SIM Roulette SR-Train Manuel utilisateur
SR-Train
User manual
EQUIPMENT
SIM aggregator
Panel container
Manual
1
1
1
GETTING STARTED WITH THE DEVICE
Graphic display
Multifunction button
WiFi by default (press 0.5 sec after power on)
Lifting contacts
Path length scan
Power supply connector
12V/2A, connector diameter 0.2 inch
Indicator lightsoperating mode
End of path signaling device
Container panel
Contacts
Zero row
The first two rows on the first
panel are not used
3
0
INSTALLING SR-TRAIN ON THE WAY
1. Remove the protective film from the surface of the SIM aggregator and
parts of the container panels.
2. Place the container panels on the legs.
3. Assemble the path from the container panels by connecting them with the
corresponding sides of the shaped connectors.
4. Cover all track end markers with an opaque material, except for the end
markers on the outer panels. If there is only one panel, you do not need to
glue the signaling devices!
5. Carefully place the SR-Train on the track as shown without force. The power
cable must be on the opposite side from the signal holes.
CONNECTING TO A LOCAL NETWORK
The SIM aggregator connects to the local network via WiFi.
By default, the device is configured to connect to a network with the name (SSID):
SIM and password: roulette
To change the connection settings, you can use the following advice:
1. Set up a SIM hotspot with the password roulette on your mobile phone.
2. Turn on the SIM aggregator and make sure that it connects to the created WiFi
network.
3. In the mobile phone browser, go to the address http://sim-roulette.local or
http:// IP_address_your_SIM_roulette (the IP address is displayed in the top line
of the device display when connected to the network).
4. Log in. By default, login: admin, password: admin.
5. Go to the Settings/Network section, select your work network and enter the
password.
6. Save settings. After restarting, the SIM aggregator will connect to the selected
network.
BEGINNING OF WORK
1. Move the SIM Aggregator manually to the middle of the panel.
2. Place the 16 Nano SIM cards in the cells of rows 0 and 3 (the rows are shown
in the figure).
3. Press the multifunction button on the body of the SIM aggregator to scan the
path length.
4. Go to the WEB-interface Terminal section.
5. If there is a stable connection with the device, the upper signal line should be
green, if there is no connection — gray.
6. Enter the command modem>connect. The command will connect the GSM
modem to the SIM cards.
7. Enter the command m:test/modems. The command will run a macro for
checking the functionality of GSM modems.
8. After checking the modems, you can choose one of 16 modems to interact with.
For example: modem>select:1
9. As a check, make an outgoing call with the
modem>send command:ATD+79001234567;
Complete list of AT commands: sim-roulette.com/en/doc/at
API SR-Nano: sim-roulette.com/en/doc/sr-train
Calibrating SR-Nano: sim-roulette.com/en/doc/sr-nano-mekhanika
Applications for SIM Roulette: sim-roulette.com/apps
If you plan to work with the aggregator using the WEB-panel
SR-Navigator, we recommend registering at sim-roulette.com and
familiarizing yourself with the capabilities of this software.
HELP AND SUPPORT
WEB-site: sim-roulette.com
Technical documentation: sim-roulette.com/en/doc
Форум: sim-roulette.com/forum
Forum: [email protected]
We recommend registering on the website sim-roulette.com
and link the aggregator to your account.
Thank you for purchasing the SR-Train and wish you fruitful work!
