Building Technologies

Fire Safety & Security Product

DMS8000 MP4.xx

Connectivity Guide Add-on

NICE/RIVER Digital Video Recorders

Data and design subject to change without notice. / Supply subject to availability.

Siemens Building Technologies AG

We reserve all rights in this document and in the subject thereof. By acceptance of the document the recipient acknowledges these rights

and undertakes not to publish the document nor the subject thereof in full or in part, nor to make them available to any third party without our

prior express written authorization, nor to use it for any purpose other than for which it was delivered to him.

Building Technologies DMS8000 Video Connectivity Configuration Guide – NICE Add-on

Fire Safety & Security Products 06.2009

Table of contents

About this document...............................................................................................2

1Introduction.............................................................................................4

2Installation...............................................................................................4

2.1 Software installation..................................................................................4

2.1.1 Requirements .............................................................................4

2.1.2 Software License........................................................................4

2.1.3 NICE add-on installation.............................................................5

2.1.4 NICE add-on uninstall.................................................................5

3Configuration...........................................................................................6

3.1 Video integration.......................................................................................6

3.2 Video Network Manager ...........................................................................6

3.3 Video Drivers.............................................................................................7

3.4 Video components ....................................................................................7

3.5 NICE DVR configuration...........................................................................8

3.5.1 Configuration checklist ...............................................................8

3.5.2 Configuration procedure.............................................................8

3.6 Limitations...............................................................................................10

4Operations.............................................................................................11

4.1 MM8000 PTZ control panel.....................................................................11

Building Technologies DMS8000 Video Connectivity Configuration Guide –NICE Add-on

Fire Safety & Security Products 06.2009

About this document

Purpose of this document

This manual is a guide to the configuration procedures for the integration of NICE

and RIVER Video systems in MM8000 management stations.

This guide is part of the general DMS8000 documentation set which includes the

Composer Technical Manual, the other DMS8000 Connectivity Guides (Net-

work/Fire/Intrusion, Access Control, and OPC), and the Installation, Configuration,

and Commissioning manual (ICC) for each specific product.

Scope

This document applies to the MM8000 Management Station MP4.15 and higher.

Target audience

This documentation is intended for the following users:

- Project Managers

- Project Engineers

- Commissioning Personnel

Individuals performing the operations described in this manual are expected to

have prior expertise and training in the field of security, at least a moderate level of

familiarity with the Siemens Building Technologies product line, and experience

with the installation, configuration, and commissioning of security management

systems.

Documentation resource information

The DMS8000 Documentation Resource Information Guide document assem-

bles in one place important information regarding documentation resources. It con-

tains the following:

−Comprehensive definitions of the target audiences for FS DMS documents

−Training program information including the Siemens intranet link

−A complete list of all available DMS8000 documents

−Instructions for how to obtain a document via the Siemens intranet using the

STEP Documentation Repository System

−A map of relevant documents for each target audience group

−Customer Support links & resources

−A glossary containing definitions of all terms and acronyms used in

DMS8000 documentation

To access the DMS8000 Documentation Resource Information Guide (STEP

#A6V10089056), go to the link and follow the instructions below:

https://workspace.sbt.siemens.com/content/00001123/default.aspx

1. Click on the STEP WEB Client image:

2. Choose 04 Fire -3F from the Product Segment box and select Activate filter.

3. Select All in the Documents section of the Quick Search page and then

select Advanced Search.

4. Enter the document number in the Brochure No. field (e.g. A6V10089056) and

press Enter.

Building Technologies DMS8000 Video Connectivity Configuration Guide – NICE Add-on

Fire Safety & Security Products 06.2009

Operational and safety regulations

iBefore beginning work on the DMS8000 systems, you must have read and un-

derstood the related documents, in particular the Safety Regulations included in

the Installation, Configuration, and Commissioning manual (ICC) for each specific

product.

