Operation Manual

Card Printer

CHC-C320-5

Handling of this Manual

Handling of this ManualHandling of this Manual

Handling of this Manual

may be reproduced or copied in any form or by any means, including translation, without

the written permission of SIN ONIA TECHNOLOGY Co., Ltd.

2. The specifications in this operation manual are subject to change without prior notice.

3. In case of having any difficulties or finding the fault in this manual, your information to

SIN ONIA TECHNOLOGY will be highly appreciated.

Introduction

ntroductionntroduction

ntroduction

This manual describes detailed instructions for handling of and basic operation of Card

Printer CHC-C320-5.

We will describe this product as “the printer” in the manual.

Read this manual thoroughly to understand how to install and operate the printer before

using it.

●

Keep this manual near the printer and operators can refer to

this manual periodically.

●

In case, lost or damaged this manual, contact your dealers.

●

In the case of transfer, do not forget to put this manual

together with the printer.

Notice

CONTENTS

PRE ACE

Chapter 1.

Chapter 1.Chapter 1.

Chapter 1.

Important Safety Instruction

Important Safety InstructionImportant Safety Instruction

Important Safety Instruction

・・・・・・・・・・・・・・・・・・・・・・・ 1-1

Environments

・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 1-1

Handling Instruction

・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 1-2

Handling Instruction for Consumable and Printed Output

・・・・・・・・・・・・・・・・ 1-3

Chapter 2

Chapter 2Chapter 2

Chapter 2.

Installing and Set Up

Installing and Set UpInstalling and Set Up

Installing and Set Up

・・・・・・・・・・・・・・・・・・・・・・・・・・・ 2-1

Unpacking and Checking the Accessories

・・・・・・・・・・・・・・・・・・・・・・・・ 2-1

Parts Name and unction

・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 2-2

Printer Status Lamps Name and Printer Status

・・・・・・・・・・・・・・・・・・・・・ 2-3

Connecting Power Cable

・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 2-4

Connecting USB Cable

・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 2-4

Installing Clean Roller

・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 2-5

Setting Color Ink Ribbon

・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 2-6

Setting Hologram Ribbon

・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 2-7

Setting the Card

・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 2-8

Transporting the Printer

・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 2-10

How to print

・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 2-10

Chapter

Chapter Chapter

Chapter 3

Routine Maintenance

Routine MaintenanceRoutine Maintenance

Routine Maintenance

・・・・・・・・・・・・・・・・・・・・・・・・・・・ 3-1

Cleaning of Thermal Head, Platen Roller, Cleaning Roller

・・・・・・・・・・・・・・・・ 3-1

Cleaning of Outer Cover

・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 3-3

Cleaning of ilter

・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 3-3

Chapter

Chapter Chapter

Chapter 4

Error Handling

Error HandlingError Handling

Error Handling

・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 4-1

Printer Status Lamps are displayed in red

・・・・・・・・・・・・・・・・・・・・・・・・ 4-1

ailure Symptoms

・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 4-2

Paper Jam

・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 4-3

Power Supply Interrupted during Printing

・・・・・・・・・・・・・・・・・・・・・・・・ 4-7

When Ribbon is snapped

・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 4-7

Chapter

Chapter Chapter

Chapter 5

In order

In order In order

In order to more comfortably use

to more comfortably use to more comfortably use

to more comfortably use

・・・・・・・・・・・・・・・・・・・・・・ 5-1

or longer Printer usage

・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 5-1

After

AfterAfter

After-

-Sales Service

Sales Service Sales Service

Sales Service

・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 5-1

Chapter 1. Important Safety Instruction

1-1

This manual provides detailed instructions for

the safety use of the printer.

Read this manual carefully before operating

the printer to ensure to have proper use.

◆

In this manual, there are notes that require

special attention.

◆

or your safety operation, Safety notices are

separated as follows;

◆

It is difficult to forecast all the danger when

customers are setting or using the printer.

Therefore, warnings in this Operation

Manual, in the other documents on the

printer cannot cover all the cases.

In case of performing the operation or

maintenance which are not described in this

manual, all the concern for the safety have to

be taken care of at the customer side.

◆

Operations and the notification for the

maintenance described in this manual and

other documents are for the proper use of the

printer.

◆

In case of use the printer in propose which is

not described in this manual, all the concern

for the safety have to be take care of at the

customer side.

◆

Do not perform the operation which are

prohibited in this manual and other

documents.

