29H-FG3RU

1-1 1-2

SHARP CORPORATION

SERVICE MANUAL

29H-FG3RU

MODEL

In the interests of user-safety (Required by safety regulations in some countries) the set should be restored

to its original condition and only parts identical to those specified should be used.

WARNING

The chassis in this receiver is partially hot. Use an isolation transformer between the line cord plug and power

receptacle, when servicing this chassis. To prevent electric shock, do not remove cover. No user – serviceable

parts inside. Refer servicing to qualified service personnel.

»SPECIFICATIONS ........................................... 2

»IMPORTANT SERVICE NOTES ...................... 2

»ADJUSTMENT PRECAUTIONS ..................... 3

»TROUBLE SHOOTING TABLE ..................... 20

»SOLID STATE DEVICE BASE DIAGRAM ..... 24

»CHASSIS LAYOUT ........................................ 25

»BLOCK DIAGRAM ........................................ 26

»WAVEFORMS ............................................... 28

»DESCRIPTION OF SCHEMATIC DIAGRAM .. 28

»SCHEMATIC DIAGRAM

■CRT UNIT ................................................. 29

■MAIN UNIT ............................................... 30

■FRONT UNIT ............................................ 32

»PRINTED WIRING BOARD ASSEMBLIES ... 34

»REPLACEMENT PARTS LIST

■ELECTRICAL PARTS ............................... 40

■MISCELLANEOUS PARTS ...................... 46

■SUPPLIED ACCESSORIES ..................... 46

■PACKING PARTS ..................................... 46

■CABINET PARTS ..................................... 46

»PACKING OF THE SET ................................ 47

Page Page

CONTENTS

COLOUR TELEVISION

Chassis No.GB-4

S45H829HFG3RU

ËAV STEREO

ËChild Lock

ËDynamic Skin Tone

ËGraphic Equalizer

ËClock

ËSound Mode (Music / Movie /

News / Custom)

ËHotel Mode

Ë16 : 9 Mode

FEATURES

ËWorld Multi 28 System

Ë100-CH Program Memory

ËAV Mode (Standard / Dynamic /

Soft / Custom)

ËCATV Hyper Band Ready

Ë4 Line Digital Comb Filter

ËVelocity Modulation

ËBlue/Black Stretch Circuit

ËPicture Noise Reduction

ËWhite Temp. Select

ËAperture Control

ËGamma Correction

ËMulti Language OSD (English / Russian)

ËOn/Off/Reminder Timer

ËComfy View

ËRear AV-IN 1 & 2, S-Video In, AV Output

(Monitor Out), Headphone and Front AV-IN 3

ËAFT

ËComponent Input Terminal

ËMulti Language TELETEXT

29H-FG3RU

2-1 2-2

IMPORTANT SERVICE NOTES

Maintenance and repair of this receiver should be done by qualified

service personnel only.

SERVICE OF HIGH VOLTAGE SYSTEM AND PIC-

TURE TUBE

When servicing the high voltage system, remove static charge from it by

connecting a 10K ohm resistor in series with an insulated wire (such as a

test probe) between picture tube dag and 2nd anode lead. (AC line cord

should be disconnected from AC outlet.)

1. Picture tube in this receiver employs integral implosion protection.

2. Replace with the same type number of picture tube for continued safety.

3. Do not lift picture tube by the neck.

4. Handle the picture tube only when wearing shatterproof goggles and after discharging

the high voltage completely.

X-RAY

This receiver is designed so that any X-Ray radiation is kept to an absolute

minimum. Since certain malfunctions or servicing may produce potentially

hazardous radiation with prolonged exposure at close range, the followin

precautions should be observed:

1. When repairing the circuit, please make sure do not increase the high voltage of the set

to more than 34.0kV (at beam 0

A).

2. To keep the set in a normal operation , please make sure it's function at 30.0kV

1.5kV

(at beam 1,700

A). The set has been factory - adjusted to the above-mentioned high

voltage.

∴∴

∴If there is a possibility that the high voltage fluctuates as a result of the repaires,

never forget to check for such high voltage after the work.

3. Do not substitute a picture tube with unauthorizerd types and/or brands which may

cause excessive X-ray radiation.

BEFORE RETURNING THE RECEIVER

Before returning the receiver to the user, perform the following safety checks.

1. Inspect all lead dress to make certain that leads are not pinched or that hardware is not

lodged between the chassis and other metal parts in the receiver.

2. Inspect all protective devices such as non-metal control knobs, insulating fishpapers,

cabinet backs, adjustment and compartment covers or shields, isolation resistor- ca-

pacity networks, mechanical insulators etc.

