2
Functional Characteristics
\ Molded enclosure, lighter, durable as well as rustless.
\ Multi-optimized air supply system, ensure farther and more uniform fog output.
\ 40 heads atomizers, thicker fog output. (CREEPER AQ is 30 heads)
\ Weather proof design
\ Abrasion-resistant silent caster
\ Latest rapid heating technology, 1-2min heating up time
\ Adjustable fog density, moisture and fan speed, versatile application to meet different requirements
\ Low-water sensor
\ Patented fog leakage prevention technology, no fog leakage even refill the machine when it is working
\ User friendly LCD control panel
\ 3.3L fluid tank, support 2h continuous output.
\ Advanced auto water refill system
Technical Specifications
\ Model Creeper AQ PLUS Creeper AQ
\ Dimension 950×500×540mm 805×390×480mm
\ Package size 1170×555×475mm 945×445×435mm
\ Voltage AC200-240V, 50-60Hz AC200-240V, 50-60Hz
AC100-120V, 50-60Hz AC100-120V, 50-60Hz
\ Work Power 2500W 2000W
\ Heat-up Time Appr. 1-2min Appr. 1-2min
\ Fluid Tank Capacity 3.3L 3.3L
\ Water Tank Capacity 35L 24L
\ DMX-512 YES YES
\ Remote control YES YES
\ Output Adjustable 1-100 1-100
\ Max. Fog Output 20,000 cfm/min 15000 cfm/min
\ Max. Coverage Appr. 400㎡Appr. 300㎡
\ Max. Fluid Consumption. Appr. 32ml/min Appr. 32ml/min
\ Max. Water Consumption Appr. 500ml/min Appr. 375ml/min
\ Continuous Output YES YES
\ Fully loaded Output Time 100+ min 100+ min
\ Consumable FX-M Fog Fluid, Water FX-M Fog Fluid, Water
\ Net Weight 48kg 35kg
\ Gross Weight 55kg 38kg
