Siemens SIMATIC RTLS Manuel utilisateur

SIMATIC RTLS PCB OEM AC

SIMATIC RTLS

Localization systems

SIMATIC RTLS PCB OEM AC

Operating Instructions

03/2020

C79000

-G8976-C519-03

Introduction

Device description

Installation & Operation

Technical specifications

Approvals

Siemens AG

Digital Industries

Postfach 48 48

90026 NÜRNBERG

GERMANY

C79000-G8976-C519-03

Ⓟ

02/2020 Subject to change

Legal information

Warning notice system

This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent

damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert

symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are

graded according to the degree of danger.

DANGER

indicates that death or severe personal injury will result if proper precautions are not taken.

WARNING

indicates that death or severe personal injury may result if proper precautions are not taken.

CAUTION

indicates that minor personal injury can result if proper precautions are not taken.

NOTICE

indicates that property damage can result if proper precautions are not taken.

If more than one degree of danger is present, the warning notice representing the highest degree of danger will

be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to

property damage.

Qualified Personnel

The product/system described in this documentation may be operated only by personnel qualified for the specific

task in accordance with the relevant documentation, in particular its warning notices and safety instructions.

Qualified personnel are those who, based on their training and experience, are capable of identifying risks and

avoiding potential hazards when working with these products/systems.

Proper use of Siemens products

Note the following:

WARNING

Siemens products may only be used for the applications described in the catalog and in the relevant technical

documentation. If products and components from other manufacturers are used, these must be recommended

or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and

maintenance are required to ensure that the products operate safely and without any problems. The permissible

ambient conditions must be complied with. The information in the relevant documentation must be observed.

Trademarks

All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication

may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.

Disclaimer of Liability

We have reviewed the contents of this publication to ensure consistency with the hardware and software

described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the

information in this publication is reviewed regularly and any necessary corrections are included in subsequent

editions.

SIMATIC RTLS PCB OEM AC

Operating Instructions, 03/2020, C79000-G8976-C519-03 3

Table of contents

1 Introduction............................................................................................................................................. 5

2 Device description................................................................................................................................... 9

2.1 Safety notices ...........................................................................................................................9

2.2 Order data RTLS PCB OEM AC...............................................................................................9

2.3 Pin assignment .......................................................................................................................10

2.4 LED status indicator................................................................................................................10

2.5 Dimension drawing .................................................................................................................11

3 Installation & Operation......................................................................................................................... 13

3.1 Notes on installation................................................................................................................13

3.2 Cleaning and maintenance .....................................................................................................13

4 Technical specifications ........................................................................................................................ 15

5 Approvals.............................................................................................................................................. 17

Table of contents

SIMATIC RTLS PCB OEM AC

4Operating Instructions, 03/2020, C79000-G8976-C519-03

SIMATIC RTLS PCB OEM AC

Operating Instructions, 03/2020, C79000-G8976-C519-03 5

Introduction

Purpose of the Operating Instructions

These operating instructions support you when installing and connecting up the SIMATIC

RTLS PCB OEM AC device.

The configuration and the integration of the devices in a network are not described in these

operating instructions.

Validity of the Operating Instructions

These operating instructions apply to the following device variants:

●RTLS PCB OEM AC (CE; article number: 6GT2700-8DF00-0AX1)

●RTLS PCB OEM AC (FCC; article number: 6GT2700-8DF10-0AX1)

●RTLS PCB OEM AC (CMIIT; article number: 6GT2700-8DF20-0AX1)

●RTLS PCB OEM AC (IC; article number: 6GT2700-8DF30-0AX1)

Further documentation

The system manual "Commissioning SIMATIC RTLS" provides information on other

SIMATIC RTLS products that you can operate together with the devices in this product line

in an Industrial Ethernet network.

You can find the system manual at the following link:

(https://support.industry.siemens.com/cs/us/en/ps/25277)

Trademarks

The following and possibly other names not identified by the registered trademark sign ®are

registered trademarks of Siemens AG:

SIMATIC RTLS

Introduction

SIMATIC RTLS PCB OEM AC

6Operating Instructions, 03/2020, C79000-G8976-C519-03

Industry Online Support

In addition to the product documentation, the comprehensive online information platform of

Siemens Industry Online Support offers support at the following Internet address:

(https://support.industry.siemens.com/cs/start?lc=en-US)

Apart from news, there you will also find:

●Project information: Manuals, FAQs, downloads, application examples etc.

