OPERATING INSTRUCTIONS
ReLy OSSD4
Safety relay
RLY3-OSSD400S14
Described product
ReLy OSSD4
Manufacturer
SICK AG
Erwin-Sick-Str. 1
79183 Waldkirch
Germany
Legal information
This work is protected by copyright. Any rights derived from the copyright shall be
reserved for SICK AG. Reproduction of this document or parts of this document is
only permissible within the limits of the legal determination of Copyright Law. Any modi‐
fication, abridgment or translation of this document is prohibited without the express
written permission of SICK AG.
The trademarks stated in this document are the property of their respective owner.
© SICK AG. All rights reserved.
Original document
This document is an original document of SICK AG.
2O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8026008/2020-07-28 | SICK
Subject to change without notice
Contents
1 Ordering information........................................................................ 5
1.1 Ordering information for ReLy.................................................................. 5
2 About this document........................................................................ 6
2.1 Purpose of this document........................................................................ 6
2.2 Scope......................................................................................................... 6
2.3 Target groups and structure of these operating instructions................ 6
2.4 Additional information.............................................................................. 6
2.5 Symbols and document conventions...................................................... 7
3 Safety information............................................................................ 8
3.1 General safety notes................................................................................ 8
3.2 Intended use............................................................................................. 8
3.3 Improper use............................................................................................. 8
3.4 Requirements for the qualification of personnel.................................... 9
4 Product description........................................................................... 10
4.1 Construction and function........................................................................ 10
4.2 Product characteristics............................................................................ 10
4.2.1 Device overview....................................................................... 10
4.2.2 Interfaces................................................................................. 10
4.2.3 Compatible sensor types......................................................... 10
4.2.4 External device monitoring...................................................... 11
4.2.5 Status indicators...................................................................... 11
5 Project planning................................................................................ 12
5.1 Manufacturer of the machine.................................................................. 12
5.2 Operating entity of the machine.............................................................. 12
5.3 Design........................................................................................................ 12
5.4 Electrical integration................................................................................. 13
5.4.1 Enabling current paths............................................................ 13
5.4.2 Feedback current path............................................................ 13
5.4.3 Connection diagrams.............................................................. 14
5.5 Testing plan............................................................................................... 14
5.5.1 Minimum requirements for the regular thorough check....... 14
6 Mounting............................................................................................. 15
6.1 Safety......................................................................................................... 15
6.2 Mounting procedure................................................................................. 15
6.3 Disassembly.............................................................................................. 16
6.4 Module exchange...................................................................................... 16
7 Electrical installation........................................................................ 18
7.1 Device connection.................................................................................... 18
CONTENTS
8026008/2020-07-28 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 3
Subject to change without notice
8 Commissioning.................................................................................. 20
8.1 Safety......................................................................................................... 20
8.2 Thorough check........................................................................................ 20
9 Troubleshooting................................................................................. 21
9.1 Safety......................................................................................................... 21
9.2 Status indicator (LED)............................................................................... 21
10 Decommissioning............................................................................. 22
10.1 Disposal..................................................................................................... 22
11 Technical data.................................................................................... 23
11.1 Data sheet................................................................................................. 23
11.2 Dimensional drawings.............................................................................. 26
11.3 Internal circuitry........................................................................................ 27
12 Annex.................................................................................................. 28
12.1 Compliance with EU directives................................................................. 28
13 List of figures..................................................................................... 29
14 List of tables....................................................................................... 30
CONTENTS
4O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8026008/2020-07-28 | SICK
Subject to change without notice
1 Ordering information
1.1 Ordering information for ReLy
Table 1: Ordering information
Part Usage Type Part number
ReLy OSSD4 Opto-electronic protec‐
tive devices
RLY3-OSSD400S14 1112276
ORDERING INFORMATION 1
8026008/2020-07-28 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 5
Subject to change without notice
2 About this document
2.1 Purpose of this document
These operating instructions contain the information required during the life cycle of the
safety relay.
These operating instructions must be made available to everyone who works with the
safety relay.
2.2 Scope
This document only applies to a ReLy safety relay with the following type label entries in
the Operating Instructions field:
•8025823
2.3 Target groups and structure of these operating instructions
These operating instructions are intended for the following target groups: project devel‐
opers (planners, developers, designers), installers, electricians, safety experts (such as
CE authorized representatives, compliance officers, people who test and approve the
application), operators, and maintenance personnel.
These operating instructions are organized by the life phases of the device: project
planning, mounting, electrical installation, commissioning, operation and maintenance.
The table below shows the target groups and how – for many applications – these are
typically divided up between the manufacturer and the entity operating the machine in
which the device is to be integrated:
Area of responsibility Target group Specific chapters of these operating instruc‐
tions 1)
Manufacturer Project developers
(planners, developers,
designers)
"Project planning", page 12
"Technical data", page 23
Installers "Mounting", page 15
Electricians "Electrical installation", page 18
Safety experts "Project planning", page 12
"Commissioning", page 20
"Technical data", page 23
Operating entity Operators "Troubleshooting", page 21
Maintenance person‐
nel
"Troubleshooting", page 21
"Ordering information", page 5
1) Chapters not listed here are intended for all target groups. All target groups must follow all of the safety
and warning instructions in all chapters of the operating instructions!
In other applications, the operating organization is also the manufacturer of the equip‐
ment with the corresponding allocation of the target groups.
2.4 Additional information
www.sick.com
The following information is available on the Internet:
•This document in other languages
•Data sheets and application examples
•CAD data and dimensional drawings
2 ABOUT THIS DOCUMENT
6O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8026008/2020-07-28 | SICK
Subject to change without notice
•Certificates (e.g. EU declaration of conformity)
•Guide for Safe Machinery Six steps to a safe machine
2.5 Symbols and document conventions
The following symbols and conventions are used in this document:
Safety notes and other notes
DANGER
Indicates a situation presenting imminent danger, which will lead to death or serious
injuries if not prevented.
