Sitecom WLM-2501 Manuel utilisateur

WLM-2501

Wireless ADSL2+ Modem Router

2

User Manual

ABLE OF

ONTENTS

KEY FEATURES .................................................................................................................... 4

PACKAGE CONTENTS ....................................................................................................... 5

PRODUCT LAYOUT............................................................................................................. 6

SYSTEM REQUIREMENTS............................................................................................... 8

WLM-2501 PLACEMENT ................................................................................................. 8

SETUP LAN, WAN ............................................................................................................... 9

PC NETWORK ADAPTER SETUP................................................................................ 10

BRING UP THE WLM-2501.......................................................................................... 13

INITIAL SETUP WLM-2501 ........................................................................................ 13

CONFIGURATION WIZARD......................................................................................... 19

BASIC SETTINGS.............................................................................................................. 20

ADVANCED SETTINGS................................................................................................... 34

FIREWALL SETTINGS .................................................................................................... 49

TOOLBOX SETTINGS ...................................................................................................... 59

Version: 1.0

Introduction

Congratulations on your purchase of the WLM-2501 Wireless ADSL2+ Mode .

The WLM-2501 is fully co pliant with 802.11n. The ode is also fully

co pliant with 802.11g & 802.11b. The ode s provide the best perfor ance

when used in co bination with 802.11n client adapters.

The WLM-2501 is not only a Mode or Wireless Access Point, but can also be

used to connect wired Ethernet devices.

For data protection and privacy, the WLM-2501 can encode all wireless

trans issions with WEP, WPA or WPA2 encryption. By default, the ode is

secured with a WPA2 (AES) encryption key. (The WPA2-key is printed on the

label underneath the ode .)

With a built-in DHCP Server & powerful SPI firewall the WLM-2501 protects your

co puters against intruders and known Internet attacks, and also provides safe

VPN pass-through.

1Key Features

Features Advantages

IEEE 02.11g compliant Fully Interoperable with IEEE 802.11b /

IEEE802.11g co pliant devices

Based on 02.11n technology WLM-1500: Up to 3 ti es faster than

regular 802.11g.

WLM-2501/2500/3500: Up to 6 ti es

faster than regular 802.11g

(in co bination with a 150n or 802.11n

wireless adapter)

Four 10/100 Mbps Fast

Ethernet Port (Auto-

Crossover)

To connect four wired PC's as well.

Firewall supports Virtual

Server

Mapping, DMZ, IP Filter, ICMP

Blocking, SPI

Avoids the attacks of Hackers or Viruses

fro Internet

Supports 02.11i

(WPA/WPA2, AES), VPN pass-

through

Provide utual authentication (Client

and dyna ic encryption keys to

enhance security)

Integrated modem (Annex A) Fully co patible with the fastest

ADSL2+ connections up-to-date.

2Package Contents

Open the package carefully, and ake sure that none of the ite s listed

below are issing. Do not discard the packing aterials, in case of return;

the unit ust be shipped back in its original package.

1. WLM-2501 ode /router

2. 220V ~ 240V Power Adapter

3. Quick Install Guide

4. CD (User’s Manual)

5. Warranty card

6. UTP cable

7. RJ11 cable

3Product Layout

Port Description

ADSL Connect your telephone/ADSL cable this port

LAN Connect the cable fro your PC or network device to

this ports.

Power connector

Connect your power adapter to this port.

Power button Turn the ode On or Off.

Power connector

LAN / computer connections

Modem connection

WPS/Reset button

Power button

Back label

The back label describes the corresponding LED indications and port functionality.

LED Description

Power Lights up when powered ON. Blinks on TEST/RESET

ADSL Lights up when an ADSL cable is connected.

Internet Lights up when internet connection is UP.

WLAN Lights up in Blue when WLAN is enabled. Blinks on traffic

OPS Blinks when OPS ode is on

LAN1~4 When a LAN cable is connected the corresponding light lights up.

4System Requirements

To begin using the WLM-2501, ake sure you eet the following as ini u

require ents:

•PC/Notebook.

•1 Free Ethernet port.

•Wi-Fi card/USB dongle (802.11 b/g/n) – optional.

•Annex A, ADSL internet connection.

•PC with a Web-Browser (Internet Explorer, Safari, Firefox, Opera)

•

Ethernet co patible CAT5 cables.

5WLM 2501 Placement

You can place the WLM-2501 on a desk or other flat surface, or you can

ount it on a wall. For opti al perfor ance, place your Wireless Broadband

Mode /Router in the center of your office (or your ho e) in a location that is

away fro any potential source of interference, such as a etal wall or

icrowave oven. This location ust be close to a power connection and the

ADSL/phone line should not be over 2 eters long.

6Setup LAN, WAN

Modem connection

LAN / computer connections

7PC Network Adapter setup

Windows XP

•Go to [Start Menu],  [Control panel],  [Network Connections].

•Right- ouse-click on the [Local Area Connection]) icon, and select

[properties]

•Select [Internet Protocol (TCP/IP)] =>Click [Properties].

•Select the [General] tab.

The WLM-2501 supports DHCP. Please select both [Obtain an IP a ress

automatically] and [Obtain DNS server a ress automatically].
