SiCEP EV-D12W Manuel utilisateur
Quick Start Guide
www.sicep.it 22874.0
EV-D12W
Welcome
Thank you for choosing SICEP.
We are devoted to providing you easy smart home products.
If you have problems using the product, please contact
our service team before returning your product.
Package content
Camera introduction
Power Adapter ×1 Screw Package ×1
Camera ×1 Mounting Plate ×1 Waterproof Connector ×1Positioning Map ×1
Quick Start Guide ×1
Build-in Mic
Lens
Spotlight
LED Indicator
Note:
Double-press the reset button to enable the camera hotspot.
The pattern of the LED indicator is included in the following table.
Press and hold the reset button for 10 s to reset the camera.
Micro SD Card Slot
Max. 256Gb
Built-in Speaker
Reset Button
LED Indicator Status
O
Booting
Device malfunction
Network connection failed
Pairing failed
Red light on
Device Status
Green light on
Waiting for network
Enter Pairing mode
Operating properly
Green light flashing
Red light flashing
Firmware updating
Powered o/LED turned o
Rebooting after reset
Green and red light
flashing alternately
My Sicep
1
Setup
WIFI Name
Password
Next
Setup
Done
2
Ceiling Mounting
3
Camera
Expansion Bolt
2
Self-tapping Screw
Mounting Plate
1
Positioning Map
Mounting Surface
2
Wall Mount:Adjusting Angle:
+60
-30
Troubleshooting
Problem Solution
The camera cannot work
normally or start
• Make sure that the network cable is connected well, and the NVR or switch
supports POE power supply. When the indicator light on the NVR or switch
ashes, it means that the camera is powered up.
The IR eect is not good • The infrared light is reected to the lens, so the eect is not good.Adjust the
ens angle to avoid occlusions around the lens.
Kurzanleitung
EV-D12W
www.sicep.it
Willkommen
Vielen Dank, dass Sie sich für SICEP entschieden haben.
Wir sind bestrebt, einfachere Produkte für das intelligente
Heim anzubieten. Wenn Sie Probleme bei der Verwendung
des Produkts haben, wenden Sie sich bitte an unser
Serviceteam.
Packungsinhalt
Einführung in die Kamera
Netzteil ×1 Schraubenbeutel ×1
Kamera×1 Montageschablone ×1 Wasserdichter Anschluss ×1Montageschablone ×1
Kurzanleitung ×1
Integriertes
Mikrofon
Objektiv
Scheinwerfer
LED-Anzeige
