Siemens SIMATIC PC Adapter TS Adapter Manuel utilisateur

SIMATIC

PC Adapter

TS Adapter

Quick Reference Guide

Edition 01/2003

A5E00078070-02

The reproduction, transmission or use of this document or its contents is not

permitted without express written authority. Offenders will be liable for damages.

All rights, including rights created by patent grant or registration of a utility model or

design, are reserved.

We have checked the contents of this manual for agreement with the hardware

and software described. Since deviations cannot be precluded entirely, we cannot

guarantee full agreement. owever, the data in this manual are reviewed regularly

and any necessary corrections included in subsequent editions. Suggestions for

improvement are welcomed.

Technical data subject to change.

Exclusion of Liability

Siemens Aktiengesellschaft A5E00078070

Printed in the Fed. Rep. of Germany

PC/TS Adapter

A5E00078070-02 i

Contents

1 Product Definition 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 Package Components 4. . . . . . . . . . . . . . . . . . . . . . . . . . .

3 Accessories 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4 MPI/DP Network 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5 Prerequisites for Operation 5. . . . . . . . . . . . . . . . . . . . . . .

5.1 Hardware 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.2 Software 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6 Connecting the Adapter 6. . . . . . . . . . . . . . . . . . . . . . . . . .

6.1 Safety-related Guidelines 6. . . . . . . . . . . . . . . . . . . .

6.2 General Remarks 7. . . . . . . . . . . . . . . . . . . . . . . . . .

6.3 Pin Configuration 10. . . . . . . . . . . . . . . . . . . . . . . . . .

6.4 Connection Procedures 12. . . . . . . . . . . . . . . . . . . .

6.5 Function and Operation of the Switch 13. . . . . . . .

6.6 Function of the Power LED 14. . . . . . . . . . . . . . . . .

7 Technical Specifications 15. . . . . . . . . . . . . . . . . . . . . . . .

7.1 Supplied PC/TS Adapter Versions 17. . . . . . . . . . .

7.2 Features of the PC/TS Adapter Versions 18. . . . . .

8 Approvals 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

8.1 Approval for USA and Canada 20. . . . . . . . . . . . . .

8.2 Approvals for Europe 22. . . . . . . . . . . . . . . . . . . . . .

PC/MPI Cable Kurzanleitung

ii PC/TS Adapter

A5E00078070-02

PC/TS AdapterQuick Reference Guide

PC/TS Adapter

A5E00078070-02 1

1 Product Definition

The adapter is available as:

SPC adapter 6ES7 972-0CA2x-0XA0

STS adapter 6ES7 972-0CA3x-0XA0

Note

Where ’adapter’ is referred to below, the text applies to both

variants.

The PC adapter connects a PC to the MPI/DP interface

(Multipoint Interface) via the serial COM port of an S7/M7/C7

system.

This does not require a PC slot, that is, the adapter is also

suitable for use in non-expandable PCs such as notebooks.

1) RS232 cable 6ES7 901-1BF00-0XA0, length 6m

RS232

COM 1 ...

1) PC adapter19.2/38.4 kbps

S7/M7/C7

system

RS232 Switch

19.2/38.4 kbps MPI/DP

Figure 1-1 PC Adapter in the System

PC/TS Adapter Quick Reference Guide

2PC/TS Adapter

A5E00078070-02

With ’direct connection’, the TS adapter allows you to link

programming devices/PCs with S7/M7/C7 systems. With this

setup, the TS adapter corresponds in functionality to the PC

adapter.

With ’modem connection’, the TS adapter enables you to link

programming devices/PCs with S7/M7/C7 systems over the

telephone network.

19.2/38.4 kb

RS232

COM1...