SPECIFICATIONS

Convergence ................................................................. Self Convergence System

Focus ......................................................... Bi-Potential, Uni-Potential Electrostatic

Sweep Deflection ...................................................................................... Magnetic

Intermediate Frequencies

Picture IF Carrier .................................................................................. 38.9MHz

Sound IF Carrier Frequency

6.5MHz .............................................................................................. 32.4MHz

6.0MHz .............................................................................................. 32.9MHz

5.5MHz .............................................................................................. 33.4MHz

4.5MHz .............................................................................................. 34.4MHz

Colour Sub-Carrier Frequency

PAL .................................................................................................. 34.47MHz

SECAM ................................................................................ 34.494/34.65MHz

NTSC ............................................................................................... 35.32MHz

Power Input .....................................................................220 ~ 240V AC 50/60 Hz

Power Consumption ...................................................................................... 135W

Audio Power Output Rating .......................................................

Speaker

Size ....................................................................................

Aerial Input Impedance

VHF/UHF .......................................................................... 75 ohms Unbalanced

Receiving Channel

PAL-B/G, SECAM-B/G

VHF-Channels .............................................................................. E2 thru E12

UHF-Channels ............................................................................. E21thru E69

CATV ........................................................................ X thru Z +2, S1 thru S41

PAL-D/K, SECAM-D/K

VHF-Channels ........................................................ R1 thru R12, C1 thru C12

UHF-Channels ...........................................................21thru 69, C21 thru C57

PAL-I, SECAM-I

VHF-Channels .................................................................. (IRELAND) B thru J

UHF-Channels ............................................................ (U.K. & H.K.) 21thru 69

NTSC-M

VHF-Channels ........................................................................... 2 thru 13 (US)

1 thru 12 (Japan)

UHF-Channels ......................................................................... 14 thru 69 (US)

13 thru 62 (Japan)

CATV .............................................................. A-6 thru A-1, A thru W+29 (US)

C13 thru C63 (Japan)

Receiving Frequency ................................................. 44.25 MHz thru 863.25 MHz

Dimensions ...................................................................................... Width: 722mm

Height: 582mm

Depth: 495mm

Weight(approx): 45.0 kg

Specifications are subject to change without prior notice.

5W X 2 +10W (at Max.)

4.3 x 21.8 cm X 2pcs(front)

+10cm round (rear woofer) x 1pc

+ 32mm round (tweeter) x2pcs

29H-FG3RU

3-1 3-2

ADJUSTMENT PRECAUTIONS

This model's setting are adjusted in two different ways: through the I2C bus control and

in the conventional analog manner. The adjustments via the I2C bus control include preset-

only items and variable data.

1. Setting the service mode by the microprocessor.

1Press and hold the local key "VOL DOWN" & "CH UP" when power on the main

switch,TV will enter into the SERVICE MODE. (The initial values of EEPROM are

2Press the CH DOWN / UP key on the remote controller to get ready to select the

mode one by one.

3Press the CH DOWN / UP key on the remote controller to select the modes

reversibly one by one.

4Using the VOLUME UP/ DOWN key on the remote controller, the data can be modi-

fied.

5Use the MENU Key on the remote controller to select the mode as shown in the

next page.

6When press the local key "VOL DOWN" & "CH UP" at the same time, it will be

released from the service mode.

2. Factory Presetting.

1After enter into the SERVICE MODE, at "INIT EEPROM" SERVICE ITEM

(which is under "CHECK MODE" section) press REMOTE CONTROLLER key of

code "ED" the initial values are automatically preset.

2The initial data are preset as listed in page 4-2 to 5-1.

3Make sure whether the data need to modify or not (Initial data).

Note: Once the chassis has been assembly together and in ready condition, please make sure it's go

through initialize process (see sect 2-(1) above)

Precaution: If haven't done this initialization, malfunction might be happen.

automatically preset when new EEPROM is used.)

SERVICE MODE

(1) In the Service Mode, Key is used to select the mode in the following order.

