Siqura FD2002M1-EI Manuel utilisateur

Unpack

Reset & Micro SD

Installation Notices Connectors

Accessing the camera - DHCP Server

Adjust to Good View

FD2002M1-EI

2MP Fixed Dome Camera

Quick Start Guide

Find additional manuals, the datasheet,

the EU Declaration of Conformity, and

the latest firmware for this product at:

Siqura.com/downloads/software

Quick Start Guide

Note 1: Subject to modification. Actual product and accessories may differ in appearance.

Vision 1.1 (28052020)

FD2002M1-EI QSG

Security Torx

NOTE:

IT IS NOT RECOMMENDED TO CONTINUOUSLY (24/7) RECORD WITH THE MICRO

SD CARD, AS THE CAMERA MAY NOT SUPPORT LONG-TERM CONTINOUS DATA

READ/WRITE. CONTACT THE MANUFACTURER OF THE MICRO SD CARD FOR

INFORMATION REGARDING THE RELIABILITY AND THE LIFE EXPECTANCY.

Screws(4x) & Plastic

Screw Anchors (4x)

CAUTION:

INSTALLATION SHALL BE PERFORMED BY QUALIFIED PERSONNEL ONLY.

INSTALLATION SHALL BE IN ACCCORDANCE WITH LOCAL PROCEDURES.

INSTALLATION WITH POE SHALL BE IN UNEXPOSED NETWORKS.

BATTERY REPLACEMENT SHALL NOT BE APPLIED IN VIEW OF THE RISK OF

EXPLOSION.

IF YOU USE AN EXTERNAL POWER SUPPLY, CONTACT SIQURA TO MAKE SURE

THAT THE POWER SUPPLY HAS THE PROPER POWER SPECIFICATIONS.

MAKE SURE THAT THE POWER SUPPLY COMPLIES WITH LPS REQUIREMENTS.

WHEN INSTALLING THE CAMERA, HOOK UP THE CAMERA WITH THE ANTI-DROP

CHAIN OF THE PENDANT TO THE ANTI-DROP RING (SEE FIGURE 1). FOR MORE

INFORATION, CONTACT SIQURA.

IP = 10.x.y.z

Network Switch

DHCP Server

IP = 10.x.y.z

Camera Unit

DHCP

Mounting Plate

Figure 2 Reset button & Micro SD

Note 2: Press and hold the reset button for 10 seconds to power on or reboot. It will restore

the factory default setting including IP address, user name and password.

Alarm I/O Audio I/O RJ-45

802.3af PoE

12 Vdc

Duster

CAT-6 RJ45 conduit

Pin Pusher

Accessing the camera –Fixed IP address Auto detect with SDM2 1st time camera login

Browser-based Viewer

IP = 192.168.0.x

Network Switch

DHCP

Siqura.com/downloads/software

SDM2-vx.xx-setup.zip

IP = 192.168.0.x

qwer1234

x6W@oM0a!9#F

Set a strong password

30s

DHCP
