Siemens CF62 Guide de configuration

Company Confidential s Com

Page 1of 10

Service Repair Documentation Level 2.5 - CF62, CF62R, CF63

Service Repair Documentation

Level 2.5 - CF62, CF62R, CF63,

Release Date Department Notes to change

1.0 23.03.2004 ICM MP CCQ GRM T New document

2.0 12.05.2004 ICM MP CCQ GRM T CF63 added

2.1 03.06.2004 ICM MP CCQ GRM T Changes in procedure

2.2 10.12.2004 ICM MP CCQ GRM T VIBRA added

2.3 22.02.2005 COM MD CC GRM T CF62R added

Company Confidential s Com

Page 2of 10

Service Repair Documentation Level 2.5 - CF62, CF62R, CF63

Introduction

This Service Repair Documentation is intended to carry out repairs on Siemens repair level

2.5. The described failures shall be repaired in Siemens authorized local workshops.only

All repairs have to be carried out in an ESD protected environment and with ESD protected

equipment/tools. For all activities the international ESD regulations have to be considered.

Assembling/disassembling has to be done according to the latest CF62, CF62R, CF63

Level 2 repair documentation. It has to be ensured that every repaired mobile Phone is

checked according to the latest released General Test Instruction document (both

documents are available in the Technical Support section of the C-market).

Check at least weekly C-market for updates and consider all CF62, CF63 related Customer

Care Information

CF62 Partnumber on IMEI label: S30880-S6050-#xxx

CF62R Partnumber on IMEI label: S30880-S6040-#xxx

CF63 Partnumber on IMEI label: S30880-S6060-#xxx

, while # may be any letter (A-Z) and xxx may be any number from 100, 101, 102....

If you have any questions regarding the repair procedures or technical questions spare not

hesitate to contact our technical support team in Kamp-Lintfort, Germany:

Scrap Handling: All Scrap information given in this manual

are related to the SCRAP-Rules and instructions.

Attention: Consider soldering rules, avoid excessive heat

Tel.: +49 2842 95 4666

Fax: +49 2842 95 4302

e-mail: [email protected]

Company Confidential s Com

Page 3of 10

Service Repair Documentation Level 2.5 - CF62, CF62R, CF63

Table of Content

1CF62, CF62 R, CF63 board layout................................................................................................4

2Connector SIM Card Reader .........................................................................................................5

3Connector IO Jack.........................................................................................................................6

4Connector Board to Board.............................................................................................................7

5Connector Battery .........................................................................................................................8

6LED Keypad Backlight and LED Keypad Magic Ring....................................................................9

7VIBRA TRANSISTOR .................................................................................................................10

Company Confidential s Com

Page 4of 10

Service Repair Documentation Level 2.5 - CF62, CF62R, CF63

1 CF62, CF62 R, CF63 board layout

Jigs, Tools and Working materials for all described repairs:

-hot air blower

-soldering gun

-tweezers

-flux

-solder

LED

LED_Keypad_Magic_Ring

LED

LED_Keypad_Backlight

Connector

BATTERY

Connector

BOARD TO BOARD

VIBRA

Transistor V211

Connector

IO JACK

Connector

SIM CARD READER

Company Confidential s Com

Page 5of 10

Service Repair Documentation Level 2.5 - CF62, CF62R, CF63

2 Connector SIM Card Reader

Fault Symptoms

Customer: GRT:

Handset does not accept SIM card SIM Card Problems

SIM Card Problems

Watch for oxidation and

damaged pads of the SIM

card reader

SCRAP has to be

send separately to

WSC

not okay

okay

Check the status of the

SIM card reader visually

okay

not okay - check for twisted or

bended contacts

- check for dry joints

Level 2 Repair

Exchange

SIM Card reader

Use the resistor test

function of a multimeter

to check connection

between spring

contacts and soldering

contacts. The value

must be ~0Ω

not okay okay

Connector SIM Card Reader

Use soldering iron to remove defective component. Avoid excessive heat! Watch surrounding components!

Resolder new component afterwards.

E-commerce order number: L36334-Z97-C335

Soldering temperature: 240 - 255°C

IRIS Diagnose Code: 43300 Interface/SIM Cardreader/Mechanical Damage

Company Confidential s Com

Page 6of 10

Service Repair Documentation Level 2.5 - CF62, CF62R, CF63

3 Connector IO Jack

Fault Symptoms

Customer: GRT:

Charging Problems No connection to GRT

Problems with external loudspeaker or microphone when using a car kit Tbd.

