Simons Voss SmartIntego Series Manuel utilisateur
SmartIntego
Locking cylinder
Manual
28.10.2020
Contents
1 Intended use ................................................................................................................................................4
2 General safety instructions..................................................................................................................... 5
3 Product specific safety notices .............................................................................................................8
4 General information on SmartIntego ..................................................................................................11
4.1 Product description.........................................................................................................................................11
4.2 Locking cylinder design .................................................................................................................................11
4.3 Half cylinder design........................................................................................................................................12
4.4 Opening and locking from the outside .................................................................................................12
4.5 Opening and locking from the inner side.............................................................................................13
5 SmartIntego designs............................................................................................................................... 14
5.1 FD version (Standard)................................................................................................................................. 14
5.2 HZ version (Standard) ................................................................................................................................ 14
5.3 Half-cylinder (HZ) version (self-locking)........................................................................................... 14
5.4 MS version ......................................................................................................................................................... 14
5.5 AP version .......................................................................................................................................................... 15
5.6 CO version.......................................................................................................................................................... 16
6 Installation guide for 'SmartIntego'.................................................................................................... 17
6.1 General instructions.......................................................................................................................................17
6.2 Programming the locking cylinder ..........................................................................................................17
6.3 Installation variants .......................................................................................................................................17
6.3.1 Installation of double thumb-turn cylinders (except types .AP2) ........................ 17
6.3.2 Fitting an anti-panic cylinder ................................................................................................. 20
6.3.3 Half Cylinder DK/MR................................................................................................................... 22
6.3.4 Installing Swiss Round...............................................................................................................24
7 SmartIntego audible signals ............................................................................................................... 26
8 Battery warnings ...................................................................................................................................... 27
8.1 SI online battery warning ........................................................................................................................... 27
8.2 SI offline battery warning........................................................................................................................... 27
9 Battery replacement in SmartIntego................................................................................................ 29
9.1 General instructions..................................................................................................................................... 29
9.2 Battery life ........................................................................................................................................................ 29
9.3 Procedure .........................................................................................................................................................30
10 Areas of use ...............................................................................................................................................32
SmartIntego Locking cylinder (Manual) Contents
2 / 44
10.1 General................................................................................................................................................................32
10.2 Fire doors............................................................................................................................................................32
10.3 Doors along rescue routes.........................................................................................................................32
10.4 Installation outdoors ....................................................................................................................................32
11 Networking.................................................................................................................................................33
11.1 Networking Online.........................................................................................................................................33
11.2 Networking Offline (Virtual networking) ............................................................................................33
12 'SmartIntego' accessories ................................................................................................................... 34
12.1 Core protection adapter Z4.MP.KA.SET............................................................................................ 34
12.2 Tool...................................................................................................................................................................... 34
12.3 Battery set ........................................................................................................................................................ 34
13 'SmartIntego' data sheets ....................................................................................................................35
13.1 Locking cylinder ............................................................................................................................................. 35
13.2 Half cylinder..................................................................................................................................................... 36
13.3 Dimensional drawings cylinder ...............................................................................................................37
14 Maintenance, cleaning and disinfection........................................................................................... 41
15 Declaration of conformity .....................................................................................................................42
16 Help and other information ................................................................................................................. 43
SmartIntego Locking cylinder (Manual) Contents
3 / 44
1 Intended use
Digital SimonsVoss SI-Locking Cylinder are installed in designated door
locks, such as DIN mortise locks, to integrate them into a digital locking
system.
The digital SI-Locking Cylinder may only be used for its intended purpose in
a designated door locking device. No other use is permitted.
Digital SI-Locking Cylinders are available in various lengths. The selection
of the proper size is of significance. The length of the locking cylinder is
printed on the packaging and can be measured at any time. If the cylinder is
too short, the handles cannot be fitted. If the cylinder is too long, it may be
ripped out of the locking device. The may not protrude more than 3 mm on
each side of the door to ensure proper operation.
The product may not be changed in any way, other than in compliance with
the changes described in the instructions.
