLICKERLESS :

This function used only for specific country to remove light flickering when light appears to

flutter.

5.4. FOCUS

The camera employs a 18x optical zoom lens combined with a 12x digital zoom function. This

camera allows you to zoom up to 212×.

Optical 18x, f = 6.8 mm to 120 mm (F 1.61 to F 4.13)

Digital Zoom 12x : enlarges of the subject

7 levels of zoom speed

FOCUS MODE :

Auto mode automatically adjusts the focus position.

Manual mode adjusts the focus position by manual and when zoom is changed.

AF MODE :

Normal mode automatically adjusts the focus position.

Interval mode adjusts the focus position at time interval and when zoom is changed.

Zoom trig mode adjusts the focus position when zoom is changed.

ONE PUSH : When One Push AF command is sent, camera becomes Auto Focus mode to adjust

focus position for a while. After it stops, mode becomes that for Manual focus mode.

NEAR LIMIT : Priority for focusing distance. The lens moves to adjust the focus

from the distance.

85Z18H

Compliments of Phase 1 Technology

phase1vision.com

Table des matières

Autres manuels skoopia Appareil photo numérique

skoopia

skoopia 21Z10S Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur

skoopia 85Z18H Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques
