Silvercrest SRR 3.7 D5 Manuel utilisateur
IAN 277761
ROTARY SHAVER SRR 3.7 D5
ROTARY SHAVER
Operating instructions ROTERENDE SHAVER
Betjeningsvejledning
ROTEREND SCHEERAPPARAAT
Gebruiksaanwijzing
RASOIR À TÊTES ROTATIVES
Mode d‘emploi
ROTATIONSRASIERER
Bedienungsanleitung
GB/IE/NI Operating instructions Page 1
DK Betjeningsvejledning Side 25
FR/BE Mode d'emploi Page 49
NL/BE Gebruiksaanwijzing Pagina 73
DE/AT / CH Bedienungsanleitung Seite 97
Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.
Før du læser, vend siden med billeder frem og bliv bekendt med alle appara-
tets funktioner.
Avant de lire le mode d'emploi, ouvrez la page contenant les illustrations et
familiarisez-vous ensuite avec toutes les fonctions de l'appareil.
Vouw vóór het lezen de pagina met de afbeeldingen open en maak u
vertrouwd met alle functies van het apparaat.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.
A
B
SRR 3.7 D5 GB│IE│NI │ 1 ■
Contents
Introduction ...................................2
Intended use ..................................2
Package contents ..............................2
Description of the appliance......................3
Technical data .................................4
Safety instructions..............................5
Charging the rechargeable
battery with the charger .......................10
Charging the rechargeable
battery without the charger.....................11
Cordless shaving ..............................12
Shaving using the mains adapter ................13
Trimmer/long hair trimmer .....................13
Travellock...................................14
Cleaning and care .............................15
Cleaning with the brush .................................15
Cleaning under running water ............................16
Thorough cleaning .....................................17
Storage .....................................18
Disposal .....................................19
Ordering spare parts ..........................20
Kompernass Handels GmbH warranty............21
Service ..............................................23
Importer.............................................23
SRR 3.7 D5
■ 2 │ GB│IE│NI
Introduction
Congratulations on the purchase of your new device.
You have selected a high-quality product. The operating instructions are
part of this product. They contain important information on safety,
usage and disposal. Before using the product, familiarise yourself
with all handling and safety guidelines. Use the product only as
described and for the range of applications specified. Please also
pass these operating instructions on to any future owner.
Intended use
This appliance is intended exclusively for shaving and trimming
human hair.
This appliance is intended solely for use in private households.
Do not use it for commercial applications.
All other uses are deemed to be improper and may result in property
damage or even in personal injury.
Package contents
▯ Shaver with cutting unit
▯ Mains adapter
▯ Trimmer unit
▯ Protective cap
▯ Brush
▯ Charger
▯ Operating instructions
SRR 3.7 D5 GB│IE│NI │ 3 ■
NOTE
Check contents for completeness and damage immediately
after unpacking. Contact Customer Services if necessary.
Description of the appliance
Figure A (front fold-out page):
Drive shaft
Cutting unit
Shaving heads
Connector
On/Off switch
Trimmer unit
Long hair trimmer
Symbol (battery charge indicator)
Symbol (charging)
Symbol (locked)
-Charging socket
Figure B (rear fold-out page):
3Connector
!Mains adapter
.Brush
0Protective cap
6Charger
1Connector (charger)
%Charging socket (charger)
SRR 3.7 D5
■ 4 │ GB│IE│NI
Technical data
Appliance
Input voltage: 5 V (direct current)
Input current: 1000 mA
Battery: 3.7 V/800 mAh Li-ion battery
Environmental temperature: 5°C up to 35°C
Charging time: approx. 60 minutes
Operating time with fully
charged battery: approx. 60 minutes
Protection rating: IPX 4: Protection against water splashes
from any direction.
Mains adapter (type PTB-050100EU)
Input voltage: 100-240 V ∼, 50/60 Hz
Output voltage: 5 V (direct current)
Input current: 0,2 A
Output current: 1000 mA
Protection rating: IP 20: Protection against ingress of solid
foreign objects with a diameter
of > 12.5 mm / No protection
against water.
Protection class: II /
Polarity of the plug:
Enclosed safety transformer:
Switched-mode power supply:
SRR 3.7 D5 GB│IE│NI │ 5 ■
Safety instructions
DANGER – RISK OF ELECTRIC SHOCK!
► Prior to use, check the appliance for visible
external damage. Never operate an ap-
pliance that is damaged. There is a risk of
electrocution.
► The appliance may no longer be used if
there is any damage to the cable, to the
mains adapter, the housing or any other
components.
► Pull the mains adapter from the mains
power socket
— if a defect occurs,
— before cleaning the appliance,
— if you do not intend using the appliance
for long periods,
— after every use.a
When doing so, pull the mains adapter
itself and not the cable.
► Never submerge the appliance or the cable
with mains adapter in water or other liquids.
SRR 3.7 D5
■ 6 │ GB│IE│NI
DANGER –
RISK OF ELECTRIC SHOCK!
► If the appliance drops into water, pull the
mains adapter out of the power socket
before you reach into the water.
► Never touch the mains adapter with wet
hands, especially when plugging it in or
unplugging it. Risk of electrical shock!
► Check the mains adapter and appliance
regularly for possible mechanical defects.
► Ensure that the cable does not get jammed
in cupboard doors or pulled over hot
surfaces. If this occurs, the cable insulation
may be damaged.
► The installation of a residual current circuit
breaker with a rated tripping current of no
more than 30 mA offers further protection
from electric shocks. Have the installation
carried out only by a qualified electrician.