WARNING
Indicates a situation presenting possible danger, which may lead to death or serious
injuries if not prevented.
CAUTION
Indicates a situation presenting possible danger, which may lead to moderate or minor
injuries if not prevented.
NOTICE
Indicates a situation presenting possible danger, which may lead to property damage if
not prevented.
NOTE
Indicates useful tips and recommendations.
Instructions to action
bThe arrow denotes instructions to action.
1. The sequence of instructions for action is numbered.
2. Follow the order in which the numbered instructions are given.
✓The check mark denotes the result of an instruction.
LED symbols
These symbols indicate the status of an LED:
oThe LED is off.
ÖThe LED is flashing.
OThe LED is illuminated continuously.
ABOUT THIS DOCUMENT 2
8026008/2020-07-28 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 7
Subject to change without notice
3 Safety information
3.1 General safety notes
DANGER
If the safety component is integrated incorrectly, the dangerous state may be ended to
late.
bPlan the integration of the safety component in accordance with the machine
requirements, see "Project planning", page 12.
DANGER
Hazard due to lack of effectiveness of the protective device
In the case of non-compliance, it is possible that the dangerous state of the machine
may not be stopped or not stopped in a timely manner.
bPlease read this document carefully and make sure that you understand the
content fully before working with the device.
bFollow all safety notes in this document.
Improper installation or manipulation can lead to serious injuries.
3.2 Intended use
The safety relay is an expansion module for sensors or safety devices with OSSDs for
switching safety-related circuits on and off.
The safety relay complies with class A, group 1 as per EN 55011. Group 1 encom‐
passes all ISM devices in which intentionally generated and/or used conductor-bound
RF energy that is required for the inner function of the device itself occurs.
The safety relay must only be used within the limits of the prescribed and specified
technical data and operating conditions at all times.
Incorrect use, improper modification or manipulation of the safety relay will invalidate
any warranty from SICK; in addition, any responsibility and liability of SICK for damage
and secondary damage caused by this is excluded.
UL/CSA applications
If the product is being used in accordance with UL 508 or CSA C22.2 No. 14, the
following conditions must also be met:
•To protect the device’s 24-volt voltage supply, use a fuse with a maximum voltage
of 4 A and a minimum of 30 V DC in accordance with UL 248.
NOTE
The safety functions have not be evaluated by UL. Authorization is in accordance with
UL 508, general applications.
3.3 Improper use
The safety relay is not suitable for the following applications (this list is not exhaustive):
•At altitudes of over 4,000 m above sea level
•In explosion-hazardous areas
3 SAFETY INFORMATION
8O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8026008/2020-07-28 | SICK
Subject to change without notice
3.4 Requirements for the qualification of personnel
The protective device must be configured, installed, connected, commissioned, and
serviced by qualified safety personnel only.
Project planning
For project planning, a person is considered competent when he/she has expertise and
experience in the selection and use of protective devices on machines and is familiar
with the relevant technical rules and national work safety regulations.
Mechanical mounting, electrical installation, and commissioning
For the task, a person is considered qualified when he/she has the expertise and
experience in the relevant field and is sufficiently familiar with the application of the
protective device on the machine to be able to assess whether it is in an operationally
safe state.
Operation and maintenance
For operation and maintenance, a person is considered competent when he/she has
the expertise and experience in the relevant field and is sufficiently familiar with the
application of the protective device on the machine and has been instructed by the
machine operator in its operation.
SAFETY INFORMATION 3
8026008/2020-07-28 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 9
Subject to change without notice
4 Product description
4.1 Construction and function
The safety relay ReLy OSSD4 is an electrical switching device with inputs and outputs.
The safety capable inputs of the safety relay are connected to safety sensors.
2 safety capable inputs control the internal relays, which are used to reliably switch the
enabling current paths.
Actuators with positively guided contacts are connected to the enabling current paths.
4.2 Product characteristics
4.2.1 Device overview
RELY
1
2
3
4
CH1
CH2
13
23
43
I1
14
24
44
I2
A2
51
33
52
34
6162
Figure 1: Device overview
1Device unlocking
2LEDs
3Front connector unlocking
4Front connector
4.2.2 Interfaces
Inputs
•2 safety capable inputs
Outputs
•4 enabling current paths (safe)
•Feedback current path (for use as external device monitoring, not safe)
4.2.3 Compatible sensor types
The safety relay is suitable for:
•Safety sensors and safety switches with OSSD output, e.g. Electro-sensitive pro‐
tective equipment (ESPE) with a single-channel or dual-channel monitored active
switching output with cross-circuit detection (OSSD) and safety controllers with
monitored semiconductor outputs
4 PRODUCT DESCRIPTION
10 O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8026008/2020-07-28 | SICK
Subject to change without notice
Autres manuels pour ReLy OSSD4
1
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels SICK Relais
SICK
SICK ReLy TIME1 Manuel utilisateur
SICK
SICK ReLy LOOP1 Manuel utilisateur
SICK
SICK LGT 015 Manuel de la liste des pièces
SICK
SICK ReLy MULT1 Manuel utilisateur
SICK
SICK ReLy OSSD4 Manuel utilisateur
SICK
SICK ReLy MULT1 Manuel utilisateur
SICK
SICK ReLy HAND1 Manuel utilisateur
SICK
SICK ReLy OSSD1 Manuel utilisateur
SICK
SICK ReLy EMSS1 Manuel utilisateur
SICK
SICK ReLy EMSS3 Manuel utilisateur