SmartIntego Locking cylinder
(Manual)
1. Intended use
4 / 44
2 General safety instructions
Signal word (ANSI
Z535.6) Possible immediate effects of non-compliance
DANGER Death or serious injury (likely)
WARNING Death or serious injury (possible, but unlikely)
CAUTION Minor injury
IMPORTANT Property damage or malfunction
NOTE Low or none
WARNING
Blocked access
Access through a door may stay blocked due to incorrectly fitted and/or in-
correctly programmed components. SimonsVoss Technologies GmbH is
not liable for the consequences of blocked access such as access to in-
jured or endangered persons, material damage or other damage!
Blocked access through manipulation of the product
If you change the product on your own, malfunctions can occur and access through a door can
be blocked.
Modify the product only when needed and only in the manner described in the
documentation.
CAUTION
Fire hazard posed by batteries
The batteries used may pose a fire or burn hazard if handled incorrectly.
1. Do not try to charge, open, heat or burn the batteries.
2. Do not short-circuit the batteries.
IMPORTANT
Damage resulting from electrostatic discharge (ESD)
This product contains electronic components that may be damaged by electrostatic discharges.
1. Use ESD-compliant working materials (e.g. Grounding strap).
2. Ground yourself before carrying out any work that could bring you into contact with the
electronics. For this purpose, touch earthed metallic surfaces (e.g. door frames, water pipes
or heating valves).
SmartIntego Locking cylinder
(Manual)
2. General safety instructions
5 / 44
Damage resulting from liquids
This product contains electronic components that may be damaged by liquids of any kind.
Keep liquids away from the electronics.
Damage resulting from aggressive cleaning agents
The surface of this product may be damaged as a result of the use of unsuitable cleaning agents.
Only use cleaning agents that are suitable for plastic or metal surfaces.
Damage as a result of mechanical impact
This product contains electronic components that may be damaged by mechanical impacts of
any kind.
1. Avoid touching the electronics.
2. Avoid other mechanical influences on the electronics.
Damage due to polarity reversal
This product contains electronic components that may be damaged by reverse polarity of the
power source.
Do not reverse the polarity of the voltage source (batteries or mains adapters).
Failure of operation due to different discharged batteries
This product uses one or more batteries for power supply. The batteries are discharged at ap-
proximately the same rate.
Always replace all batteries at the same time.
Operational malfunction due to radio interference
This product may be affected by electromagnetic or magnetic interference.
Do not mount or place the product directly next to devices that could cause electromagnetic
or magnetic interference (switching power supplies!).
Communication interference due to metallic surfaces
This product communicates wirelessly. Metallic surfaces can greatly reduce the range of the
product.
Do not mount or place the product on or near metallic surfaces.
NOTE
Intended use
SimonsVoss-products are designed exclusively for opening and closing
doors and similar objects.
Do not use SimonsVoss products for any other purposes.
SmartIntego Locking cylinder
(Manual)
2. General safety instructions
6 / 44
Battery contact malfunction due to grease film
When touching batteries, leave a thin film of skin grease on the batteries. This film deteriorates
the contact between the electronics and the batteries.
1. Do not touch the contacts of the new batteries with your hands.
2. Use clean and grease-free gloves.
Dispose of the batteries as per local and country-specific regulations.
Function error due to poor battery contact
If the contact surface to the battery is too small, then the battery connection may not create a
stable connection to the battery.
Only use batteries that are approved by SimonsVoss.
Qualifications required
The installation and commissioning requires specialized knowledge.
Only trained personnel may install and commission the product.
Incorrect installation
SimonsVoss Technologies GmbH accepts no liability for damage caused to doors or compon-
ents due to incorrect fitting or installation.
Modifications or further technical developments cannot be excluded and may be implemented
without notice.
The German language version is the original instruction manual. Other languages (drafting in the
contract language) are translations of the original instructions.
Read and follow all installation, installation, and commissioning instructions. Pass these instruc-
tions and any maintenance instructions to the user.
SmartIntego Locking cylinder
(Manual)
2. General safety instructions
7 / 44
3 Product specific safety notices
WARNING
Failure of the escape door function
The use of unsuitable components or components that are not ready for
operation can impair the function of an escape door. If you use the anti-
panic cylinder in non-approved locks, the escape door function may be im-
paired and cannot be released again.
1. Make sure that all parts of the lock are ready for operation.
2. Make sure that the panic function of the mortise lock is ensured.
3. Please refer to the documentation of the lock manufacturer.
4. Only use the anti-panic cylinder within the specified temperatures.
5. Perform a function test after installation or battery change of the anti-
panic cylinder.
