Simply Brands GD96 Manuel utilisateur

2.4G G-Sensor Control

Foldable Spider Drone

USER MANUAL

Model: GD96 SKU: SBA-00139 (without Camera)

SBA-00140 (4K HD Stills Camera/

1080p FHD Video Camera)

CAUTION: This product is not a toy. This

is not intended for use by children under the

age of 14. For your safety, please read this user

manual carefully and thoroughly before using

this product.

Please keep this manual somewhere safe for

future reference.

What’s Included

1x Foldable Spider

Drone (rechargeable

battery included)

1x Remote Control

(3x AAA batteries

not included)

2x Backup Propellers 1x USB Charger

1x Screwdriver 1x User Manual

Please Note

Please carefully check the number of accessories

shown above are not missing. Please provide proof of

purchase and contact the retailer for any replacement

parts if they are missing.

Pre-Flight Preparation

1. Opening the Wings

Wings now extended

2. Attaching the Protective Guard

Align the protective guard with the bottom of the

motor and rmly press it into place.

3. Attaching the Propellers

Align the propellers to the motor shaft and press them

in until rmly attached (match Propeller Awith Shaft A

and Propeller Bwith Shaft B).

4. Battery Charging for the Drone

Pre-Flight Preparation

A. Remove the rechargeable lithium battery pack from

the bottom at the drone.

B. Connect the USB charger with the charging port of

the lithium battery pack.

Please Note

Battery pack’s red LED indicator light will be off whilst

charging and it will only switch on when fully charged.

Charging time is about 150 minutes. The drone’s

operation time is about 7 minutes.

Battery Pack Guidelines

•There is a certain risk when using the drone’s lithium

battery. It may potentially cause a re, body injury or

property damage. Users must be aware of these risks

and take full responsibility in ensuring the battery

isn’t improperly used.

• If battery leakage occurs, please avoid electrolyte

discharge making contact with your eyes or skin.

If it happens, please wash your eyes thoroughly with

clean water and immediately seek medical care.

•Please immediately remove the battery from the

drone if you sense any peculiar smell, noise or smoke

coming from it.

Battery Pack Charging

•Please use the originally supplied USB charger to

ensure your safety and minimise any potential risks.

•Do not charge a dilatant or outworn battery.

•Do not overcharge the battery. Please unplug the

USB charger once the battery is fully charged.

• Do not charge the battery next to inammables such

as carpet, wooden oor, wooden furniture or on the

surface of electro-conductive objects. Please always

keep an eye on the battery when charging.

•Do not charge the battery when it’s not yet properly

cooled down.

•The battery’s charging temperature should be

between O°C to 40°C.

Battery Recycling

•Do not dispose the battery as household rubbish.

Please take it to a battery recycling point at a

recycling centre local to you. Alternatively you can

take it to a specic recycling collection point in a

supermarket, a DIY centre or local shop.

Remote Control Overview

High / Low Speed

One-key Flips &

Rolls 360°

Left Joystick (press

and hold down for

‘Headless Mode’)

Right Joystick (press

and hold down for

‘Fine-tuning Mode’)

One-key Start /

Landing (long press for

emergency stop)

Power Switch

Indicator Light

Inserting AAA Lithium Batteries

Open the battery cover and correctly insert the 3x

AAA batteries according to the +/- electrode markings.

(please note that batteries for the remote control are

not included).

Please Note

1. Make sure the batteries are loaded correctly according

to the polarity markings in the battery compartment.

2. Please do not mix old and new batteries together.

3. Please do not mix different types of batteries together.

Transmitter and Receiver

signal connection

Turn on the drone and place it on a level surface,

the drone’s indicator light should start to slowly

blink, which indicates it’s waiting for pairing.

Switch on the remote controller. When the remote

controller’s indicator light blinks, move the left

joystick upwards and you’ll hear a beep sound. Then

move it downwards and you’ll hear another beep

sound. When both the remote controller’s and

drone’s indicator light appear solid, this will indicate

pairing has been successful.

Press the ‘One Key Start/

Landing’ button as

shown on the right and

the drone’s propellers

will start to rotate.

Begin ying using

‘One Key Start’

Basic Flight Controls

Use the left joystick to control the ight altitude (ascent

or descent) and to rotate around to the left or right.

The right joystick lets you control to go forwards or

backwards as well as being able to bank to the left-

hand side / right-hand side.

Left Joystick

Descent

Ascent

Rotate

Left

Rotate

Right

Backwards

Forwards

Bank

Left

Bank

Right

Right Joystick

Basic Flight Controls

Flips & Rolls

When the drone is ying above 3 metres high, you can

press the ‘360° ips and rolls’ button and move the

right joystick to any specic direction you want which

will make the drone rotate in that chosen direction.

360° ips and rolls

Bank right

Bank left

Forwards

Backwards

Hover

When you let go of the left joystick (throttle) after the

drone has ascended / descended, the drone will stay

still hovering in mid-air until you next move one of the

joysticks again.

Left Joystick

– once you let

go of this, the

drone will stay

still hovering

in mid-air

Headless Mode

Using ‘Headless Mode’ helps to make it easier and

safer to learn how to y a drone especially if you are

a beginner. The drone will automatically y in the

direction you want it to regardless of the direction it’s

facing. This is particularly useful if you’re unsure what

the drone’s orientation is if you can’t tell from a long

distance away from you.

1. The drone is by default in ‘common / normal’ mode

as the drone’s indication light will be visibly on.

When you press the ‘headless mode’ function key on

the remote control, you’ll hear a short beep sound

that will indicate the drone has entered into headless

mode. When you next press the headless mode

function key again, you’ll then hear a long beep

sound that indicates the drone has now come out of

headless mode and is back to it’s default setting.

2. ln headless mode, you as the operator don’t need to

worry about identifying the direction of the drone’s

nose is facing, which just leaves you to easily control

the direction of the drone you want it to y to. If you

move the drone to the left or right, it will move to

your left or right.

Left Joystick

– press this

down to enter

/ exit ‘headless

mode’

One-key Landing Mode

Press the ‘One-key Start

/ Landing’ button on the

remote control to make

the drone automatically

slowly descend until

landing on the ground

and switch itself off.
