OPERATOR’S

MANUAL

Coronet

13HP Hydro

Coronet Series

11HP Gear Riders

Mfg. No. Description

1693030 Coronet, 11HP Gear

1693032 Coronet, 11HP Gear (Export)

13HP Hydro Riders

Mfg. No. Description

1693034 Coronet, 13HP Hydro

1693036 Coronet, 13HP Hydro (Export)

14HP Hydro Riders

Mfg. No. Description

1693038 Coronet, 14HP Hydro

1693040 Coronet, 14HP Hydro (Export)

30” Mower Decks

Mfg. No. Description

1692543 30” Mower Deck

34” Mower Decks

Mfg. No. Description

1692545 34” Mower Deck

1693168 34” Mower Deck (Export)

1717739

Rev 4/97

TP-100-2064-00-CO-S

MANUFACTURING, INC.

500 N Spring Street / PO Box 997

Port Washington, WI 53074-0997

www.simplicitymfg.com

OPERATOR’S

MANUAL

400 Series

Riders

Mfg. No. Description

1693042 411G, 11HP Gear

1693044 412H, 13HP Hydro

1693046 414H, 14HP Hydro

Mower Decks

Mfg. No. Description

1692544 30” Mower Deck

1692546 34” Mower Deck

1717740

Rev 4/97

TP-100-2064-00-CO-A

AGCO-Allis Lawn & Garden Equipment

500 N. Spring Street \ P.O. Box 997

Port Washington, WI 53074-0997 USA

www.allislawn.com

OPERATOR’S

MANUAL

2400 Series

Riders

Mfg. No. Description

1693048 2411G, 11HP Gear

1693050 2414H, 13HP Hydro

Mower Decks

Mfg. No. Description

1692544 30” Mower Deck

1692546 34” Mower Deck

1717741

Rev 4/97

TP-100-2064-00-CO-M

Massey Ferguson Lawn & Garden Equipment

is Manufactured and Distributed by Simplicity Manufacturing, Inc.

500 N. Spring Street • P.O. Box 997

•

Port Washington, WI 53074-0997 USA

www.masseylawn.com

RIDER & MOWER IDENTIFICATION............................2

SAFETY RULES............................................................3

SAFETY DECALS .........................................................5

FEATURES & CONTROLS...........................................6

Rider Features & Controls....................................................6

Engine Compartment............................................................7

Safety Interlock System........................................................8

OPERATION..................................................................9

General.................................................................................9

Mower Removal & Installation..............................................9

Operating The Mower.........................................................10

Checks Before Starting.......................................................10

Clutch/Brake Pedal Operation............................................11

Starting The Engine............................................................11

Selecting Ground Speed & Engine Speed .........................11

Stopping the Rider .............................................................12

Neutral Safety Checks........................................................12

Pushing the Rider by Hand ................................................12

MOWING PATTERN & TIPS.......................................13

NORMAL CARE ..........................................................15

Schedule.............................................................................15

Raising the Seat Deck........................................................15

Checking/Adding Gasoline .................................................15

Checking Tire Pressure......................................................15

Checking the Fuel Filter......................................................15

Lubrication..........................................................................16

Battery Maintenance...........................................................17

Checking the Battery Fluid ..............................................17

Cleaning the Battery and Cables.....................................17

Servicing the Mower Blades...............................................17

STORAGE ...................................................................19

Temporary Storage.............................................................19

Long Term Storage.............................................................19

Starting After Long Term Storage.......................................20

TROUBLESHOOTING & REPAIR...............................21

General...............................................................................21

Troubleshooting The Rider ................................................21

Troubleshooting The Mower...............................................22

Checking the Battery ..........................................................22

Charging A Completely

Discharged Battery..........................................................22

Jump Starting with

Auxiliary (Booster) Battery...............................................23

ADJUSTMENTS ..........................................................25

Seat Adjustment .................................................................25

Brake Adjustment ..............................................................25

Steering Gear Adjustment ..................................................26

Steering Wheel Adjustment................................................26

Mower Adjustments............................................................26

BELT REPLACEMENT................................................29

Rider Drive Belt..................................................................29

Mower Belt - 30” ................................................................29

Mower Belt - 34” ................................................................29

SPECIFICATIONS.......................................................30

INTERNATIONAL SYMBOLS.....................................31

PARTS & ACCESSORIES ..........................................32

Common Replacement Parts..............................................32

Maintenance Items .............................................................32

Optional Accessories..........................................................32

TECHNICAL MANUALS.............................................32

Table Of Contents

NOTE: In this manual, “left” and “right” are referred to as seen

from the operating position.

WARNING

Engine exhaust from this product contains chemi-

cals known, in certain quantities, to cause cancer,

birth defects, or other reproductive harm.

