6
“SP00”:built-in speed adjustable SP00-SP15
”Pr00”; Built-in program mode,Pr00-Pr15
”FA00”: gradual change model(FA00-FA15 speed are the quickest)
”FL00”: strobe model(FL00-FL15 speed are the quickest)
operation
Press Menu key each time will switch a kind of model. UP/Down can change the content
of this model, the parameter would be saved automatically, which means you will enter the
process saved previously when you start the light next time.
Pr00:red; Pr01:green Pr02:blue
Pr03:red+green Pr04:red+blue Pr05:green+blue
Pr06:red+green+blue Pr07:program 1 Pr08:program 2
Pr09: program 3 Pr10: program 4 Pr11: program 5
Pr12: program 6 Pr13: program 7 Pr14: program 8
Pr15: Comprehensive program 1-8;
Note:Pr7--- Pr15 Can change the content Of SP,SP0-SP15.
8.Operating Control Instruction
Master/Slave
Master:The master should always work as a master as long as it is not set in a DMX
mode whatever other modes it is. And it send out the signal so that the slave synchronous
with it. To avoid the host signal and DMX512 signals interfere with each other, should cut off
the DMX512 signals. The signal lines are longer than 60 meters(20 lamps) ,should increase
a signal amplifier.
Slave:he Slave must be set in DMX mode and the address code should be A001, to
assure receive the master’s signals correctly. Only one light can be set as a Master and
others are slaves.
Note: This product uses input and output power cord 0.75 m ㎡copper core wire,
