CORDLESS WINDOW VACUUM CLEANER SFR 3.7 D3

CORDLESS WINDOW VACUUM CLEANER

Assembly, operating and safety instructions

AKUMULATORSKI ČISTILNIK OKEN

Navodila za montažo, uporabo in varnostna navodila

AKUMULÁTOROVÝ ČISTIČ OKEN

Pokyny k montáži, obsluze a bezpečnostní pokyny

PRÍSTROJ NA ČISTENIE OKIEN

Pokyny pre montáž, obsluhu a bezpečnostné pokyny

AKKU-FENSTERSAUGER

Montage-, Bedienungs- und Sicherheitshinweise

143 mm 138 mm

IAN 331391_1907

138 mm

GB Assembly, operating and safety instructions Page 5

SI Navodila za montažo, uporabo in varnostna navodila Stran 16

CZ Pokyny k montáži, obsluze a bezpečnostní pokyny Strana 27

SK Pokyny pre montáž, obsluhu a bezpečnostné pokyny Strana 38

DE/AT/CH Montage-, Bedienungs- und Sicherheitshinweise Seite 49

138 mm 143 mm

HG04476

5GB

Warnings and symbols used ...................................... Page 6

Introduction ......................................................... Page 7

Intended use ........................................................ Page 7

Scope of delivery.................................................... Page 7

Description of parts.................................................. Page 7

Technical data....................................................... Page 8

Safety instructions.................................................. Page 8

Before ﬁrst use ...................................................... Page 11

Assembly ............................................................ Page 11

Product assembly.................................................... Page 11

Attaching the wiper.................................................. Page 11

Operation............................................................ Page 12

Charging the product ................................................ Page 12

Cleaning windows................................................... Page 12

Turning on/oﬀ....................................................... Page 12

Vacuuming windows................................................. Page 12

Cleaning and care .................................................. Page 12

Troubleshooting..................................................... Page 13

Storage .............................................................. Page 13

Disposal.............................................................. Page 14

Warranty ............................................................ Page 14

6 GB

Warnings and symbols used

The following warnings are used in this user manual and on the packaging:

DANGER! This symbol in

combination with the signal word

“Danger” marks a high-risk hazard

that if not prevented could result in

death or serious injury.

Voltage (alternating current)

Voltage (direct current)

Hertz (supply frequency)

Watts

WARNING! This symbol in

combination with the signal word

“Warning” marks a medium-risk

hazard that if not prevented could

result in death or serious injury.

NOTE: This symbol in combination

with “Note” provides additional

useful information.

For indoor use only.

CAUTION! This symbol in

combination with the signal word

“Caution” marks a low-risk hazard

that if not prevented could result in

minor or moderate injury.

Danger – risk of electric shock!

Symbol for a protection class III

product. The main part of the product

operates within a completely safe

voltage range.

Do not use bleach.

Symbol for a protection class II

product. The charger has a double

insulation.

Do not dry clean. Do not tumble dry.

Do not iron. Washable at 60 °C.

7GB

Short-circuit proof safety transformer. Polarity of the output terminal.

SMPS (Switch mode power supply

unit) (switching power supply).

Protected against splashing water

from all directions.

CORDLESS WINDOW

VACUUM CLEANER

Introduction

We congratulate you on the purchase of your

new product. You have chosen a high quality

product. The instructions for use are part of the

product. They contain important information

concerning safety, use and disposal. Before using

the product, please familiarise yourself with all

of the safety information and instructions for use.

Only use the product as described and for the

speciﬁed applications. If you pass the product on

to anyone else, please ensure that you also pass

on all the documentation with it.

Intended use

This product is designed for cleaning and

vacuuming smooth surfaces (e.g. windows). Do

not use it for any other purpose.

This product is only intended for private

household use, not for commercial purposes.

The manufacturer accepts no liability for

damages caused by improper use.

Scope of delivery

After unpacking the product, check if the delivery

is complete and if all parts are in good condition.

Remove all packing materials before use.