CAUTION
Use of the anti-panic version of the locking cylinder in non-approved
locks
If you use the anti-panic version of the locking cylinder in unauthorised
locks, the escape door function may be impaired and cannot be released
again.
1. Only use the anti-panic version of the locking cylinder in locks for which
the locking cylinder is expressly approved.
2. Please refer to the documentation of the respective lock manufacturer.
3. Contact SimonsVoss Technologies GmbH for further information on this
subject (see
Help and other information [}43]
).
Hand injuries from carrier springing back
A spring-loaded carrier is used in the anti-panic construction of the closing cylinder. This carrier
can spring back when it is not installed, causing hand injuries.
Do not hold the anti-panic construction of the closing cylinders in the area of the carrier.
IMPORTANT
Damage caused by moisture in outdoor use
Moisture can damage the electronics.
1. If you want to use the locking cylinder for outdoor applications or in high humidity (bathrooms
or washrooms), use the WP version.
2. Carefully insert the locking cylinder to avoid damaging the O-rings.
SmartIntego Locking cylinder
(Manual)
3. Product specific safety notices
8 / 44
Mechanical damage to the thumb-turn as a result of obstacles
If the thumb-turn can knock against the wall or other objects as a result of the installation situ-
ation, it may become damaged.
In such situations, use a suitable door stop.
Mechanical damage to the knob through misuse as door-opener
Some doors are very heavy and solidly constructed. The knob is not suitable for opening such
doors.
1. Don't pull the knob to open doors.
2. Make suitable door openers available (suitable handles) to avoid misuse of the knob.
DoorMonitoring in gear locks
Door monitoring cylinders are not suitable for operation in multi-lock systems with gear (gear
locking devices). Except: DM.AP2, without bolt monitoring.
Do not use door monitoring cylinders in gear locking devices.
NOTE
Maintenance interval of not more than one month for emergency exit
locks
As per European standard EN 179, Appendix C, all components in a locking
device must be checked at intervals no greater than one month to ensure
that they are in satisfactory working order as part of emergency exit locking
device maintenance.
Inclusion of persons without means of identification
The freely-rotating construction of the closing cylinder can only be opened with a means of iden-
tification from both sides.
Ensure that no persons without means of identification are in the secured area.
Length of locking system password
For security reasons, the locking system password must consist of at least 8 characters. The
code length for digital closing cylinders
(and for System 3060/3061 and MobileKey)
corres-
ponds to 2168 Bit.
Fault in the interior knob due to moisture
The inner knob of the closing cylinder is of protection class IP40 and is thus not protected from
moisture.
Ensure that the interior knob cannot come into contact with water.
Battery changes may only be carried out by trained personnel and only with the battery key
provided (Z4.KEY)!
Programming with obsolete LSM version
New components can only be programmed with the current version of LSM.
SmartIntego Locking cylinder
(Manual)
3. Product specific safety notices
9 / 44
Difficulty of operation of the lock due to stiff latch or bolt
If the latch or bolt of the mortice lock are stiff, the closing cylinder will also be stiff.
Check that the latch or the bolt of the mortice lock are free-moving.
Fitting error or incorrect order
If you make a mistake in measuring the door and order a closing cylinder, the closing cylinder will
not fit.
Check the dimensions of the door again before ordering.
SmartIntego Locking cylinder
(Manual)
3. Product specific safety notices
10 / 44
Ce manuel convient aux modèles suivants
6
Table des matières
Autres manuels Simons Voss Serrure de porte
Simons Voss
Simons Voss PegaSys Door Handle 4.1 Reader on both sides Manuel utilisateur
Simons Voss
Simons Voss PegaSys Door Handle 4.1 Panic bar Manuel utilisateur
Simons Voss
Simons Voss 3061 DM Manuel utilisateur
Simons Voss
Simons Voss SmartIntego SmartHandle Series Manuel utilisateur
Simons Voss
Simons Voss PegaSys Door Handle 4.1 PAS24 Manuel utilisateur
Simons Voss
Simons Voss 3061 FD Manuel utilisateur
Simons Voss
Simons Voss PegaSys Door Handle 4.1 Scandinavian Oval Manuel utilisateur
Simons Voss
Simons Voss SmartIntego SmartHandle AX Series Manuel utilisateur