Liability disclaimer for damage or injuries

Before products are delivered, they are tested to ensure they function correctly

when used properly. Siemens disclaims all liability for damage or injuries caused

by the incorrect application of the instructions, or the disregard of danger adviso-

ries. This disclaimer applies in particular to personal injuries or damage caused by:

−Improper and/or incorrect use.

−Disregard of safety instructions in the documentation or on the product.

−Poor maintenance or a lack of maintenance.

We have checked the contents of this manual for agreement with the hardware and

software described. Since deviations cannot be precluded entirely, we cannot

guarantee full agreement. However, the data in this manual are reviewed regularly

and any necessary corrections included in subsequent editions. Suggestions for

improvement are welcome.

Modification index

Version Date Notes

A6V10097205_a_en 06.2009 Corresponds with DMS8000 MP4.20

A6V10097205_a_en 06.2008 Corresponds with DMS8000 MP4.15

Building Technologies DMS8000 Video Connectivity Configuration Guide –NICE Add-on

Fire Safety & Security Products 06.2009

1 Introduction

This is a guide to the software configuration procedures for the NICE and RIVER

Digital Video Recorders (DVR) in the MM8000 Management Station.

For a complete guide to the configuration process, this manual should be used with

the DMS8000 Network, Fire and Intrusion Guide, and with the Installation, Configu-

ration and Commissioning manual (ICC) of the specific product.

Video devices software version

The exact software version to use in the video device to integrate into the

DMS8000 systems is indicated in the latest MM8000 or MK8000 Release Notes.

2 Installation

The NICE/RIVER package is provided in the MM8000 product CD as add-on. It

can be installed using the standard Add-on Manager.

2.1 Software installation

2.1.1 Requirements

The NICE/RIVER application and driver software must be in place before installing

MM8000. In fact, the MM8000 setup provides for a customization of the (previously

installed) NICE/RIVER software environment. The list of the required applications

includes:

−PlayerComponentPackage.msi

−NiceVision API Package.exe

If the NICE/RIVER software is reinstalled or somehow modified, you can use the

Init_CCTV utility to customize the environment for MM8000 again.

→For information about Init_CCTV, refer to section 3.4.10 (Program Utilities) of

the MM8000 ICC, doc.no. A6V10062413_a_en.

2.1.2 Software License

MM8000 license must include specific items for the NICE/RIVER Add-on, for the

NS8016 driver, and for the required DVR units.

Therefore, the required license includes:

•WW8000 Composer (project configuration and download): Composer License

or Service key.

•MM8000 core, no. of subsystems.

This license should include the number of DVR units.

•NICE/RIVER add-on license.

•NS8016 driver license.

Other licenses, covering more MM8000 options, may or may not be used and they

are not related to the NICE/RIVER support.

Building Technologies DMS8000 Video Connectivity Configuration Guide – NICE Add-on

Fire Safety & Security Products 06.2009

2.1.3 NICE/RIVER add-on installation

The following are the installation procedures for the NICE/RIVER add-on module.

1. Start Add-on Manager; from the Windows Start menu, select the following:

Start ÆDMS8000 ÆTools ÆAdd-on Manager

The Add-on Manager window appears (Fig. 1).

2. In the list of add-ons Names, select Nice or River depending on which product

family you have to use. Note that the MM8000 Add-on software is the same for

the two.

Fig. 1 Add-on Manager Window

3. If your MM8000 installation includes a customized MM8000 internal account,

then deselect the default checkbox (Use default MM8000 User account) and

specify username and password.

→For information about the MM8000 Internal Account, refer to section 3.4.12

of the MM8000 ICC, doc.no. A6V10062413_a_en.

4. Click Install (or Update if a previous version is detected).

2.1.3.1 Multiple add-on’s installation

In general, it is possible to install multiple add-on packages and benefit of their

combined functionalities.

2.1.4 NICE/RIVER Add-on uninstall

The add-on module cannot be uninstalled.