◆

The contents that cannot be printed due to

a failure while using the use of this printer

are not guaranteed.

Environments

To use the printer safety, please pay attention

to the followings:

Attention:

Indicates

the cause of the

trouble and the environmental

condition.

Caution: Inappropriate handling

may cause minor injury and/or

damage to property.

Warning: Inappropriate handling

may cause serious injury or death.

Caution:

Do not let children to

touch the printer or the cables.

It may cause accidents or electric

shock.

Attention:

Do not place the printer under

the low temperature such as ski resort,

skating rink or open-air with direct

sunlight.

Warning:

Do not block the

openings of the printer. In case,

the opening blocked, the heat will

remain inside and it may cause

fire.

Caution:

Do not place the printer

on rickety place and/or inclined

place.

Printer may fall down or tumble

and it may cause injury.

aution:

Do not place the printer

under humid or dusty place.

It may cause fire, electric shock

or printer problem.

Do not place the printer with

dust, sand and high humidity

such as bathing place, bathroom,

hot spring or on the street.

Warning:

Do not put vase,

flowerpot, or a cup with water

inside or on the metric items.

In case the water spilt or metric

items fall into the printer, it may

cause the fire

electric shock.

Warning: Do not insert or fall

metallic items or flammable

items into the printer through

the openings of the printer, it

may cause fire or electric shock.

Chapter 1. Important Safety Instruction

1-2

Attention:

appropriate interface cable

and power cable will be required to use

this printer.

Warning:

Secure the power

cable firmly.

Warning:

The thermal head

reaches high temperature during

operation but this is normal. Do

not touch the thermal head.

Warning:

Do not attempt to

service for the printer beyond the

instruction specified in this

document. In case it is

impossible to recover the problem,

please contact to the dealers or

service center.

Warning: Only specified power

cable should be used, and please

make sure that it is connected

properly before turn the printer

power on. If do not operate

correctly, it may cause fire or

electric shock.

Also, there is a possibility to occur

radio or television

signal-receiving interference.

In the case you cannot connect

properly, please contact to the

dealers or services center.

Warning:

Never

disassemble or

modify the printer.

Some sections of the printer

contain a high voltage or become

very hot. Ignoring this warning

may cause electric shock, fire or

burns.

Warning

The card will be

released from the discharge port at

a high speed. Do not look into the

outlet while in use. It may cause

blindness or injury.

Warning

the fan motor

ailure

it may cause fire. or replace it

please contact to the dealers or

service center.

Handling Instruction

In handling the printer, please pay attention to

the followings;

Warning:

Lift the printer from

its box and put it onto a flat table

or desk.

Warning:

Be careful when you

transport the printer on the

slippery floor.

Warning:

In case you drop the

printer, firstly turn off the power

of the printer and remove the

power cable, then contact the

dealers or service center. If use

the printer without any checking,

may

cause

fire or electric shock

Warning:

he printer is too

heavy to be lifted by one person.

(Nearly 23 Kg)

Please take a good care of your

hands and fingers when lifting

the printer from the box.

Attention:

Touching the surface of the

thermal head directly may cause damage

to thermal head. When hard object get

into the printer, it may cause damage to

the printer mechanism. In such case,

please stop to use the printer.

Chapter 1. Important Safety Instruction

1-3

Attention:

Card

Handling

・ Use the card specified by SIN ONIA

TECHNOLOGY.

・ Store the card in a dry and dark place

to avoid the direct Sunlight.

(Temperature less than 30°C,

humidity less than 60%).

・ Do not touch the card surface before

printing to avoid the fingerprints.

・

Do not leave the card on the floor or in

place which might have a foreign

matter. Something such as dust or

water drops might attach to the card.

Attention:

Ink Ribbon Handling

・ Use the ink ribbon specified by

SIN ONIA TECHNOLOGY.

・ Store the ink ribbon in cool place to

avoid the direct Sunlight.

(Temperature less than 30°C,

humidity less than 60%).

・

Do not leave the ink ribbon on the

floor or in a dusty place. It might

cause foreign matter adhesion.

Attention:

Printed Output Handling

・Store the printed output in a dark place

to avoid the direct sunlight.

・Store the printed output away from the

organic fluid such as benzene, thinner

and alcohol which may change or

deteriorate the colors.

Caution:

When abandon the ink

ribbon, please handle it as

harmful industrial waste.

Caution:

Be careful not to injure

your hands with the card edge

when handling card.