1x Vacuum attachment

1x Dirt water container

1x Motor unit

1x Wiper

1x Water container

2x Microﬁber cover

1x Charger

Description of parts

1Vacuum attachment

2Charger

3Microﬁber cover (x2)

4Wiper

5Spray nozzle

6Water container (of spray bottle)

7Charging socket (with stopper)

8Dirt water container

9Motor unit

(on/oﬀ button with indicator light)

Eject buttons

Suction head

Release button (vacuum attachment)

8 GB

Technical data

Window vacuum cleaner

Rated voltage: 3.7 V

Rated current: 1 A

Battery type: Li-Ion Battery, 3.7 V ,

2200 mAh

Operating time: approx. 40 minutes

Charging time: approx. 2.5 to 3.5 hours

IP protection class: IPX4

Protection class: III

Sound pressure

level: 68 dB(A)

Dirt water container

capacity:

270 ml (about 150 ml at

MAX marking)

Spray bottle: 360 ml

Weight: approx. 800 g

Charger

Manufacturer’s

name or trade

mark, commercial

registration number

and address:

Xiamen Xunheng Electronics

Tech Co., Ltd

91350200MA34779Q3L

No. 28, Xiangyue Road,

Xiangan District, Xiamen,

China

Model identiﬁer: XH0500-1000WG

Input voltage: 100-240 V∼

Input AC frequency: 50/60 Hz

Output voltage: 5.0 V

Output current: 1.0 A

Output power: 5.0 W

Average active

eﬃciency: 73.9 %

No-load power

consumption: 0.10 W

Protection class: II

Safety instructions

BEFORE USING THE PRODUCT,

PLEASE FAMILIARISE

YOURSELF WITH ALL OF

THE SAFETY INFORMATION

AND INSTRUCTIONS FOR

USE! WHEN PASSING THIS

PRODUCT ON TO OTHERS,

PLEASE ALSO INCLUDE ALL

THE DOCUMENTS!

In the case of damage resulting

from non-compliance with

these operating instructions

the warranty claim becomes

invalid! No liability is accepted

for consequential damage! In

the case of material damage

or personal injury caused by

incorrect handling or non-

compliance with the safety

instructions, no liability is

accepted!

Children and persons with

disabilities

mWARNING! RISK

OF LOSS OF LIFE OR

ACCIDENT TO INFANTS

AND CHILDREN!

Never leave children

unsupervised with the

packaging material.

9GB

The packaging material

represents a danger of

suﬀocation. Children frequently

underestimate the dangers.

Always keep children away

from the packaging material.

This product can be used by

persons with reduced physical,

sensory or mental capabilities

or lack of experience and

knowledge if they have

been given supervision or

instruction concerning use

of the product in a safe way

and understand the hazards

involved. The product shall

not be left unattended while

it is connected to the supply

mains. Keep the product out

of reach of children when it is

energized.

Children shall not play with the

product.

Cleaning and user

maintenance shall not be made

by children without supervision.

Intended use

mWARNING! Misuse may

lead to injury. Use this product

solely in accordance with these

instructions. Do not attempt to

modify the product in any way.

Electrical safety

mDANGER! Risk of electric

shock! Never attempt to

repair the product yourself. In

case of malfunction, repairs

are to be conducted by

qualiﬁed personnel only.

mWARNING! Risk of

electric shock! Do not

immerse the product in water

or other liquids. Never hold the

product under running water.

10 GB

mWARNING! Risk of

electric shock! Never use a

damaged product. Disconnect

the product from the power

supply and contact your

retailer if it is damaged.

mWARNING! Risk of

injury! Switch the product

oﬀ and disconnect it from the

power supply before cleaning

work and when not in use.

mWARNING! Risk of

injury! This product contains

a non-replaceable Lithium-Ion

rechargeable battery. Do not

throw the product into a ﬁre.

mDANGER! Only use this

product with the supplied

charger.

Do not operate the product

while it is being charged.

Always charge the product

in an open area away from

ﬂammable materials and

liquids.

Misuse can cause ﬁre and

burns.

The product is not to be used

if it has been dropped, if there

are visible signs of damage or

if it is leaking.

Protect the connection cord

against damages.

Do not let it hang over sharp

edges, do not squeeze or bend

it. Keep the connection cord

away from hot surfaces and

open ﬂames.

Ensure that nobody can pull on

or trip over it unintentionally.

Operation

The charger must be

disconnected from the wall

outlet before the water tank is

ﬁlled with water.

Keep the charging socket

closed with the stopper at all

times to ensure the product's

ingress protection against

splashing water.

11GB

Do not obstruct the ventilation

slots during operation. A

blocked ventilation circuit

can result in overheating and

damage to the product.

Cleaning and storage

Do not pull the charger out

of the wall outlet by the

connection cord.

Protect the charger against

dust, direct sunlight, dripping

and splashing water. Protect

the product against dust and

direct sunlight.