Problems with accessories connected at the IO connector

IO connector Problems

Connector IO Jack

Use soldering iron to remove defective component. Avoid excessive heat! Watch surrounding components!

Resolder new component afterwards.

E-commerce order number: L36334-Z93-C303

Soldering temperature: 240 - 255°C

IRIS Diagnose Code: 46100 Interface/Charging Connector/Mechanical Damage

47300 Interface/Data Interface/Mechanical Damage

4B100 Interface/Headset Connector/Mechanical Damage

Exchange

IO connector

Check the status of the

IO connector visually

okay

not okay

Level 2 Repair

- check for twisted or

bended contacts

- check for dry joints

okay

Use the resistor test

function of a multimeter

to check connection

between spring

contacts and soldering

contacts. The value

must be ~0Ω

Watch for oxidation and

damaged pads of the

IO connector

not okay

okay

Clean

IO connector

Check for dust inside

the IO connector

okay

not okay

SCRAP has to be

send separately to

WSC

not okay

Company Confidential s Com

Page 7of 10

Service Repair Documentation Level 2.5 - CF62, CF62R, CF63

4 Connector Board to Board

Fault Symptoms

Customer: GRT:

Display problems, like missing lines or columns on the LCD or

display contrast problems or illumination problems

Display problems

B to B connector Problems

Watch for oxidation and

damaged pads of the BtoB

connector

SCRAP has to be

send separately to

WSC

not okay

okay

Check the status of the

BtoB connector visually

okay

not okay - check for twisted or

bended contacts

- check for dry joints

Level 2 Repair

Exchange

BtoB connector

Connector Board to Board

Use hot air blower to remove defective component. Avoid excessive heat! Watch surrounding components!

Resolder new component afterwards.

E-commerce order number: L36334-Z97-C341

Soldering temperature: 240 - 255°C

IRIS Diagnose Code: 2A100 Display/Outer(Claimshell)/Performance

2A100 Display/Outer(Claimshell)/ Background Illumination

72110 Acoustics/Receiving/Earcap/No Function

72170 Acoustics/Receiving/Earcap/Low Voice Level

75100 Acoustics/Vibra/No Function

Company Confidential s Com

Page 8of 10

Service Repair Documentation Level 2.5 - CF62, CF62R, CF63

5 Connector Battery

Fault Symptoms

Customer: GRT:

Mobile does not switch on No connection to GRT

Battery connector

Problems

Check the status of the

battery connector visually

okay

not okay

Level 2 Repair

Exchange

Battery connector

- check for twisted or

bended contacts

- check for dry joints

Use the resistor test

function of a multimeter

to check connection

between spring

contacts and soldering

contacts. The value

must be ~0Ω

Watch for oxidation and

damaged pads of the battery

connector

not okay okay

okay

SCRAP has to be

send separately to

WSC

not okay

Connector BATTERY

Use hot air blower to remove defective component. Avoid excessive heat! Watch surrounding components!

Resolder new component afterwards.

E-commerce order number: L36334-Z97-C336

Soldering temperature: 240 - 255°C

IRIS Diagnose Code: 13000 Battery/Mechanical Damage

Company Confidential s Com

Page 9of 10

Service Repair Documentation Level 2.5 - CF62, CF62R, CF63

6 LED Keypad Backlight and LED Keypad Magic Ring

Fault Symptoms

Customer: GRT:

Keypad illumination does not work Tbd.

LED’s Problems

Check the status of the

LED's visually

okay

not okay

Level 2 Repair

Exchange

Keypad LED

SCRAP has to be

send separately to

WSC

- check for dry joints

Watch for oxidation and

damaged pads of the LED’S

not okay

Use the diode test

function of a multimeter

to check the status of

the diode. The typical

voltage drop on the

diode is 1.7 V when

testing the diode

function with the

multimeter.

okay

not okay

LED Keypad Backlight

Use soldering iron to remove defective component. Avoid excessive heat! Watch surrounding components!

Resolder new component afterwards. Attention: Remove Metal Dome Sheet before!!!

E-commerce order number: CF62/CF63: L36840-L2095-D670 CF62R: L36840-L2083-D670

Soldering temperature: 240 - 255°C

IRIS Diagnose Code: 36000 Keys/Illumination

LED Keypad Magic Ring

Use soldering iron to remove defective component. Avoid excessive heat! Watch surrounding components!

