Siemens SINUMERIK 802D Supplément

SINUMERIK 802D

09.2001

Short Guide

User Documentation

Milling

ISO Dialect M

SINUMERIK 802D

Milling

ISO Dialect M

Short Guide

09.2001 Edition

Valid for

Control Software Version

SINUMERIK 802D 1

SINUMERIK® Documentation

Printing history

Brief details of this editiion and previous editions are listed

below.

The status of each edition already published is shown by

the code in the "Remarks" column.

Status code in the "Remarks" column:

A .... New documentation.

B .... Unrevised reprint with new order no.

C .... Revised edition with new status

Edition Order No. Remarks

09.01 6FC5698-1AA50-0BP0 A

This manual is included in the documentation on CD-ROM

(DOCONCD)

Edition Order No. Remarks

09.01 6FC5298-6CA00-0AG1 C

Trademarks

SIMATIC®, SIMATIC HMI®, SIMATIC NET®, SIROTEC®,

SINUMERIK®and SIMODRIVE®are registered trademarks of

the Siemens AG. Other product names used in this

documentation might be trademarks which, if used by third

parties, could infringe the rights of their owners.

Further information is available on the Internet under:

http://www.ad.siemens.de/sinumerik

This publication was produced with Win Word V8.0 and

Designer V7.0

Other functions not described in this document might be executable in the control. This

does not, however, represent an obligation to supply such functions with a new control

or when servicing.

Subject to change without prior notice.

The reproduction, transmission or use of this document or its contents is not permitted

without written authority. Offenders will be liable for damages. All rights, including

rights created by patent grant or registration of a utility model or design, are reserved.

SINUMERIK 802D Milling ISO Dialect M (ISF) - Edition 09.01

09.01 General

Introduction

How to use this document

This document is a short guide describing

all the important operating and programming steps.

For detailed descriptions of operating and programming the

SINUMERIK 802D, refer to:

•User Manual, Turning,

Order No. 6FC5698-2AA00-0BP0

•User Manual, Milling,

Order No. 6FC5698-2AA10-0BP0

Method of description

The method of description is as follows:

Operating

Prerequisite

Operating sequence

Programming

Programming the function

Meaning of the parameters

Descriptive picture with an example of a workpiece

SINUMERIK 802D Milling ISO Dialect M (ISF) - Edition 09.01

Table of Contents 09.01

Table of Contents

1. Setup 1-9

Activate ISO Dialect M, G291 .........................................1-10

Tool Offsets.....................................................................1-11

Enter Zero Offset ............................................................1-12

2. Create/Edit Program 2-13

Create/Open Program.....................................................2-14

Insert/Edit Block..............................................................2-15

Copy/Insert/Delete Block ................................................2-16

Block Search/Numbering................................................2-17

Start/Simulate Program...................................................2-18

3. Execute/Correct Program 3-19

Select/Trace Program.....................................................3-20

Correct Program .............................................................3-21

Block Search...................................................................3-22

4. Program Positional Data 4-23

Absolute Dimension, Incremental Dimension, G90/G91 4-24

Zero Offset, G54 to G59 .................................................4-25

Select the Working Plane, G17 to G19...........................4-26

5. Program Axis Motions 5-27

Rapid Traverse, G0.........................................................5-28

Linear Interpolation, G1..................................................5-29

Circular Interpolation, G2/G3..........................................5-30

Tapping, G74/G84 ..........................................................5-31

Polar Coordinates, G15/G16...........................................5-32

6. Tool Offsets 6-33

Call Tool..........................................................................6-34

Cutter Radius Path Offset, G41/G42 ..............................6-35

7. Program Preparatory Functions 7-37

Program Feed, G94/G95 ................................................7-38

Exact Stop, G9/G61........................................................7-39

Feed in Continuous-Path Mode, G64 .............................7-40

Program Spindle Motion .................................................7-41

Subroutine Call, M98/M99 ..............................................7-42

SINUMERIK 802D Milling ISO Dialect M (ISF) - Edition 09.01

09.01 Table of Contents

Table of Contents

8. Appendix 8-43

List of M Commands.......................................................8-44

List of the G Functions....................................................8-45

Cycle Alarms...................................................................8-47

Notes ..............................................................................8-48

SINUMERIK 802D Milling ISO Dialect M (ISF) - Edition 09.01

1. Setup

Activate ISO Dialect M, G291 1-10

Tool Offsets 1-11

Enter Zero Offset 1-12

1. Setup 09.01

SINUMERIK 802D Milling ISO Dialect M (ISF) - Edition 09.01

Activate ISO Dialect M, G291

N10 G291

G291 Activate ISO Dialect M NC programming

language

G290 Activate SIEMENS NC programming language

Machine OEM

Please observe the details supplied by the machine OEM

before switching on the power and when switching from

the Siemens programming language into the ISO dialect

programming language.

•The active tool,

•the tool offsets, and

•zero offsets

are retained when the ISO dialect programming language is

active.

ISO dialekt

The "ISO Dialect M" NC programming language is a second

programming language with a G Code command set.
