Installation Instructions

Document No. 565-714

October 31, 2009

Veeder-Root Driver for PXC Modular

These installation instructions cover the connection of

the Veeder-Root Driver or the Veeder-Root Enterprise

Driver to the Veeder-Root system only. For hardware

installation of the PXC Modular, see PXC Modular

Series Installation and Quick Start (553-638).

Product Description

The Veeder-Root Driver enables communication

between the APOGEE®Automation System and the

Veeder-Root system.

Product Numbers

PXC00-PE96.A PXC Modular RS-485 or

Ethernet ALN, 96 FLN nodes

PXC00-E96.A PXC Modular with BACnet/IP

ALN and BACnet MS/TP ALN,

96 FLN nodes

PXC100-PE96.A PXC Modular RS-485 or

Ethernet ALN, TX-I/O Support,

96 FLN nodes

PXC100-E96.A PXC Modular BACnet/IP ALN

and BACnet MS/TP ALN, TX-I/O

Support, 96 FLN nodes

PXX-485.3 Expansion Module, three

RS-485 FLN connections

LSM-INT-VR Veeder-Root PXC Modular

Driver License

LSM-INT-VRE Veeder-Root Enterprise PXC

ModularDriverLicense

Accessories

538-670 Trunk Interface II, 115V

538-675 Trunk Interface II, 230V

Warning/Caution Notations

WARNING:

Personal injury/loss of life may occur if you

do not follow the procedures as speciﬁed.

CAUTION:

Equipment damage or loss of data may

occur if you do not follow the procedures

as speciﬁed.

Expected Installation Times

The expected installation time is 30 minutes.

Required Tools and Materials

• Flat-blade screwdriver (1/8-inch blade width).

• Wire strippers.

• Cabling and connectors. See the Connecting

the Veeder-Root Driver to the Veeder-Root

Devicessection.

CAUTION:

Always wear an electro-static discharge

wrist strap and discharge accumulated

static before touching ﬁeld panel

components.

Prerequisites

• Driver hardware is installed according to its

respective installation instructions.

• FLN Termination blocks installed, if any.

Depending on the type of installation, other

prerequisites may have to be completed.

Item Number: 565-714, Rev. AA Page 1 of 4

Document No. 565-714

Installation Instructions

October 31, 2009

Connecting the Veeder-Root Driver

to the Veeder-Root Devices

Follow these steps to connect the Veeder-Root Driver

to the Veeder-Root system:

1. Make cables per diagram in Figure 1.

2. Connect cables per diagram in Figure 1.

Page 2 of 4 Siemens Industry, Inc.

Document No. 565-714

Installation Instructions

October 31, 2009

RS-485 TRUNK CABLE

(MAX 4000 ft / 1200 m;

STANDARD 24 AWG LOW CAPACITANCE)

TRUNK INTERFACE II

VEEDER-ROOT

TLS CONTROLLER

TAPE BACK

SHIELD

RS-232 25-PIN MALE TO

25-PIN MALE CABLE

(MAX 50 ft)

RS-232 PORT

(25-PIN FEMALE)

RS-232 PORT

(25-PIN FEMALE)

FLN

GROUND WIRE TO EARTH

(P/N 538-583)

POWER PACK

POWER

DRIVER

GW0768R3

Figure 1. Connecting the Veeder-Root Driver to the Veeder-Root Devices.

Siemens Industry, Inc. Page 3 of 4

Document No. 565-714

Installation Instructions

October 31, 2009

Information in this document is based on speciﬁcations believed correct at the time of publication. The right is reserved to make changes as

design improvements are introduced. Product or company names mentioned herein may be the trademarks of their respective owners.

Siemens Industry, Inc. Your feedback is important to us. If you have Document No. 565-714

1000 Deerﬁeld Parkway comments about this document, send them to Country of Origin: US

Buffalo Grove, IL 60089-4513 SBT_technical.editor[email protected]. Page 4 of 4

U.S.A.
