Sigmann DELTA SD160BTex Manuel utilisateur

Sigmann DELTA GmbH Tel. 06268-92899-73 Commercial Register Volksbank Kraichgau

Hauptstraße 53 Fax 06268-92899-74 Mannheim HRB 703603 BLZ 672 922 00 Konto 55258007

D-74928 Hüffenhardt info@sigmann-delta.de Manager S.W.I.F.T.-Code GENO DE 61SSH

UstIDNr: DE257944309 http://www.sigmann-delta.de Joachim Kraus IBAN DE31 6729 2200 0055 2580 07

Date: 10.10.2013

Operating Instructions

Bluetooth Handheld Scanner SD160BTex

Type SD.113.000.0x

Operating Instructions_SD160BTex_002

Table of contents

1 Important Notes on the Operating Instructions 2

1.1. Safety Information ........................................................................................ 2

1.2 Notes on the Operating Instructions ........................................................................................ 3

1.3 General Notes of Caution ........................................................................................ 4

2 Product Information 6

2.1 Manufacturer ........................................................................................ 6

2.2 Explosion Protection ........................................................................................ 6

2.3 Technical Data Handheld Scanner ........................................................................................ 6

2.4 Technical Data Base Charging Station ........................................................................................ 7

2.5 Type Numbers ........................................................................................ 8

2.6 Serial Number ........................................................................................ 8

2.7 Application ........................................................................................ 8

3 System Assembly 9

3.1 System assembly 1 –Explosion-protected base charging station ..................................... 9

3.2 System assembly 2 –Non-explosion-protected base charging station ...................................... 10

3.3 Cable range in system assembly 1 ..................................... 11

3.4 Cable range in system assembly 2 ..................................... 11

4 Step-by-step guide on installation and operation 11

4.1 Step 1: Preparation handheld scanner SD160BTex .......................................... 11

4.2 Step 2: Using base charging station for system 1 .......................................... 12

4.3 Step 2: Using base charging station for system 2 .......................................... 13

4.4 Step 3: Pin assignment power supply SDVM125ex RS232 .......................................... 14

4.5 Step 3: Pin assignment power supply SDVM125ex USB .......................................... 16

5 Attachment 18

5.1 EG-Type Examination Certificate: SD160BTex and SD160BTex base charging station ........... 18

5.2 EG-Type Examination Certificate: SDVM125ex ................................ 20

6 Contact 24

Operating Instructions_SD160BTex_002 2

1 Important notes on the Operating Instructions

1.1 Safety information

Warnings are highlighted by a special symbol and a different font colour:

Danger

Non-compliance may result in life-threatening situations.

This warning must be heeded.

Warning

This type of warning concerns dangerous situations that may result in minor injuries.

Info

Important and helpful notes and information.

Operating Instructions_SD160BTex_002 3

1.2 Notes on the Operating Instructions

Before starting up the equipment please read the Manual thoroughly.

The Operating Instructions contain important information on functionality as well as safety rules. If these

are not heeded, normal operations within hazardous areas cannot be guaranteed.

The notes contained in this manual are important for starting up and operating the product.

These instructions may be updated at any time. Sigmann DELTA GmbH reserves the right to make changes to

this document.

Before they use the product, users must ensure that they have the most up-to-date version of the operating in-

structions.

To make sure this is the case, please check Sigmann DELTA's website at www.Sigmann-DELTA.de or contact

one of the company's staff.

The drawings contained in these operating instructions are for illustration purposes only and may differ somewhat

from the actual design.

No changes may be made to the device that were not intended or approved

by Sigmann DELTA.

If the handheld scanner is not used properly, the operating permission for hazardous areas may lapse for the

device in question.

Non-adherence to the instructions will void any warranty.

For the full commission of the SD160BTex handheld scanner the programming information contained in

the manual issued by SICK AG (www.SICK.com) are also required.

Operating Instructions_SD160BTex_002 4

1.3 General notes of caution

Caution / Notes

The devices may only be operated when fully assembled.

In hazardous areas the devices must not be wiped or cleaned with a dry cloth.

The device must be switched off immediately if it is likely that as a consequence

of damaging impact or general peculiarities the device can no longer be safely

operated. (e.g. ingress of water or other fluids, temperatures outside of the

specified range,...)

General statutory requirements or health and safety rules and accident preven-

tion guidelines and environmental laws must be adhered to (e.g. the German

Occupational Health and Safety regulation).

Users must not open the device.

Users must not make any changes to the device. Components may not be ex-

changed or replaced. If non-specified components are used, explosion protec-

tion is no longer guaranteed.

Ensure safe handling with firm footing and sufficient room for movement.

If the enclosure is in any way damaged the device must be removed from the

hazardous area immediately.

In accordance with IEC 60079-19 and IEC 60079-17, operators of electrical

installation in hazardous areas are obliged to have them serviced by qualified

electricians.