Building Technologies DMS8000 Video Connectivity Configuration Guide –NICE Add-on

Fire Safety & Security Products 06.2009

3 Configuration

3.1 Video integration

The DMS8000 systems MM8000 and MK8000 can support the connection to

the following NICE video systems (and to the corresponding RIVER products

when applicable):

Manufacturer Model Device type

NICE NiceVision Alto Digital Video Recorder (DVR)

NICE NiceVision Pro Digital Video Recorder (DVR)

NICE NiceVision NVSat Digital Video Recorder (DVR)

NICE NiceVision NVR9000 Digital Video Recorder (DVR)

This integration allows providing advanced control capabilities as well as the

access to video images in MM8000 event treatment and navigation.

A detailed configuration guide for this video device is provided in this section.

3.2 Video Network Manager

The advanced video functionalities require a basic communication infrastructure

between MM8000/MK8000 and the CCTV units; this is actually a LAN network.

In Composer, a Video Network Manager (VNM) and the associated drivers should

be added to the MM8000/MK8000 main station in order to support the video net-

work communication. The drivers concern the NICE DVR units.

The Fig. 2 illustrates how to add the VNM to the configuration:

1. In the MM8000 physical configuration, select the main station name:

Supervisor System Settings ÆMM8000 System ÆPhysical configuration

Æ<Station name>

2. Click the button Ato add the VNM (see Fig. 2).

A new node is added. No further configuration is required for the VNM.

Fig. 2 Adding the Video Network Manager (A)

Note: Adding the VNM results in the entire Composer project being expanded in

order to support the CCTV functions. Particularly, the new tab Camera Extensor is

added to all nodes. Depending on the size of the configuration tree, the operation

may take a few minutes.

The Composer plug-in #251701 is required.

Building Technologies DMS8000 Video Connectivity Configuration Guide – NICE Add-on

Fire Safety & Security Products 06.2009

3.3 Video Drivers

The VNM can support the driver required to handle the network communication

with NICE/RIVER units. To add the driver to your project, proceed as follows:

1. Select the VNM node.

2. In the toolbar, click the icon corresponding to the NR driver (Fig. 3):

Fig. 3 Video drivers

A Select this icon to add the TELSCAN driver

B Select this icon to add the SISTORE driver

C Select this icon to add the NICE/RIVER driver

In small system, the Video Driver is installed on the MM8000 server. Large sys-

tems may include FEP stations with additional Video Drivers that can distribute the

traffic load. In the FEP station, the IP address must be configured:

1. Select the Video Driver node and then the Node tab.

2. In the Server Settings section, enter the FEP IP address in the Video LAN.

3.4 Video components

The Video menu of the Composer button bar on the left hand side includes the

available video component. Fig. 4 illustrates the menu options and the correspond-

ing components.

Fig. 4 CCTV components menu

A Select this icon to add a Camera folder

B Select this icon to add a Monitor folder

C Select this icon to add a NICE ( or RIVER) Digital Video Recorder

Building Technologies DMS8000 Video Connectivity Configuration Guide –NICE Add-on

Fire Safety & Security Products 06.2009

3.5 NICE/RIVER DVR configuration

3.5.1 Configuration checklist

Verify that you have satisfied the items needed in the first checklist before proceed-

ing to the configuration procedure that follows.

ITEMS NEEDED FOR CONFIGURATION

The NR Video driver installed and configured under the Video Network Manager

in Composer

The DVR IP address

The camera connections

Plug-ins needed:

– Plug-ins 258501 (NR driver) and 358201 (NICE/RIVER ST), which must be

installed before you can configure your system

3.5.2 Configuration procedure

The configuration of NICE and RIVER units is similar to the one for SISTORE DVR

that is described in the Video Connectivity Guide (doc.no. A6V10062457), although

the CCTV architecture can include multiple Video Drivers installed on various ma-

chines (MM8000 FEPs) on the network.

The following are the configuration procedures for a DVR unit:

Adding the folder for the DVR system

•Optionally, create a folder for the DVR unit.