S7/M7/C7

system

MPI/DP

TS adapterRS232

Switch

19.2/38.4 kbps

1) RS232 cable 6ES7 901-1BF00-0XA0, length 6m

Direct Connection

2) Modem cable (supplied with modem)

Modem

PG/PC

RS232

COM1... RS232

Modem

Telephone network

MPI/DP

TS adapterRS232

2) 2)

ModemConnection

S7/M7/C7

system

Figure 1-2 TS Adapter in the System

The TeleService optional package is always required to

operate the TS adapter (see 5.2 Software). The switch on the

adapter is used to change the transmission rate on the

RS232 side in direct connection. With modem connection, it

has no function.

PC/TS AdapterQuick Reference Guide

PC/TS Adapter

A5E00078070-02 3

MPI/DP connector Adapter

RS232 connector

LED “POWER”

LED “ACTIVE”

Switch

“19.2/38.4 kbps”

Figure 1-3 Adapter

The two adapter types differ with respect to the location of the

MPI/DP parameters:

SThe MPI/DP parameters for the PC adapter are set in

“Set PG/PC interface”. When opening an online display

for the first time, ther parameters are transferred to the PC

adapter.

SThe MPI/DP parameters for the TS adapter are set via a

Teleservice application and stored permanently on the TS

adapter. When opening an online display for the first time,

these parameters are activated.

PC/TS Adapter Quick Reference Guide

4PC/TS Adapter

A5E00078070-02

2 Package Components

SAdapter

SQuick Reference Guide

SMounting assembly (TS adapter only)

3 Accessories (not part of the adapter package)

SRS232 cable, 6 meters in length 6ES7 901-1BF00-0XA0

(required to operate the PC adapter and to operate the

TS adapter in direct connection only).

4 MPI/DP Network

A maximum of 32 nodes can be interfaced to an MPI/DP

network segment. The total cable length may not exceed 50

meters. Using so-called RS485 repeaters, several network

segments can be combined to form a network comprising a

maximum of 127 nodes.

The data signalling rate in an MPI/DP network is max. 12

Mbit/s.

Der Adapter unterstützt Übertragungsraten bis max.

1,5 Mbit/ s.

Note

Also refer to “S7-300, Hardware and Installation”.

!Warning

If the transmission rate is 187.5 Kbits/sec and

higher, it is not allowed to insert cable extensions

in the S7/M7/C7 adapter system connection

(spur lines not allowed).

PC/TS AdapterQuick Reference Guide

PC/TS Adapter

A5E00078070-02 5

5 Prerequisites for Operation

5.1 Hardware

PC/programming device with a free COM port (COM1 or

COM2, 9-pin COM connection). Appropriate adapters for

other connector combinations are available in specialist

shops, for example 9-pin to 25-pin subminiature D connector.

GND

DCD

RXD

TXD

DTR

DSR

RTS

CTS

Shield

Shield Shield

Shield

25-pin subminiature D:

Connector casingConnector casing

Signal: 9-pin subminiature D:

1) 1)

Pins or sockets, depending on usage

Figure 1-4 9-Pin - 25-Pin RS232 Adapter

5.2 Software

PC adapter

SSTEP 7 Standard Package from V1 or

SS7 DOS

TS adapter

SSTEP 7 Standard Package from V3.1 and

STeleService optional package from Version 3.0

PC/TS Adapter Quick Reference Guide

6PC/TS Adapter

A5E00078070-02

6 Connecting the Adapter

6.1 Safety-related Guidelines

Qualified Personnel

A device/system may only be commissioned or operated by

qualified personnel. Qualified personnel as referred to in

safety guidelines in this document are persons authorized to

energize, de-energize, clear, ground, and tag circuits,

equipment and systems in accordance with established

safety practice. For a detailed description of the

safety-related guidelines, please refer to the Appendix.

Proper Usage

Please observe the following:

!Warning

The equipment/system or the system

components may only be used for the

applications described in the catalog or the

technical description, and only in combination

with the equipment, components, and devices of

other manufacturers as far as this is

recommended or permitted by Siemens.

The product will function correctly and safely only

it it is transported, stored, set up, and installed as

intended, and operated and maintained with

care.

Cleaning the Device

The device may be cleaned only using a soft cotton cloth and

neutral detergent. Make sure that no liquid penetrates the

housing.
