Sirona XIOS Manuel utilisateur

Sirona Dental Systems, LLC Charlotte, NC 28273 4835 Sirona Drive Suite 100

Tel: 1 800 659 5977 ext 2 Fax: (704) 587 9394

`

[email protected]

January 2008

Quick Reference Guide for XIOS Intraoral Sensor

System

Please follow these guidelines to avoid possible errors or problems

during the installation of the XIOS software and hardware.

NEVER PLUG IN ANY HARDWARE BEFORE INSTALLING

SOFTWARE

1. Installing Sidexis Imaging Software Version 2.2 or higher

XIOS Intraoral Sensors only run with Sidexis Software Version 2.2 or higher. If older versions of

Sidexis Imaging Software are installed in the practice, Sidexis Software needs to be updated to

Version 2.2 or higher before installing the XIOS Intraoral Sensor System.

1.1 Install Sidexis Imaging Software 2.2 (or higher versions)

2. Installing XIOS Software (USB Driver)

NEVER plug in any hardware before installing the XIOS software.

2.1 Use the XIOS Software CD 2.23 to install the XIOS USB driver. CD should autorun, if not

double-click on the autorun.bat file to start CD and follow the instructions.

2.2 The autorun CD will automatically install all applicable patches.

3. Install XIOS sensor calibration file

3.1 Insert CD supplied with each Sensor. CD will autorun, if not double-click the autorun file to

start.

Pop-up will show up VERY shortly on the bottom right: “Sensor calibration successful”

Note:In case the Sensor Calibration CD is lost and the calibration files are needed they can be

downloaded through SIDEXIS Manager\XIOS Sensor download: Enter SN – select download

location.

4. Connecting XIOS USB module

4.1 ONLY use USB ports on the back of the PC, not the front port. The ports on the back of the PC

are directly soldered to the board, while the front one use internal cables which might introduce

problems

4.2 Disable power saving for USB ports:

Under System Properties\Hardware\Device Manager\USB Root Hubs – make sure to uncheck

all boxes under Power Management. All hubs need to be unchecked separately.

Sirona Dental Systems, LLC Charlotte, NC 28273 4835 Sirona Drive Suite 100

Tel: 1 800 659 5977 ext 2 Fax: (704) 587 9394

4.3 Connect XIOS USB module to computer only AFTER successful installation of the XIOS

software.

Pop-up will show up VERY shortly on the bottom right: “Hardware detected, Hardware

installed”

•

DON’T use external, un-powered USB hubs. If you have more then 2 hubs next to each other use

only one of the hubs and leave the one next (long side of connector) to the XIOS USB open.

•

DON’T use USB extension cables. If you can’t avoid it under any circumstances use ONLY the

following IO-Gear Booster cable brands: GEU216 (preferred) or G2LUB16 (less preferred - USB

1.1 only).

NEVER use the “Add Hardware wizard”

If the “Add Hardware wizard” pops up Cancel and stop “Add Hardware

wizard”

•

Unplug XIOS USB module; Reboot Computer

•

Install XIOS Software according to the instructions in this guide