Do not insert any sharp objects into the enclosure or any other openings of the

handheld barcode scanner. Any openings at the device may not be covered or

blocked.

The device and any accessories must be properly disposed of, i.e. as legally

specified, for example by a certified company.

Notes on installation

Electrical plants are subject to certain regulations concerning installation and

operation (e.g. RL 99/92/EG, RL 94/9EG, or the national rules such as

IEC 60 079-14 and VDE 0100).

In the hazardous area it is the operator's responsibility to carry out any repair

and maintenance in compliance with applicable rules.

Operating Instructions_SD160BTex_002 5

Caution

on laser devices

Devices fitted with laser fall under standards US 21 CFR 1040.10 and EN

60825-1. The laser's classification is stated on a plate affixed to the device.

Class 1 lasers are deemed inherently safe during normal use, but users must

not look directly into the light source. The following declaration is required by

American and international laws:

Usage of control elements, adaptations or the use of procedures that differ from

these instructions may result in a dangerous exposure to laser beams.

Class 2 lasers use a visible low-voltage LED. As with any source of bright light,

such as the sun, the user should avoid looking directly into the light. Brief expo-

sure to a class 2 laser is deemed not dangerous.

Maintenance

Provided the device is operated and assembled according to instructions and

the ambient requirements are being met continuous maintenance is not neces-

sary.

Servicing

Operators of electric equipment in hazardous areas are obliged to have them

serviced by qualified electricians (IEC 60079-19 and IEC 60079-17).

Repairs

Repairs may only be carried out by the manufacturer or by persons trained and

commissioned for this purpose by the manufacturer.

The device is closed ex-factory. It may only be opened in the factory by specifically trained personnel.

Software installation

For instructions on how to install the software at the PC please refer to the

manual issued by SICK.

Operation

Before operating the device you must ensure that all necessary components are

available.

Operating Instructions_SD160BTex_002 6

2 Product information

2.1 Manufacturer

Sigmann DELTA GmbH

Hauptstraße 53

74928 Hüffenhardt

Germany

Device

SD160BTex type: SD.113.0000.0x

2.2 Explosion

protection

II 2G Ex ib IIC T4

II 2G Ex ib IIC T4 Gb

II 2D Ex ib IIIC T135C

II 2D Ex ib IIIC T135C Db

Protection category

IP65

2.3 Technical Data

Handheld scanner

Nominal values

Light source: Visible red light, 630nm

Ambient temperature: -20 °C to +50 °C

Test certificate: IBExU 12 ATEX 1162

Bluetooth: V2.1 EDR

Weight: 260g inc. batteries

Bluetooth range up to 30 m

Operating Instructions_SD160BTex_002 7

2.4 Technical Data

Base charging station

Ambient temperature

Base charging station

-20°C to +50°C

Bluetooth

Base charging station

Bluetooth V 2.1 EDR, Class 2

2.4 ... 2.4835 GHz (ISM band)

Terminal assignment

(Base charging station)

USB cable

USB/D+ green

USB/D- white

GND black

+UB brown

RS 232 cable

RS 232-TXD white

GND brown

+UB yellow

Operation

Base charging station

The base charching station may be operated in hazardous areas. Its purpose is to re-

ceive data captured by the associated handheld scanner (1D bar codes or 2D stacked

codes) via Bluetooth.

Nominal values of the hazard-

ous base charging station

maximum input voltage Ui 4.9 V (SD.Z10.0010.xx / SD.Z10.0011.xx)

5.6 V (SD.Z.10.0007.xx)

maximum input current li 490 mA

maximum input power Pi 1.25 W

maximum internal inductance Li: negligible

maximum internal capacitance Ci 109 µF (SD.Z10.0010.xx/ SD.Z10.0011.xx)

46 µF (SD.Z.10.0007.xx)

Nominal values

of the non hazardous base

charging station

Operating voltage U = 5V

Power requirement I = 85 mA in standby mode

Operating Instructions_SD160BTex_002 8

2.5 Type numbers

SD.113.0000.00

SD 113.0000.01

Standard version

Stacked PDF version

Both are for use with accu SD.Z10.0018.00

and a base charging station of your choice (see below)

Explosion-protected connection cable USB SD.Z10.0011.0x

/ RS232 SD.Z10.0010.0x

or a non-explosion-protected connection cable USB SD.Z10.0013.0x

/ RS232 SD.Z10.0012.0x

and a power supply SDVM125ex, depending on voltage and interface

SD.211.XX11.00

SD.114.0000.00

Explosion-protected base charging station

SD.Z10.0015.00

Non-explosion-protected base charging station

SD.Z10.0014.00

Non-explosion-protected charging station without Bluetooth

2.6 Serial numbers

Serial key: year of manufactur serial number

2 numbers 4 numbers

Example: 130001

2.7 Application

The scanner is a handheld device.

Its purpose is the portable capture and direct transfer of data in hazardous areas. The device has been designed

for use in hazardous areas zones 1 and 21.