Store the product in a cool,

dry place, protected from

moisture and out of the reach

of children.

Protect the product against

heat.

Do not place the product close

to open ﬂames or heat sources

such as stoves or heating

appliances.

Before ﬁrst use

Remove all packaging materials. Check if all

parts are complete.

NOTE: The product's built-in battery is not

charged on delivery. Charge the battery

completely before ﬁrst use (see “Charging

the product” section).

Assembly

Product assembly

Push the vacuum attachment 1onto the

suction head

Place the assembly on the motor unit 9.

Attaching the wiper

NOTES:

Prior to assembling the wiper 4, ﬁll the

water container 6with water and/or

cleaning detergent.

Do not use abrasive or aggressive cleaning

detergents. These could damage the product.

Do not exceed the water container's 6

maximum capacity of 360 ml.

Screw the wiper 4onto the water

container 6.

Unfasten the hook-and-loop strap on one

side of the microﬁber cover 3.

Place a microﬁber cover 3on the wiper 4.

Fasten the hook-and-loop strap of the

microﬁber cover 3.

Autres manuels pour SFR 3.7 D3

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Silvercrest Aspirateur

Silvercrest

Silvercrest SAS 7.4 LI B2 Manuel utilisateur

Silvercrest

Silvercrest SAS 7.4 LI B1 Manuel utilisateur

Silvercrest

Silvercrest SHAZB 29.6 B2 Manuel utilisateur

Silvercrest

Silvercrest 331174 1907 Manuel utilisateur

Silvercrest

Silvercrest SAS 7.4 LI C2 Manuel utilisateur

Silvercrest

Silvercrest SAS 7.4 LI D3 Fiche d'information produit

Silvercrest

Silvercrest SAS 7.4 LI D3 Fiche d'information produit

Silvercrest

Silvercrest SHAZ 22.2 A1 Manuel utilisateur

Silvercrest

Silvercrest 42774 Manuel utilisateur

Silvercrest

Silvercrest SHSS 12 C2 Manuel utilisateur

Silvercrest

Silvercrest SHSS 12 C2 Manuel utilisateur

Silvercrest

Silvercrest SAS 7.4 LI C1 Manuel utilisateur

Silvercrest

Silvercrest SAST 18 A1 Manuel utilisateur

Silvercrest

Silvercrest SHS 12.0 A2 Manuel utilisateur

Silvercrest

Silvercrest SHSS 18 B1 Manuel utilisateur

Silvercrest

Silvercrest SAS 7.4 LI A1 Manuel utilisateur

Silvercrest

Silvercrest SMS 300 A1 Fiche d'information produit

Silvercrest

Silvercrest SHAZ 22.2 A1 Manuel utilisateur

Silvercrest

Silvercrest SAS 7.2 A1 Manuel utilisateur

Silvercrest

Silvercrest SHS 12.0 A2 Manuel du propriétaire

Silvercrest

Silvercrest SHS 12.0 A2 Manuel utilisateur

Silvercrest

Silvercrest SBBK 700 A1 Comment utiliser

Silvercrest

Silvercrest 79406 Manuel utilisateur

Silvercrest

Silvercrest SAS 7.4 LI D3 Fiche d'information produit

Manuels Aspirateur populaires d'autres marques

Bissell

Bissell LittleGreen Proheat 1425 Series Manuel utilisateur

Panasonic

Panasonic MC-YL637S147-AE Manuel utilisateur

NEFF

NEFF N17XH10 0 Series Manuel utilisateur

LG A9 Series Manuel utilisateur

Oreck

Oreck Cordless Captura BK51700 Series Manuel utilisateur

Kogan

Kogan KAVACROBVWA Manuel utilisateur

Kränzle

Kränzle VENTOS 50 ID Guide de l'utilisateur

EVVO

EVVO Ai35 Manuel utilisateur

DeWalt

DeWalt DWH200D Manuel utilisateur

Pontec

Pontec Pondomatic Vacuum Cleaner Manuel utilisateur

Cleanmaxx

Cleanmaxx PC-P007E Manuel utilisateur

Exido

Exido 240-114 Manuel utilisateur

RIDGID

RIDGID WD1685AU0 Manuel utilisateur

Ezviz

Ezviz RE4P Manuel utilisateur

STG global

STG global TANVAC HDV3000 Manuel utilisateur

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuel utilisateur

Factory

Factory M3340 Manuel utilisateur

Shop-Vac

Shop-Vac VN92 SERIES Manuel utilisateur
