Technical Specification

H8922 3G/4G Router

www.hongdian.com

Doc. Version 1.0

H8922 3G/4G Router Technical Specification

Contents

Contents ...................................................................................................................................................i

1 Product Overview...................................................................................................................................3

2 Product Specification ..............................................................................................................................3

3 Definition of Structure Size and Interface ..................................................................................................4

4 Panel Indicator Status .............................................................................................................................5

Hongdian Corporation

H8922 3G/4G Router User Manual

1 Product Overview

H8922 4G industrial router is based on 3G/4G network, and supports wired / wireless network backup, with high

reliability and convenient construction. It is suitable for large-scale distributed applications, can be widely used in

the self service terminal industry such as smart courier cabinet, charging pile, bank ATM machine, POS machine,

tower monitoring, business networking, electric, water conservancy, environmental protection etc. Industrial

design and multi interface expansion, can help customers achieve machine networking, state monitoring, remote

maintenance, reduce the cost of integrated maintenance, improve service response speed, accelerate the

implementation of industrial 4.0.

2 Product Specification

Specification Name

Description

Remarks

Product Name

H8922

V30

Network Standard

Choose different modules according to

user’s needs, support different network

standards

Front Panel

Interface

2 SIM card slots (1.8V/3.0V)

12 working status indicator lamps (see lamp description for

details)

Rear Panel Interface

4 antenna interfaces (SMA-K female connector, 4G2-A

antenna is not supported temporarily)

1 RESET button

1 WAN interface (10/100Mb adaptive)

4 LAN interfaces (10/100Mb adaptive)

1 DC power connector

Power Supply

Working voltage

+5V~+36V DC

Working Power

Single module idle

status

About 200mA@12V DC

Signal module

communication status

About 450mA@12V DC

Hongdian Corporation

H8922 3G/4G Router User Manual

Specification Name

Description

Remarks

Other

Weight (dual module)

About 540g

Size (without power

cable interface and

bracket)

L x W x H (mm) 176×105×25

Working environment

temperature

-20~+75℃

Storage temperature

-40~+85℃

Relative humidity

<95%( Non-condensing)

Note: the communication power consumption is influenced by the network signal strength and the module

network standard, and the product can be tested by 8V, 10ms voltage drop test.

3 Definition of Structure Size and Interface

In the following diagrams, the dimensions of corresponding objects are expressed in millimeter.

Hongdian Corporation

H8922 3G/4G Router User Manual

①

4G1-A auxiliary antenna interface

②

RESET button

③

4G1-M main antenna interface

④

DC power connector

⑤

LAN interface

⑥

WAN interface

⑦

WiFi-M main antenna interface

⑧

SIM card slot

4 Panel Indicator Status

The front panel of the H8922 4G Router has 12 LED indicator lights, indicating the working state and the network

state of 4G Router H8922. The description of indicator status shows in table 4-1.

Hongdian Corporation

H8922 3G/4G Router User Manual

Table 4-1

Indicator Name

State Description

RUN

On: system startup and normally run

Off: system is not fully activated (power on less than 10 seconds, or in

the restart process)

WAN

On: network is connected normally via cable

Blink: network port has data transmission

Off: no network cable inserted or connecting abnormal with other

devices through the cable

LAN1～4

On: Network connected normal and data forwarding is normal.

Blink: network port has data transmission

Off: no network cable inserted or connecting abnormal with other

devices through the cable

SIG1～2

On: signal strength is well, value in 21 ~ 31

Fast flashing (0.5s flashing): signal strength is medium, value in 11 ~ 20

Slow flashing (2s flashing): the signal strength is poor, value in1 ~ 10

Off: no signal

3G/4G1～2

On: dial-up success, access 3G/4G network

Slow flashing (2s flashing): dial-up success, access 2G/2.5G/2.75G

network

Quick flashing (0.5s flashing):dialing

Off: could not find the modem or dial-up is disabled

WLAN

On: 2.4G and 5G Wi-Fi are running in the same time.

Slow flashing: only 2.4G Wi-Fi is enabled

Fast flashing: only 5G Wi-Fi is enabled

Off: 2.4G and 5G Wi-Fi are disabled

WPS

Not support for the time being

F14 - F16, Tower A, Building 14, No.12, Ganli 6th Road, Longgang District, Shenzhen 518112, China.

+86-755-88864288-5 +86-755-83404677 hongdianchina

www.hongdian.com sales@hongdian.com Hongdian_China

Create smart things