29H-FG3RU

4-1 4-2

SREC/SRAC/SYI/STTM SREC-SCA (SKD)

R/C CODE

MCL 1 (R/C CODE 117h) MCL 2 (R/C CODE 169h)

TV-CH. CH-No. Fv (MHz) S-SYSTEM CH-No. Fv (MHz) S-SYSTEM

0SKIP OFF FREE 590.25 5.5 B/G

1E-2 48.25 5.5 B/G AU-0 46.25 5.5 B/G

2 E-4/B-3 62.25 5.5 B/G AU-2 64.25 5.5 B/G

3OIR-3 77.25 6.5 D/K AU-3 86.25 5.5 B/G

4E-5 175.25 5.5 B/G AU-4 95.25 5.5 B/G

5E-6/B-5 182.25 5.5 B/G AU-5A 138.25 5.5 B/G

6OIR-7 183.25 6.5 D/K AU-6 175.25 5.5 B/G

7OIR-8 191.25 6.5 D/K AU-7 182.25 5.5 B/G

8E-8/B-7 196.25 5.5 B/G AU-8 189.25 5.5 B/G

9J-9 199.25 4.5 M AU-9 196.25 5.5 B/G

10 E-10/B-9 210.25 5.5 B/G AU-10 209.25 5.5 B/G

11 E-12/B-1 224.25 5.5 B/G AU-11 216.25 5.5 B/G

12 E-21 471.25 5.5 B/G SKIP OFF FREE

13 I-23 487.25 6.0 I SKIP OFF FREE

14 E-25 503.25 5.5 B/G SKIP OFF FREE

15 E-34 575.25 5.5 B/G SKIP OFF FREE

16 E-35 583.25 5.5 B/G SKIP OFF FREE

17 E-37 599.25 5.5 B/G SKIP OFF FREE

18 J-38 621.25 4.5 M SKIP OFF FREE

19 OIR-42 639.25 6.5 D/K SKIP OFF FREE

20 B-50 703.25 5.5 B/G SKIP OFF FREE

21 I-54 735.25 6.0 I SKIP OFF FREE

22 E-58 767.25 5.5 B/G SKIP OFF FREE

23 E-64 815.25 5.5 B/G SKIP OFF FREE

24 I-69 855.25 6.0 I SKIP OFF FREE

25 E-69 855.25 5.5 B/G SKIP OFF FREE

26 US-2 55.25 4.5 M SKIP OFF FREE

27 A-6 83.25 4.5 M SKIP OFF FREE

28 JA-6 183.25 4.5 M WE-28 527.25 5.5 B/G

29 JA-8 193.25 4.5 M SKIP OFF FREE

30 JA-12 217.25 4.5 M SKIP OFF FREE

31 US-14 471.25 4.5 M SKIP OFF FREE

32 JA-14 477.25 4.5 M SKIP OFF FREE

33 JA-50 693.25 4.5 M SKIP OFF FREE

34 US-83 885.25 4.5 M SKIP OFF FREE

35 S-2 112.25 5.5 B/G SKIP OFF FREE

36 S-10 168.25 5.5 B/G SKIP OFF FREE

37 SKIP OFF FREE 590.25 5.5 B/G

38 S-20 294.25 5.5 B/G SKIP OFF FREE

39 S-41 463.25 5.5 B/G SKIP OFF FREE

40 SKIP OFF FREE SKIP OFF FREE

41 B-43 647.25 5.5 B/G E-2 48.25 5.5 B/G

42 B-45 663.25 5.5 B/G WE-4 62.25 5.5 B/G

43 B-47 679.25 5.5 B/G OI-3 77.25 6.5 D/K

44 E-5 174.95 5.5 B/G E-5 175.25 5.5 B/G

45 E-5 175.55 5.5 B/G OIR-7 183.25 6.5 D/K

46 SKIP OFF FREE OIR-8 191.25 6.5 D/K

47 SKIP OFF FREE E-10 210.25 5.5 B/G

48 SKIP OFF FREE E-12 224.25 5.5 B/G

49 SKIP OFF FREE I-23 487.25 6.0 I

50 SKIP OFF FREE WE-25 503.25 5.5 B/G

51 SKIP OFF FREE E-34 575.25 5.5 B/G

INITIAL SETTING

(1) Execute MCL 1/2 key to set the following data in EEPROM.

29H-FG3RU

5-1 5-2

(1) The following default data has been factory-setting for the EEPROM.

Model-Set: The data in table below (1.1), Model set overview is updated to the respective EEPROM location base on

RC key input Model Set 1~10.

MODEL-SET KEY

Default Settings:

Note : The CHILD LOCK PASSWORD and

VIEW TIMER PASSWORD are common use.