Handling Instruction for Consumable and

Printed Output

In handling the ink ribbon, card and printed

output, please pay attention to the followings;

Chapter 2. Installing and Set Up

2-1

This chapter explains the unpacking and set up of the printer.

Before proceeding to this chapter, please make sure to read Chapter 1. Important Safety

Instruction.

Unpacking and Checking the Accessories

1. Open the box and remove the box containing the accessories and protection materials.

2. Take out the printer by holding front and back of

the printer.

Accessory details

Ribb on Cassett e

（ Co lor）

Ribb on Cassett e

（ SP）

Dust Box Cleaning Roller

Attention:

Keep the packaging materials.

The

box and protection materials are

necessary when moving or

transporting the printer. Make sure

that they are retained.

Caution: This printer weighs about

Kg.

Please handle it carefully.

When the printer is taken out of

packing box or when you want to carry

it, please hold the handle parts in

front and back of the printer.

Transportation and installation must

be done by two or more personnel.

Printer

Cushioning material

Chapter 2. Installing and Set Up

2-2

Parts Name and unction

(

ront View

) (

Rear View

)

(

Upper View

)

№

Name

unction

①

rinter Status

Indicator Printer status display lamps are located on the panel.

②

Upper Unit

Open when replacing the ink ribbon or when performing maintenance.

③

Card set unit

Open when set the card, or when performing maintenance.

④

Card set unit

open button

Push this button to open the card set unit.

⑤

Power Switch

This switch turns on/off the power of the printer. When press the “|”

marked side of the switch, the power turn on.

When press the “○” marked side of the switch, the power turn off.

<Caution>Once the printer is turned off, wait at least 3 seconds before

turning it on again.

⑥

Power Connector

To be used to connect the power cable.

⑦

USB Connector

To be used to connect the USB cable.

⑧

Upper Unit

Open Lever

Hold this lever to open the open guide unit,

①

②

③

④ ⑤ ⑥

⑦

⑧

Chapter 2. Installing and Set Up

2-3

Printer Status Lamps Name and Printer Status

LED Display

Description

POWER MEDIA ERROR

○ ○ ○

The power of printer is off.

＊ ○ ○

The printer is processing.

● ○ ○

The printer is ready to make prints.

● ○ ＊

The card set unit or upper unit are opened.

● ○ ●

Card jammed in printer.

Mechanical part is faulty.

Trouble of printer control board.

● ＊ ●

The ink ribbon loaded is not supported.

● ● ●

Card is not set.

Out of card.

The ink ribbon is not loaded.

The ink ribbon is empty.

● ＊ ○

The printer is initializing for the ink ribbon.

Printer status lamp display

●

:on,

○

:off, ＊:flashing

2-4

Connecting Power Cable

Insert the power cable into the power connector

located on the rear of the printer.

Connecting USB Cable

Connect the USB cable from computer to the

USB connector located on the left rear side of

the printer.

Fully insert the USB cable.

Warning:

Make sure to turn

off the power of the printer

before inserting the power cable.

Warning:

Make sure to insert

the power cable correctly. If not, it

may cause fire or the printer

problem.

Warning:

Do not insert or

remove the power cable with wet

hands. It may cause electric

shock

Warning:

Do not make any

damage or any modification to

the power cable. Never put

heavy items on the power cable,

give a strong pull to the power

cable or twist the power cable.

It may cause fire or electric

shock.

Warning:

When it is

not u

sing

the printer, disconnect the power

cable

for safety.

Warning:

Do not use extension

cord. It may cause fire or

electric shock.

Warning:

When moving the

printer, make sure to turn off the

power of the printer, remove the

power cable in order to have no

connection with other devices.

Otherwise, the power cable might

be damaged and it can cause the

fire and electric shock.

Also there is a possibility to fall

dow

n caught by the

cable

Attention:

ake sure that the pr

inter is

in the waiting status before remove the

USB cable. It would not be able to print

correctly in the case the USB cable be

removed during data transfer.

Table des matières

Autres manuels Sinfonia Technology Imprimante

Sinfonia Technology

Sinfonia Technology CHC-S2245 Guide d'installation

Sinfonia Technology

Sinfonia Technology CHC-S6145 Manuel utilisateur

Sinfonia Technology

Sinfonia Technology CHC-C320 Manuel utilisateur

Sinfonia Technology

Sinfonia Technology Color Stream S3 CHC-S2245-5 Manuel utilisateur

Sinfonia Technology

Sinfonia Technology DP-1045 Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur
