SimPure MS6 Manuel utilisateur
MS6 Air Puri�ier
Please retain owner's manual for future reference
Getting Started
Installation Guide
Operation Guide
Overview
Introduction
System features
SimPure® contact details
Health & Safety
Warnings & Cautions
Operating Guidelines
System Contents
Start-up
Connecting to power
Operating Guide
Mode Selection
Filter Replacement
Troubleshooting Guide
Warranty
1
Introduction
Getting Started
Website: www.simpurelife.com
Toll-Free Phone: 1-866-528-4572
Thank you for purchasing the SimPure®MS6 Air
Puri�ier, which delivers clean and healthy air for you
and your car/home or of�ice. Please contact us for
the latest product information, including operator
manuals, videos, support materials, and where to
purchase replacement �ilter.
The MS6 is a durable piece of
equipment, with proper care it will
last for many years. This owner's
handbook outlines the installation,
operation, and maintenance
requirements to sustain perfect
product performance.
The MS6 can �ilter out impurities and particles in the
air, such as viruses, mold, dust, allergens, pollen,
bacteria, dust mites, cigarette smoke, pet dander,
odors, and unhealthy vapors.
2
SimPure® products are designed with safety in mind.
However, personnel using this device must be familiar
with any potential dangers. All safety information
detailed in this handbook should be reviewed before
installing and operating this air puri�ier.
Warnings and Cautions are provided; Failing
to observe these instructions could damage
the equipment, associated parts,
surroundings, or personal injury.
This product is not a toy; children must be
supervised when using the device. Keep packing
materials out of children's reach.
Do not use the device in a place with heavy
moisture or smoke. Please keep the device away
from �lammable gas appliances such as heaters
or �ireplaces.
Unplug the unit when cleaning, do not use strong
corrosive detergents of chemicals as they may
damage the device's surface.
Do not obstruct the air inlets or outlets on the
device. Do Not wash or reuse the composite
�ilters– Replace with a new �ilter only.
3
Health & Safety
The following table lists the operating parameters
for this product. Operating this product outside
these speci�ications may cause system performance
issues and may even lead to personal injury and void
any warranty. Please contact SimPure® for further
advice and support.
4
Operating Guidelines
Operating Parameters
Model SimPure®MS6
DC 5 V (USB Power)
0.82 lb (370g)
A single composite �ilter
3 W
(2.7 x 2.7 x 7.4) inches
(68 x 68 x 188) mm
Rated Voltage
Rated Power
Dimensions
Operational weight
Filter Element type
Overview
Your SimPure® MS6 Air Puri�ier was carefully
assembled, packaged, and shipped complete with all
the parts you should require.
Unsure about something? Is there a problem?
Please contact SimPure® via our service email
or toll-free number.
5
Operating Guidelines
Power button
Body
Composite �ilter
Base
Website: www.simpurelife.com
Toll-Free Phone: 1-866-528-4572
Before using the air puri�ier for the
the �irst time, remove any packaging
material from the product.
Plug the power output of the USB cord
into the air puri�ier. Plug the USB
connector into a USB port such as the
car adaptor/ computer or USB power
bank. The power button will illuminate
and beep when power is available. The
air puri�ier starts in auto-mode. The fan
speed will change based on air quality.
6
Startup the System
Step 1
Step 2
Excellent Low fan speed
Middle fan speed
High fan speed
General
Poor
Color of
the light Air quality Fan speed
Control Panel
Operating Mode
Operating Guide
When the power is �irst connected to the air puri�ier,
the power indicator light will indicate the air puri�ier
is in auto-mode.
The air puri�ier is equipped with TVOC sensors to
detect air quality. When the air puri�ier is in auto mode,
the fan speed will adjust automatically according to the
air quality.
Once you press the power button, the air puri�ier will
switch to manual mode. If you want to return to
auto-mode again, you will need to turn off the unit or
remove the power cord to restart the unit.
7
Power button
Air quality indication
Power Button
Filter Timer
Filter Reset
When the �ilter lifespan reaches 100%, you need to
replace the �ilter. (see page 9). After the �ilter is replaced,
press and hold the power button for 8 seconds while in
operation mode, the light on the power button will �lash
green and beep, indicating the �ilter lifespan timer has
been reset.
NOTICE: It is only possible to reset the �ilter lifespan
when the red light on the power button �lashes three
times with three beeps.
Press the power button repeatedly to cycle
through the different speed settings in
manual mode.
1 - Low fan Speed - Blue indicator light
2 - Medium fan speed - Yellow indicator light
3 - High fan speed - Red indicator light
The corresponding fan speed indicator light
will display the current fan speed.
The �ilter element lifespan is dependent on
how many hours the air puri�ier is utilized
and which mode of operation is used.
The system automatically monitors the fan
speed and operational hours; when the �ilter
lifespan reaches 100%, the red light on the
power button will �lash three times with
three beeps. It is now time to replace the �ilter.
8
Filter Replacement
Press and hold the power button
until the indicator light turns off.
Unplug the USB power cord from
the air puri�ier.
Holding the puri�ier, turn the base
clockwise and pull the lower housing
away. You will now see the �ilter
located inside the lower housing, lift
out the old �ilter, and dispose of
regular household waste (non-toxic).
The �ilter's actual lifespan may vary depending on the
amount of dust, smoke, humidity, and the concentration
of other airborne particles and vapors in the air.
Please note: the MS6 uses a disposable �ilter and should
not be washed.
Remove any packing material from
the new �ilter. Slot the new �ilter
into the base of the puri�ier. Replace
the base and turn anti-clockwise
until it locks closed. Plugin the air
puri�ier and follow the Filter reset
instructions (See Page 8).
9
Step 1
Step 2
Step 3
