▲Technical Specifications
Model SONICBOOMTM / SONICBOOMTM X
Power Input 220V version: AC220V-240V 50/60Hz
110V version: AC100V-120V 50/60Hz
Fuse 15A/250V
Work Power 220V version: 3,000W/1500W (Half power mode)
110V version: 2000W
LED Power 5W ×35PCS
Heat-up Time 220V version: 5min
110V version: 7min
SONICBOOM Mode YES for SONICBOOM X
Max Continuous Output Duration 8s
Output 55000cuft/min
Max Output Height 10m
Tank Capacity 2.5L
N.W. 17.2Kg
G.W. 19Kg
Machine Size 482×408×215 (mm)
Package Size 560×480×280 (mm)
DMX Channel 11/1
Consumable FX-S/FX-ST
▲Safety Information
》Unauthorized repair are prohibited, it may cause serious incident.
》This product is not waterproof design, please keep it dry, please do not use it when there are fog
fluid leakage or wet from rain.
》Make sure power supply in consistent with the rated voltage of the equipment, and the socket
must well grounded. Unplug and turn off the machine when not use.
》For adult use only, keep it away from fire, inflammable and explosive articles.
》Installed in well ventilated area, ensure at least 50cm space around the machine, cover of the
nozzle is forbidden.
》If the machine fails to work, please stop operation and unplug the machine. Check fog fluid, fuse,
power connection etc. carefully, if can’t solve the problem, please contact SHOWVEN or your local
SHOWVEN partner for advise.
》Only use SHOWVEN original FX-S/FX-ST fog fluid, other fluid may lead to clog or malfunction.
Please do not adding any other material such as pigment, water etc to the fuel bottle.
》To avoid fluid spill, make sure fog fluid not exceed related MAXIMUM fluid level line. When install
SONICBOOM in invert direction, the fuel bottle should installed upward.
》In case of eye contact of fog fluid, please wash it with clean water. If fluid is swallowed immediate
ly look for medical advice.
》Independent smoke column color change
》Patented pipeline integration technology, ensure 0.3s instant smoke burst
》Automatic constant pressure design, highly consistent smoke effect
》220V version SONICBOOM Support 1500W half power mode, easier main power supply.
》Over temp. alarm, no fuel alarm, over voltage alarm etc. multi safety status monitoring. Safer for
use, easier for maintenance.
》Support manual operation on machine control panel
》DMX control, 11 channels and 1 channel optional
》Only use SHOWVEN original FX-S/FX-ST fog fluid, other fluid may lead to clog or malfunction.
》FX-S is quick dissipating fog fluid, the smoke dissipate in seconds, it is perfect choice for creating
instant smoke column.
》FX-ST is special designed to generate sonicboom effect, suggest to use on SONICBOOM X for short
time (less than 2s) effects, the dissipating time is little longer than FX-S.