Resolder new component afterwards.

E-commerce order number: CF62/CF63: L36840-L2055-D670 CF62R: L36197-F5005-F782

Soldering temperature: 240 - 255°C

IRIS Diagnose Code: 36000 Keys/Illumination

Company Confidential s Com

Page 10 of 10

Service Repair Documentation Level 2.5 - CF62, CF62R, CF63

7 VIBRA TRANSISTOR

Fault Symptoms

Customer: GRT:

Vibra permanent works Tbd.

Vibra

Problems

Check the status of the

Vibra Transistor visually /

electrically

okay

not okay

Level 2 Repair

Exchange

Vibra Transistor

- check for twisted or

bended contacts

- check for dry joints

Watch for oxidation and

damaged pads of the Vibra

Transistor

not okay

Perform the resistor test

with an Ω-multimeter.

Check the connection

between the component

parts and the soldering

contacts. The value

must be 0 Ω.

okay

SCRAP has to be

send separately to

WSC

not okay

VIBRA Transistor (V211)

Use hot air blower to remove defective component. Avoid excessive heat! Watch surrounding components!

Resolder new component afterwards.

E-commerce order number: L36810-C6144-D670

Soldering temperature: 240 - 255°C

IRIS Diagnose Code: 75400 Acoustics / Vibra / Electrical Damage

Autres manuels pour CF62

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Siemens Téléphone

Siemens

Siemens A30853 Manuel utilisateur

Siemens

Siemens HiPath 8000 Manuel utilisateur

Siemens

Siemens Gigaset SX670 isdn Manuel utilisateur

Siemens

Siemens OpenScape Voice Manuel utilisateur

Siemens

Siemens Gigaset C59H Manuel utilisateur

Siemens

Siemens HIPATH 2000 Manuel utilisateur

Siemens

Siemens euroset 5040 Manuel utilisateur

Siemens

Siemens HiPath 3000 V3.0 or later Gigaset M1... Manuel utilisateur

Siemens

Siemens optiPoint 410 entry Manuel d'utilisation et d'entretien

Siemens

Siemens Gigaset 5030 Manuel utilisateur

Siemens

Siemens OpenStage 5 Manuel de l'opérateur

Siemens

Siemens Maestro 300 Manuel utilisateur

Siemens

Siemens EUROSET 805S Manuel utilisateur

Siemens

Siemens hicom 150 H optiset E standard Manuel utilisateur

Siemens

Siemens Hicom 150 E optiset E standard Manuel utilisateur

Siemens

Siemens Gigaset SX303isdn Manuel utilisateur

Siemens

Siemens HIPATH 2000 Manuel utilisateur

Siemens

Siemens HIPATH HIPATH 3000 Manuel utilisateur

Siemens

Siemens Gigaset DL500A Manuel utilisateur

Siemens

Siemens Gigaset S450 IP Manuel utilisateur

Siemens

Siemens Hicom 300 optiset E Standard Manuel utilisateur

Siemens

Siemens Gigaset A100 Manuel utilisateur

Siemens

Siemens Gigaset 8825 Manuel utilisateur

Siemens

Siemens 2000C pocket Manuel utilisateur

Manuels Téléphone populaires d'autres marques

GE 2-9480 Manuel utilisateur

Geemarc

Geemarc PHOTOPHONE 155 Manuel utilisateur

D-Link

D-Link DWR-720/PW Manuel utilisateur

Interquartz

Interquartz Gemini IQ333 Manuel utilisateur

SSS Siedle

SSS Siedle HT 840-0 Manuel utilisateur

Motorola

Motorola TITANIUM Manuel utilisateur

Panasonic

Panasonic ICX Manuel utilisateur

LG H870DS Manuel utilisateur

Samsung

Samsung GT-I9500 Manuel utilisateur

AT&T

AT&T Trimline 205 Manuel utilisateur

Selta

Selta zenyth 600 Manuel utilisateur

Doro

Doro AFTI 20 Manuel utilisateur

UNIQCELL

UNIQCELL A1 Manuel utilisateur

Panasonic

Panasonic KX Series Manuel utilisateur

Jabra

Jabra SP5050 - Bluetooth hands-free Speakerphone Manuel utilisateur

BT Decor 425 Manuel utilisateur

NEC

NEC SV8500 Manuel utilisateur

Teledex

Teledex PEARL Manuel utilisateur
