Thank you for choosing the Simpled Slim Door Lock. Please
1. Read this manual completely before using the Simpled Slim Door Lock.
2. Alkaline Baeries are recommended.
3. Replace the baery when you noce the low-baery alarm.
4. Keep the Emergency keys outside the house.
For more informaon and support on Simpled Slim Door
Lock, feel free to contact us:
Product Overview
What’s Included
Specificaon
Factory reset
Installaon
Step 1 Resize the length according to the door thickness
Step 2 Tighten the Screw
Step 3 Install Indoor knob
Step 4 Installaon completed
Step 5 Install the Baeries
Operaon
Seng up the Smart App
Bluetooth Unlock
Add fingerprint
Add passcodes
Passcode Management
Create and Send e-Keys
e-Key Management
Add Fobs/Tags/Sckers
Unlocking Records
Gateway Pairing
FAQ
Contact Us
1-2
3
4
4
5
5
6
6
7
8
9
10
11
12
12
12
13
13
14-15
16
17
Table of Contents:
Product Overview
.: 1 :.
Overview Installaon Operaon FAQ Contact Us
69 mm
98765
4321
80 mm Lock core
Adjust the Cylinder to perfectly match your door and escutcheon.
69 mm
98765
321
60 mm Lock core
56 mm
56 mm
.: 2 :.
Overview Installaon Operaon FAQ Contact Us
For the inner part:
It's easier. Aer mounng the cylinder on the door, we can screw the inner
knob on the proper hole.
In this case, it will be the number 6 that gives us the 10mm that we want.
In this example, the door thickness is 60mm.
The escutcheon thickness is 10mm each.
So we need to increase the length by 10mm for each side.
For the outer part:
1. We unscrew the hex on the cylinder body
2. then secure it on the 2nd hole, extending the outer part to 10mm.
Door Thickness
Inside Outside
60 mm
10 mm 10 mm
40 mm
40 mm
12
Outdoor
length
1
30 mm 1
35 mm 2
40 mm 3
45 mm /
1
2
50 mm 3
55 mm 4
Intdoor
length
2
5
6
7
8
5
6
7
8
60 mm
85mm
80 mm
110 mm
40 mm
45 mm
30 mm
35 mm
40 mm
45 mm
50 mm
55 mm
40 mm
45 mm
.: 3 :.
Overview Installaon Operaon FAQ Contact Us
What’s Included?
NameNo QTY
Simpled Cylinder
1 1
Sucon Cup2 1
3 3
Proxy Fobs / Sckers
4 2
Emergency Key
51User Manual
50* Screw for Cylinder M5
6 1
7 1
8 1
9 3
10 2
70* Screw for Cylinder M5
5mm* Hex Screw M1.5
10mm* Hex Screw M1.5
Hex Screw driver
.: 4 :.
Overview Installaon Operaon FAQ Contact Us
Specificaons
Model: CF-YC
Materials
Lock Weight
Unlocking
Way
Colour
Low Baery
Alarm
Doors
Applicable
Baery
Voltage
Data
Capacity
Working
Temperature
Working
Humidity
Aluminium Door
Wooden Auto
6V/4 x AA Baeries
Door Thickness
to Fit
60-85mm
80-110mm
Fingerprint: 200
Password: 150
Fob: 200
-10°C-55°C
0-95%
Less than 4.8 v
Silver - Black
Bluetooth
Fingerprint
Password
Proxy Fob / Sckers
Emergency Key
Alexa (Bridge needed)
Google Home (Bridge needed)
1 KG
Aluminum alloy
Open the cover and
long-press the
"reset" buon for 5 sec.
Then key in "000#".
It short beeps twice to
show it is successfully
reset.
Factory reset
.: 5:.
Overview Installaon Operaon FAQ Contact Us
Setup1 Resize the length according to the door thickness
Setup2 Tighten the Screw
.: 6:.
Overview Installaon Operaon FAQ Contact Us
Setup3 Install Indoor knob
Setup4 Installaon completed
.: 7 :.
Overview Installaon Operaon FAQ Contact Us
Setup5 Install the Baeries
1. Insert the key and rotate
counterclockwise to unlock.
Remove the keypad panel.
(When you open it for the first me,
there’s no hex screw.)
2. Alkaline baeries are highly
recommended
3. Take the M1.5*5mm hex
Screw out of the fing bag
and ghten it clockwise.
Ce manuel convient aux modèles suivants
