Simpson SWF12843 Guide d'installation

SWF12843

RRP AUS $869.00

Simpson Ezi Sensor 8kg washing machine with 1200rpm spin speed, durable

inverter motor, fast wash program, extra large drum opening and time

remaining display.

SWF12843 - Ezi Sensor 8kg front load washing machine

Product Details

Features

Auto water level sensing Time save option Pause and add button High spin, less dry time

Easy iron wash option Tub clean program Rinse+ option for extra

rinsing Delay end option to plan

when your wash finishes

Liquid or powder detergent

drawer

SWF12843 - Ezi Sensor 8kg front load washing machine

Product Details

Benefits

EZI Load XXL drum opening

The extra-large drum opening makes loading and unloading

your washing so effortless and easy. Perfect for big loads or

those bulky items like blankets and curtains, youll have things

in or out in no time.

Easy control of every wash

Enjoy great results at the touch of a button. With everything

you need at your fingertips, the full-touch controls are easy to

use and help you get your washing done faster. Simply work

your way from left to right, set your wash and go. Plus, a

quick wipe is all you need to keep things clean.

An inverter motor that really lasts

Enjoy better care for your clothes with our super efficient

inverter motor. It's not only durable, but also saves on

energy too. So reliable, it has a 10 year warranty on the

inverter motor (parts only).

Save time with Fast Wash

Sometimes you just need to get a few things clean fast. And

thats where Fast Wash comes in. Designed to wash a daily

3kg load of lightly soiled clothes, this super-quick wash takes

just 30 minutes. Perfect for quick loads during the week or

when youve got to do multiple washes, Fast Wash is sure to

become your favourite program.

High spin, less dry time

Experience maximum efficiency with a higher spin speed that

expertly extracts more moisture from your clothes. This

means a shorter drying time. You can also adjust the spin

speed if preferred.

Timed to suit you

Keep your clothes fresh and say goodbye to wet and wrinkled

washing sitting in your machine. Now you can plan ahead and

get your wash to finish when its convenient for you. Simply

set the time you need your wash done and your clothes will be

ready when you are.

SWF12843 - Ezi Sensor 8kg front load washing machine

Specifications

PRODUCT PROFILE

Domestic warranty

details (yrs) 2

Front Loader Type Front Loader

Capacity (Kg) 8

DIMENSIONS

PRODUCT

Total height (mm) 850

Total width (mm) 600

Total depth (mm) 660

Depth with hoses (mm) 690

ENERGY FOR WASHING

Energy Star Rating 3.5

Energy Consumption

Warm (KWhr/yr) 373

Water efficiency star

rating 4.5

Water consumption (litres) 68

WASH PROGRAMS

Number of

Programs 7

Frontloader

Wash

programs

woollens,delicates,bedding,Whites,Colours,Tub

clean,ECO,Fast wash

Wash

options rinse plus,spin selection,rinse hold,wash

temperatures,cold wash,easy iron,Time

save,Heavy duty,rinse,drain & spin

Dispenser fabric conditioner dispenser,bleach

dispenser,Powder or liquid detergent dispenser

CONTROLS

Type of controls electronic touchscreen

Control panel colour white

Functions available door lock indicator,time

remaining,fault diagnostic

display,child lock

indicator,delay end,pause

Type of display LED

BOWL

Drum material stainless steel

SWF12843 - Ezi Sensor 8kg front load washing machine

DOOR

door lock Yes

Door opening angle 160

Door opening mm 341

CABINET

Cabinet Colour white

Cabinet material painted galvanized steel

TECHNICAL

Water pressure

requirements min 50

Water pressure

requirements max 800

Water supply cold

Inlet hose length 1300

Inlet hose extension avail

as spare part Yes

Drain hose length 1500

Drain hose extension avail

as spare part Yes

Service cord length 1700

Motor type inverter

Maximum spin speed 1200

Variable spin speed Yes

Number of spin speeds 3

SHIPPING

Shipping Weight (Kg) 73

Pack Dimensions Height

(mm) 870

Pack Dimension Width

(mm) 635

Pack Dimension Depth

(mm) 698

STUFFING QUANTITIES

40ft HC 150

SWF12843 - Ezi Sensor 8kg front load washing machine

ELECTROLUX HOME PRODUCTS AUSTRALIA

telephone: 1300363 640

fax:1800350067

email: customercare@electrolux.com.au

web:www.electrolux.com.au

ELECTROLUX HOME PRODUCTS NEW ZEALAND

telephone:095732230

fax:095732221

email: customercare@electrolux.co.nz

web:www.electrolux.co.nz

Terms and Conditions

IMPORTANT

This is a guide of product dimensions only. For complete installation instructions, refer to the manual provided with product.