TP 100-2064-00-CO-SMA

Rider & Mower Identification

IDENTIFICATION NUMBERS

Record your model number, manufacturer number and

engine idnetification number in the space provided for

easy reference. The models and manufacturer numbers

covered in this manual are listed on the front cover. The

rider I.D. tag is located on the left-side of the frame, in

front of the rear tire, as shown below. The mower deck

I.D. tag is also on the left side, on top of the mower deck.

Refer to the engine Owner’s Manual for location of

engine identification number.

Be sure to fill out and return the Warranty Registration

Card supplied with your rider.

MODEL REFERENCE

Model Number:

Manufacturer Number:

Engine I.D. Number:

Dealer Name/Date Purchased:

Figure 1. Rider & Mower Identification Tags

Mower

Identification Tag

Rider

Identification Tag

GENERAL OPERATION

• Read, understand, and follow all instructions in the

manual and on the unit before starting.

• Only allow responsible adults, who are familiar with

the instructions, to operate the unit.

• Clear the area of objects such as rocks, toys, wire,

etc., which could be picked up and thrown by the

blade(s).

• Be sure the area is clear of other people before mow-

ing. Stop unit if anyone enters the area.

• Never carry passengers.

• Do not mow in reverse unless absolutely necessary.

Always look down and behind before and while trav-

elling in reverse.

• Be aware of the mower discharge direction and do

not point it at anyone. Do not operate the mower

without either the entire grass catcher or the deflector

in place.

• Slow down before turning.

• Never leave a running unit unattended. Always

disengage the PTO, set parking brake, stop engine,

and remove keys before dismounting.

• Turn off the PTO switch to disengage the blades

when not mowing.

• Stop engine before removing grass catcher or

unclogging chute.

• Mow only in daylight or good artificial light.

• Do not operate the unit while under the influence of

alcohol or drugs.

• Watch for traffic when operating near or crossing

roadways.

• Use extra care when loading or unloading the unit

into a trailer or truck.

SLOPE OPERATION

Slopes are a major factor related to loss-of-control and

tip-over accidents, which can result in severe injury or

death. All slopes require extra caution. If you cannot

back up the slope or if you feel uneasy on it, do not mow it.

• See your authorized dealer for recommendations of

wheel weights or counterweights to improve stability.

• Mow up and down slopes, not across.

• Remove obstacles such as rocks, tree limbs, etc.

• Watch for holes, ruts, or bumps. Uneven terrain could

overturn the unit. Tall grass can hide obstacles.

• Use slow speed. Choose a low gear so that you will

not have to stop or shift while on the slope.

• Use extra care with grass catchers or other attach-

ments. These can change the stability of the unit.

• Keep all movement on the slopes slow and gradual.

Do not make sudden changes in speed or direction.

Do Not

•

Do not

start or stop on a slope. If tires lose traction,

disengage the blade(s) and proceed slowly straight

down the slope.

•

Do not

turn on slopes unless necessary, and then,

turn slowly and gradually downhill, if possible.

•

Do not

mow near drop-offs, ditches, or embank-

ments. The mower could suddenly turn over if a

wheel is over the edge of a cliff or ditch, or if an edge

caves in.

•

Do not

mow on wet grass. Reduced traction could

cause sliding.

•

Do not

try to stabilize the unit by putting your foot on

the ground.

•

Do not

use grass catcher on steep slopes.

Safety Rules

Read these safety rules and follow them closely. Failure to obey these rules could result in loss of control of

rider, severe personal injury or death to you, or bystanders, or damage to property or equipment. This

mowing deck is capable of amputating hands and feet and throwing objects. The triangle in text

signifies important cautions or warnings which must be followed.

WARNING - SLOPE OPERATION

Never operate on slopes greater than 30 percent

(16.7°) which is a rise of three feet vertically in 10 feet

horizontally. When operating on slopes that are

greater than 15 percent (8.5°) but less than 30 percent

use front counterweights and rear wheel weights (see

your dealer). Select slow ground speed before driving

onto slope. In addition to front and rear weights, use

extra caution when operating on slopes with rear-

mounted grass catcher. Mow UP and DOWN the slope,

never across the face, use caution when changing

directions and DO NOT START OR STOP ON SLOPE.

CHILDREN

Tragic accidents can occur if the operator is not alert to

the presence of children. Children are often attracted to

the unit and the mowing activity. Never assume that chil-

dren will remain where you last saw them.

• Keep children out of the mowing area and under the

watchful care of another responsible adult.

• Be alert and turn unit off if children enter the area.

• Before and when backing, look behind and down for

small children.

• Never carry children. They may fall off and be seri-

ously injured or interfere with safe unit operation.

• Never allow children to operate the unit.

• Use extra care when approaching blind corners, shrubs,

trees, or other objects that may obscure vision.

TRANSPORTING AND STORAGE

• Always observe safe refueling and fuel handling prac-

tices when refueling the rider after transportation or

storage.