Adding the DVR node

1. Select the new folder.

2. Click the Video menu

3. Select the NICE icon or RIVER icon to add a DVR node

Linking the DVR node

1. Expand the node structure including the NR Video Driver:

Supervisor System Settings ÆMM8000 System ÆPhysical configuration

Æ<Station name> ÆVideo Network Manager

2Select the DVR node.

3. Drag and drop the link to the Video Driver.

Configuring the DVR IP address

1. Select the new DVR node and click the Node tab.

Note: By default, the node will be named ‘Nice #nn’ or ‘River #nn’. In the Node

tab, you can customise the Description text.

2In the Setting section, enter the IP address,

which should match the value locally set in the DVR unit.

Autres manuels pour DMS8000 MP4 Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Siemens Système de contrôle

Siemens

Siemens SIMOTION P320-3 Manuel utilisateur

Siemens

Siemens TIASTAR Manuel

Siemens

Siemens SINUMERIK 840D sl Manuel de la liste des pièces

Siemens

Siemens SINUMERIK 840DE SL Guide de démarrage rapide

Siemens

Siemens SINUMERIK 840D sl Guide de démarrage rapide

Siemens

Siemens SINUMERIK 828D Turning Manuel d'instructions

Siemens

Siemens SIMATIC PC BI45 Manuel de la liste des pièces

Siemens

Siemens Climatix HMI-LED POL831.25/STD Manuel de l'opérateur

Siemens

Siemens SIMATIC PCS 7 Guide de l'utilisateur

Siemens

Siemens SINUMERIK 840D sl Manuel du propriétaire

Siemens

Siemens SIMATIC C7-626 Mode d’emploi

Siemens

Siemens SINUMERIK 828D Turning Manuel de la liste des pièces

Siemens

Siemens SIMATIC PCS 7 Feuille d'instructions

Siemens

Siemens SINUMERIK 840D sl Manuel du propriétaire

Siemens

Siemens SINUMERIK 840D sl Guide de démarrage rapide

Siemens

Siemens SIPLUS HCS3200 Guide de l'administrateur

Siemens

Siemens SIMATIC PCS 7 Manuel utilisateur

Siemens

Siemens SIPLUS HCS HCS PM4000 U/I Guide de l'administrateur

Siemens

Siemens SINUMERIK 840D sl Guide de démarrage rapide

Siemens

Siemens DESIGO RX QAX33.1 Manuel utilisateur

Siemens

Siemens SIMATIC PCS 7 Manuel de la liste des pièces

Siemens

Siemens SINUMERIK 808D Manuel utilisateur

Siemens

Siemens RVW26.000B27 Manuel de l'opérateur

Siemens

Siemens SINUMERIK 840D sl Manuel de la liste des pièces

Manuels Système de contrôle populaires d'autres marques

Pentair Pool Products

Pentair Pool Products Compool Manuel utilisateur

ComfortNET

ComfortNET CTK04 Manuel utilisateur

Fireye

Fireye InSight II 95DSS3 Manuel utilisateur

CAME

CAME G3000 Manuel utilisateur

Idemia

Idemia MorphoAccess VP MD Manuel utilisateur

Axis

Axis P1445-LE-3 Manuel utilisateur

HEIDENHAIN

HEIDENHAIN TNC 150 B Manuel utilisateur

CNC-Step

CNC-Step High-Z T-Series Manuel utilisateur

Doosan

Doosan DVF Series Manuel utilisateur

Honeywell

Honeywell KAP 140 Manuel utilisateur

Honeywell

Honeywell vk41 series Manuel utilisateur

AirBench

AirBench FPW Guide d'installation

Cypress

Cypress HHR-3160 Manuel utilisateur

CAME

CAME GLT40AOS Manuel utilisateur

Zonex

Zonex GEN II -VVT Guide de l'utilisateur

Altronics

Altronics K 9650 Manuel utilisateur

micro-trak

micro-trak RoadMaster Manuel utilisateur

micro-trak

micro-trak Calc-An-Acre II Manuel utilisateur
