Simrad FS70 - Manuel utilisateur
FS70 Sensor
PI Sensor
LCD Monitor
Simrad
FS Trawl sonar
system
www.SIMRAD.com
MAXIMIZING YOUR PERFORMANCE AT SEA
The new trawl sonar platform combines
the best of two worlds
SIMRAD
FS
SYSTEM
The perfect back up
By installing a PI cabinet and
hydrophone, you have a complete
back up system for catch indi-
cators and other sensors.
It is now possible to get trawl
height, door spread, catch and
depth information from the wire-
less sensors by implementing
the receiver from the wireless
PI system into the third wire
FS system. In addition all the
data from the wireless sensors
can be received wireless by the
vessel making it the ultimate
back up system if the third
wire breaks.
The new Simrad FS Trawl system provide the full
picture by utilizing the ultimate FS third wire system
with PI sensors integration. This sophisticated solution
enables the fisherman to have full control of any
type of fishery.
The system provide real-time images from the trawl
sonar head and the data from the PI sensors to the
bridge, thus maximizing the quality of the catch and
increasing effeciency at sea.
A major benefit of the third wire
integrated with PI sensors is to
prevent loss of communication
with the trawl as the vessel is
changing course or in heavy
sea conditions.
Simrad PI sensor family with 6”, 10” and 15” bridge unit.
New flexible Trawl Sonar System
The Simrad FS70 full screen presentation in a polar-
sounder mode indicates the position of the trawl
close to the bottom and the opening of the net
by displaying the Cursor 1 and 2.
In addition, the sounder display provides an accurate
depth of the bottom and the foot rope. The operator
can monitor up to 4 catch indicators, indicating the
amount of fish being caught by the trawl and the time
when the sensors where activated.
The Simrad FS70 200kHz Echosounder provides
a real time picture of the trawl opening and position
relative to the bottom. In addition to the high resolution
sounder, the operator can control the decent of the
trawl during the set by monitoring the position of
the foot rope and the bottom.
Simrad FS70 sounder display mode.
Simrad FS70 full screen display mode.
FS70 Trawl unit
The FS70 trawl housing unit is designed for
the harshest environments and for withstanding
the extreme forces encountered when shooting
a trawl. However, it is easy to handle and the
now infamous Simrad yellow colour makes it
easy to see even in the dark.
The Catch sensor provides information
about the filling rate of fish in the cod
end.
PI Catch sensor
Catch sensor 2 is active and has been
triggered for 60 minutes during the last
tow. Catch sensor 1 is not active, but
has been active for 10 minutes.
FS70 TRAWL SENSOR/VERTICAL SOUNDER
PI DEPTH SENSOR (back up)
PI CATCH SENSORS
PI BOTTOM CONTACT OR RIP SENSORS
FS THIRD WIRE TELEMETRY LINK
PI HYDROPHONES (acoustic link)
PI SPREAD SENSORS
Processing unit
Industrial HP/PC unit
Operating system: MS Window XP
Sonar operating system: Simrad “Winson”
40GB hard drive
RS232 serial port
Dual graphic monitor output
Sound card
Network LAN port
USB port
Power input: 115/240VAC, 50/60Hz +/- 10% (5AMP)
Dimensions: L. 40cm, W. 33cm, H. 10cm
(15.75” x 13” x 4”)
Trawl sonar head
Head type: Vertical/Sounder
Vertical transducer frequency: 120kHz or 330kHz
Beam width: 120kHz: 5ox 40o
330kHz: 1.9ox 20o
Sounder transducer 200kHz: 10ox 20o
Depth rating: 2000 meters
Sensors: Temperature, Depth and Catch
Transmit power: Selectable, 1KW maximum
Transmit pulse length: Selectable
TVG setting: Selectable, 20, 30, 40 and user log
Input/output data: NMEA format
Power/TTM Interface unit
Power input: 115/240VAC, 50/60Hz +/- 10% (5AMP)
Power output: Selectable 89Vdc to 200Vdc @ 1A maximum
Dimentions: L. 43cm, W. 41cm, H. 21cm
(17” x 16” x 6.25”)
FS Trawl unit
Deployment package
Material: Polyurethane with S.S fasteners
Dimensions: L. 79cm x W. 43cm x H. 27cm
(31” x 17” x 10.5”)
Weight: 28 kg. (Complete FS70 system in air)
Option and upgrade
• PI Catch Sensor: No 1, 2, 3 and 4
Catch Sensor frequency: 40kHz or 70kHz
Depth rating: 2000 meters
Option available for 40k z acoustic link only
Communication channel: Selectable and programmable
• Pitch and roll indicators +/- 30o
• PI Spread Sensors
• PI RIP Sensor
• PI Bottom Contact Sensor
• Depth Sensor
• Second control station
Note: Specifications subject to change without notice.
SIMRAD MARKETING - 3.000 10.05
www.SIMRAD.com
MAXIMIZING YOUR PERFORMANCE AT SEA
FS70 Trawl unit FS70 ead
Specifications
FS70 Trawl unit
790 mm ( 31” )
Depth: 270 mm ( 10.5” )
430 mm ( 17” )
FS70 Expanded Configuration
DGPS
NMEA
IN/OUT
HP/PC
PROCESSING
UNIT
KEYBOARD
REMOTE
KEY PAD PWR/TTM UNIT
THIRD WIRE
FS70 TRAWL UNIT
OPTIONAL
REMOTE
PROCESSING
UNIT
PC
MOUSE
LCD MONITOR 2ND MONITOR OPTIONAL 2ND STATION
23” Monitor
19” Monitor
17” Monitor
Weight: 10 kg
Weight: 28 kg Weight: 11.3 kg Weight: 18.2 kg
380 mm (15”)
77 mm (3.1”)
490 mm (19”)
500 mm (20”)
615 mm (24.1”)
400 mm (15.6”)
77 mm (3.1”)
77 mm (3.1”)
490 mm (19”)