• Always follow the engine manual instructions for

storage preparations before storing the rider for both

short and long term periods.

• Always follow the engine manual instructions for

proper start-up procedures when returning the unit to

service.

• Never store the unit or fuel container inside where

there is an open flame or pilot light, such as in a

water heater. Allow unit to cool before storing.

SERVICE AND MAINTENANCE

• Use extra care in handling gasoline and other fuels.

They are flammable and vapors are explosive.

a) Use only an approved container.

b) Never remove gas cap or add fuel with the engine

Safety Rules

running. Allow engine to cool before refueling. Do

not smoke.

c) Never refuel the unit indoors.

• Never run a unit inside a closed area.

• Keep nuts and bolts, especially blade attachment

bolts, tight and keep equipment in good condition.

• Never tamper with safety devices. Check their proper

operation regularly.

• Keep unit free of grass, leaves, or other debris build-

up. Clean up oil or fuel spillage.

• Stop and inspect the equipment if you strike an

object. Repair, if necessary, before restarting.

• Never make adjustments or repairs with the engine

running unless specified otherwise in the engine

manufacturer’s manual.

• Grass catcher components are subject to wear, dam-

age, and deterioration, which could expose moving

parts or allow objects to be thrown. Frequently check

components and replace with manufacturer’s recom-

mended parts, when necessary.

• Mower blades are sharp and can cut. Wrap the

blade(s) or wear gloves, and use extra caution when

servicing them.

• Check brake operation frequently. Adjust and service

as required.

• Use only factory authorized replacement parts when

making repairs.

• Always comply with factory specifications on all

settings and adjustments.

• Only authorized service locations should be utilized

for major service and repair requirements.

• Never attempt to make major repairs on this unit

unless you have been properly trained. Improper ser-

vice procedures can result in hazardous operation,

equipment damage and voiding of manufacturer’s

warranty.

Autres manuels pour 1692546

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Simplicity Tondeuse à gazon

Simplicity

Simplicity SunRunner Series Manuel utilisateur

Simplicity

Simplicity Cobalt 5101602 Manuel utilisateur

Simplicity

Simplicity 3244 Manuel utilisateur

Simplicity

Simplicity Axion 1695447 Manuel utilisateur

Simplicity

Simplicity 1692380 Manuel utilisateur

Simplicity

Simplicity 5116 Manuel utilisateur

Simplicity

Simplicity 1695296 Manuel utilisateur

Simplicity

Simplicity Broadmoor 2600 Manuel utilisateur

Simplicity

Simplicity 1692174 Manuel utilisateur

Simplicity

Simplicity 1690530 Manuel utilisateur

Simplicity

Simplicity 1695266 Manuel utilisateur

Simplicity

Simplicity Javelin TP 400-4284-01-HZ-S Manuel utilisateur

Simplicity

Simplicity Conquest 4WD Series Manuel utilisateur

Simplicity

Simplicity Cobalt Series Manuel utilisateur

Simplicity

Simplicity 500 Series Manuel utilisateur

Simplicity

Simplicity 2690817 Manuel utilisateur

Simplicity

Simplicity 12.5 LTH Manuel utilisateur

Simplicity

Simplicity 19 Series Manuel d'exploitation et d'entretien

Simplicity

Simplicity Massey Ferguson 2690487 Manuel utilisateur

Simplicity

Simplicity 1693074 Manuel utilisateur

Simplicity

Simplicity TP 100 Manuel utilisateur

Simplicity

Simplicity 1964-1976 Manuel utilisateur

Simplicity

Simplicity SunRunner 1691198 Manuel utilisateur

Simplicity

Simplicity Derby Stallion ZT2561 Manuel utilisateur

Manuels Tondeuse à gazon populaires d'autres marques

RHINO

RHINO 1958 Manuel utilisateur

Wolf Garten

Wolf Garten Compact plus 40 B Manuel utilisateur

Cub Cadet

Cub Cadet LTX 1045 Manuel utilisateur

Craftsman

Craftsman 917.378461 Manuel utilisateur

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manuel utilisateur

Challenge

Challenge CH18V2 Instructions de fonctionnement

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manuel utilisateur

DEWEZE

DEWEZE ATM-725 Manuel d'utilisation

Weed Eater

Weed Eater 180083 Manuel utilisateur

Husqvarna

Husqvarna Poulan Pro PP185A42 Manuel utilisateur

Better Outdoor Products

Better Outdoor Products Quick Series Manuel utilisateur

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manuel d'utilisation

MTD

MTD 795, 792, 791, 790 Manuel utilisateur

Toro

Toro Groundsmaster 3505-D Manuel utilisateur

Dennis

Dennis FT 610 Manuel utilisateur

AIRFORCE

AIRFORCE F-15 Gen 3 Manuel utilisateur

MTD

MTD 126-220-000 Manuel utilisateur

Toro

Toro 74806 Manuel utilisateur
