Simplicity Pacer Manuel utilisateur

Parts Manual

Rev. 6/2008

Pacer

Series Transaxle Drive Walk-Behind Mower

TP 400-7226-E-PA-S

. No. Descri

tion

15HP Product

1694895 Pacer, 15HP B&S Walk-Behind

2690447 Pacer, 15HP B&S w/34" Deck

. No. Descri

tion

17HP Product

5900630 Pacer, 17HP B&S w/34" Deck

. No. Descri

tion

Mower Decks

1694287 34" Mower Deck

5100117

Part No.:

Table Of Content

Torque Specification Chart ..................................................................... Inside Back Cover

PRODUCT COMPONENTS PAGES

Engine Frame & Handle Bars Group ................................................................................................................... 4

Engine & PTO Group ........................................................................................................................................... 6

Transaxle - SERVICE PARTS ............................................................................................................................. 8

Transaxle, Mount & Drive Idler Group ................................................................................................................. 10

Motion Control, Parking Brake & Operator Presence Group ............................................................................... 12

Fuel Supply Hose & Tank Replacement Parts Group ......................................................................................... 14

Fuel Tank & Mount Group (S/N: 2012825357 & Below) ...................................................................................... 16

Fuel Tank & Mount Group (S/N: 2012825358 & Above) ..................................................................................... 18

Electrical Group .................................................................................................................................................... 20

Wheel & Tire Group .............................................................................................................................................. 22

Decal Group ......................................................................................................................................................... 24

34" Mower Deck - Belt, Idler Arm & Hitch ............................................................................................................ 26

34" Mower Deck - Frame, Caster & Shield .......................................................................................................... 28

34" Mower Deck - Grass Mulcher ........................................................................................................................ 30

34" Mower Deck - Height Adjustment & Roller Bar ............................................................................................. 32

34" Mower Deck - Housing, Arbors & Blades ...................................................................................................... 36

Engine Frame & Handle Bars Group (226hbre0)

NOTE: Unless noted otherwise, use

the standard hardware torque

specification chart.

226hbre0

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1694895 - Pacer

2690447 - Pacer

5900630 - Pacer

TP 400-7226-E-PA-S

PART NO. DESCRIPTIONREF NO. QTY.

Engine Frame & Handle Bars Group (226hbre0)

Footnotes

SWITCH, PTO1 1722887SM 1 SWITCH RETAINER RING2 5022222SM 1 NUT, 3/8-24 Hex3 5025035SM 1 CABLE, Choke Control, 47"4 5046501SM 1 BOLT, 1/4-20 x 3/45 5025010X6SM 2 SWITCH, Ignition, Complete6 1686734SM 1 KEY, Ignition, Molded Set7 1717163SM 1 COVER8 1704346SM 1 PLASTIC NUT9 5022791SM 1 CABLE, Throttle Control, 46"10 5047629SM 1 GRIP, Foam11 5021841SM 2 NUT, 1/4-20 Hex Nylon Lock12 5025095SM 2 HANDLE BAR ASSEMBLY13 5061279CSM 1 NUT, #10-24 Hex Nylon Lock14 5025271SM 2 RUBBER STRAP15 5021670SM 1 SCREW, #10-24 x 116 5025270SM 2 BATTERY BOX17 5046188SM 1 BATTERY, Lawn & Garden, 12V (BCIU1, 340 CCA)18 - 1 BODY CLIP, 5/16-1819 5022308SM 4 REAR SHIELD20 5047735CSM 1 BOLT, 5/16-18 x 3/421 5025011X6SM 4 WASHER, 5/16" SAE22 5025155SM 4 ENGINE DECK ASSEMBLY23 5049229C 1

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1694895 - Pacer

2690447 - Pacer

5900630 - Pacer

TP 400-7226-E-PA-S

Engine & PTO Group (226eng0)

NOTE: Unless noted otherwise, use

the standard hardware torque

specification chart.

226eng0

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1694895 - Pacer

2690447 - Pacer

5900630 - Pacer

TP 400-7226-E-PA-S

PART NO. DESCRIPTIONREF NO. QTY.

Engine & PTO Group (226eng0)

Footnotes

ENGINE, 15HP Briggs & Stratton, Model 28 (15HP Model Only)1* 1 FUEL FILTER2 5021178X3SM 1 OIL FILTER (492932)2* 1 FOAM PRE-CLEANER (697015)2* 1 AIR FILTER (697634)2* 1 SPARK PLUG (691043)2* 1 MUFFLER (697349)2* 1 EXHAUST MANIFOLD (496750)2* 1 EXHAUST DEFLECTOR (396903)2* 1 EXHAUST MANIFOLD GASKET (692236)2* 2 GROMMET3 5021379SM 1 CRANKSHAFT BOLT, 7/16 x 2-3/44 5047632SM 1 CLUTCH RETAINER5 5042132SM 1 ELECTRIC CLUTCH6 1686880SM 1 KEY, 1/4 Sq. x 27 5050407X3SM 1 CAPSCREW, Hex Head, 5/16-18 x 2-1/28 5025011X20SM 1 WASHER, 5/169 5025155SM 5 OIL DRAIN HOSE10 5048681SM 1 NUT, Hex Nylon Lock, 5/16-1811 5025057SM 4 WASHER, 5/16" Internal Tooth Lock12 5025188SM 2 ENGINE, 17HP Briggs & Stratton (17HP Model Only)13 * 1

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1694895 - Pacer

2690447 - Pacer

5900630 - Pacer

TP 400-7226-E-PA-S

Transaxle - SERVICE PARTS (226tsp0)

NOTE: Unless noted otherwise, use

the standard hardware torque

specification chart.

226TSP0

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1694895 - Pacer

2690447 - Pacer

5900630 - Pacer

TP 400-7226-E-PA-S

PART NO. DESCRIPTIONREF NO. QTY.

Transaxle - SERVICE PARTS (226tsp0)

Footnotes

SEALANT6 5022905X1SM 10.5 SHAFT, INPUT9 5022905X2SM 1 RING - RETAINING10 5022905X3SM 1 SPACER11 5022905X4SM 1 RING - RETAINING12 5022905X5SM 3 SEAL, Lip, .67 x 1.58 x .27613 5022905X16SM 1 BALL BEARING14 5022905X6SM 1 OUTBOARD SLEEVE BEARING32 5022905X7SM 2 LIP SEAL, Axle Seal34 5022905X17SM 2 AXLE SHAFT - RH35 5022905X8SM 1 AXLE SHAFT - LH36 5022905X9SM 1 SPRING - HELICAL COMPRESSION55 5022905X10SSM 1 WASHER56 5022905X11SM 1 20W-50 OIL57 5022905X12 78.8 HYDRO RETURN SPRING101 5022967SM 1 FAN, 6", 10 BLADE119 5022905X13SM 1 EXPANSION TANK KIT128 5022905X14SM 1 FAN/PULLEY KIT130 5022905X15SM 1

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1694895 - Pacer

2690447 - Pacer

5900630 - Pacer

TP 400-7226-E-PA-S

Transaxle, Mount & Drive Idler Group (226trn0)

NOTE: Unless noted otherwise, use

the standard hardware torque

specification chart.

226trn0

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1694895 - Pacer

2690447 - Pacer

5900630 - Pacer

TP 400-7226-E-PA-S