●Contacts, Technical Forum

●The option submitting a support query: (https://support.industry.siemens.com/My/us/en/)

●Our service offer:

Right across our products and systems, we provide numerous services that support you

in every phase of the life of your machine or system - from planning and implementation

to commissioning, through to maintenance and modernization.

You will find contact information on the Internet at the following address:

(https://www.automation.siemens.com/aspa_app/?ci=yes&lang=en)

SITRAIN - Training for Industry

The training offer includes more than 300 courses on basic topics, extended knowledge and

special knowledge as well as advanced training for individual sectors - available at more

than 130 locations. Courses can also be organized individually and held locally at your

location.

You will find detailed information on the training curriculum and how to contact our customer

consultants at the following Internet address:

(https://new.siemens.com/global/en/products/services/industry/sitrain/personal.html)

Security information

Siemens provides products and solutions with industrial security functions that support the

secure operation of plants, systems, machines and networks.

In order to protect plants, systems, machines and networks against cyber threats, it is

necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial

security concept. Siemens’ products and solutions constitute one element of such a concept.

Customers are responsible for preventing unauthorized access to their plants, systems,

machines and networks. Such systems, machines and components should only be

connected to an enterprise network or the internet if and to the extent such a connection is

necessary and only when appropriate security measures (e.g. firewalls and/or network

segmentation) are in place.

For additional information on industrial security measures that may be implemented, please

visit: (https://new.siemens.com/global/en/company/topic-areas/future-of-

manufacturing/industrial-security.html)

Siemens’ products and solutions undergo continuous development to make them more

secure. Siemens strongly recommends that product updates are applied as soon as they are

available and that the latest product versions are used. Use of product versions that are no

longer supported, and failure to apply the latest updates may increase customers’ exposure

to cyber threats.

Introduction

SIMATIC RTLS PCB OEM AC

Operating Instructions, 03/2020, C79000-G8976-C519-03 7

To stay informed about product updates, subscribe to the Siemens Industrial Security RSS

Feed under: (https://support.industry.siemens.com/cs/us/en/ps/15247/pm)

Recycling and disposal

The products are low in harmful substances, can be recycled and meet the requirements of

the Directive 2012/19/EU for disposal of waste electrical and electronic equipment (WEEE).

Do not dispose of the products at public disposal sites.

For environmentally compliant recycling and disposal of your electronic waste, please

contact a company certified for the disposal of electronic waste or your Siemens

representative.

Note the different national regulations.

Introduction

SIMATIC RTLS PCB OEM AC

8Operating Instructions, 03/2020, C79000-G8976-C519-03

SIMATIC RTLS PCB OEM AC

Operating Instructions, 03/2020, C79000-G8976-C519-03 9

Device description

2.1 Safety notices

NOTICE

Avoid contact with the RTLS transponder

Avoid contact (e.g. with your hands) with the RTLS transponder in order to avoid

contamination of and resulting damage to the RTLS transponder.

NOTICE

Precautionary measures against electrostatic discharge

The RTLS transponder can be damaged by electrostatic discharge (ESD). Take suitable

precautionary measures when unpacking and operating the transponder to avoid damage.

2.2 Order data RTLS PCB OEM AC

Table 2- 1 Order data RTLS PCB OEM AC

Article number

SIMATIC RTLS PCB OEM AC CE

FCC

CMIIT

6GT2700-8DF00-0AX1

6GT2700-8DF10-0AX1

6GT2700-8DF20-0AX1

6GT2700-8DF30-0AX1

Device description

2.3 Pin assignment

SIMATIC RTLS PCB OEM AC

10 Operating Instructions, 03/2020, C79000-G8976-C519-03

2.3 Pin assignment

P2 socket

Type: JST SM02B-SRSS-TB

Description / Function

3.3 V supply voltage

GND

P1 connector

Internal interface for production and manufacturing test, do not use.

2.4 LED status indicator

The operating states of the transponder are indicated by the LEDs. The states can be off ,

on and flashing .

LED

Meaning

Flashes green every three seconds when the transponder is active

Is off when the transponder is inactive

Green and red LEDs light up for 1 second on system start

Flashes green every 0.1 seconds after a watchdog reset