Refer to next page for setting of each destination. Refer to next page for (*1) ~ (*4)

SHIPPING SETTING & CHECKING

OSD LANGUAGE

SOUND SYSTEM

Chinese

(AUTO)

Chinese

(AUTO)

English

(AUTO)

Arabic

(AUTO)

Russian

(AUTO)

Malay

(AUTO)

French

(AUTO)

English

Thai

(AUTO)

Iranian

(AUTO)

Table 1.1

Items

Default Settings

Items

Default Settings

GENERAL

EQUALIZER menu

Last power

MODE

MOVIE

Last TV/AV mode

TV mode

INSET menu (for PIP model)

Last position-TV

Program 1

BRIGHTNESS

Last position-RADIO

Program 1

TINT

Flashback Program-TV

Program 1

FEATURE menu

Flashback Program-RADIO

Program 1

BLUE BACK

OFF

Favorite Program A

Program 10

AUTO SELECT

Favorite Program B

Program 20

POWER SAVE (*1)

OFF

Favorite Program C

Program 30

COMFY VIEW (*2)

OFF

Favorite Program D

Program 40

SAFETY MODE (*3)

OFF

1 / 2 digit entry

2 digit entry

ROTATION

Volume

16:9 MODE

OFF

GAME Volume

DEMO

OFF

PIP

OFF

PIP location

Lower-Right

Last position-PIP

Program 1

CHILD LOCK menu

AFT

All Programs ON

LOCK TV

OFF

NICAM STEREO mode

All Programs STEREO

LOCK STATUS

OFF

NICAM BILINGUAL mode

All Programs M1

LOCK GAME (*4)

OFF

NICAM MONO mode

All Programs MONO

PASSWORD

0000

A2 STEREO mode

All Programs STEREO

TIMER menu

A2 BILINGUAL mode

All Programs MAIN

CLOCK

_ _:_ _

PICTURE menu

DAY

SUN

VIDEO MODE

DYNAMIC

ON TIMER

_ _:_ _

CONTRAST

STATUS

ONCE

COLOUR

POSITION

_ _

BRIGHNESS

VOLUME

_ _

TINT

OFF TIMER

_ _:_ _

SHARPNESS

REMINDER

_ _:_ _

PICTURE NR

OFF

BEEP REMINDER

OFF

WHITE TEMP

0 (CENTER)

VIEW TIMER menu

SOUND menu

VIEWING TIME

_ _:_ _

SURROUND

OFF

LOCK

OFF

BBE

PASSWORD

0000

BALANCE

CH SETTING menu

AVL

POSITION NAME

BLANK (For all position)

SUPER BASS/BASS+

COLOUR

All Programs AUTO

SOUND

All Programs AUTO

SKIP

All Programs OFF

FM RADIO menu

SKIP

All Programs OFF

For model Set 8 processing only,

the respective EEPROM position

is updated again with MCL2 data

(just like MCL2 key has been

pressed)

SREC/SRAC/SYI/STTM SREC-SCA (SKD)

R/C CODE

MCL 1 (R/C CODE 117h) MCL 2 (R/C CODE 169h)

TV-CH. CH-No. Fv (MHz) S-SYSTEM CH-No. Fv (MHz) S-SYSTEM

52 SKIP OFF FREE E-37 599.25 5.5 B/G

53 SKIP OFF FREE JPN-38 621.25 4.5 M

54 SKIP OFF FREE OI-42 639.25 6.5 D/K

55 SKIP OFF FREE I-54 735.25 6.0 I

56 SKIP OFF FREE E-58 767.25 5.5 B/G

57 SKIP OFF FREE WE-64 815.25 5.5 B/G

58 SKIP OFF FREE I-69 855.25 6.0 I

59 SKIP OFF FREE JA-1 91.25 4.5 M

60 SKIP OFF FREE JA-6 183.25 4.5 M

61 SKIP OFF FREE JA-8 193.25 4.5 M

62 SKIP OFF FREE JA-12 217.25 4.5 M

63 SKIP OFF FREE US-14 471.25 4.5 M

64 SKIP OFF FREE JA-50 693.25 4.5 M

65 SKIP OFF FREE S-2 112.25 5.5 B/G

66 SKIP OFF FREE S-10 168.25 5.5 B/G

67 SKIP OFF FREE S-20 294.25 5.5 B/G

68 SKIP OFF FREE S-41 463.25 5.5 B/G

69 SKIP OFF FREE E-5 174.95 5.5 B/G

70 SKIP OFF FREE E-5 175.55 5.5 B/G

99 SKIP OFF FREE SKIP OFF FREE

29H-FG3RU

6-1 6-2

MODE DYNAMIC STANDARD SOFT

CONTRAST 60 60 50

COLOUR +6 +1 -5

BRIGHTNESS 0 0 0

TINT 0 0 0

SHARPNESS +6 1 - 4

PEICTURE NR OFF OFF OFF

WHITE TEMP 0 (center) 0 (center) 0 (center)

MODEL MAGNETIC FIELD (V.H) nT BACKGROUND LANGUAGE S-SYS FACTORY SET

HONG KONG 20,000 40,000 17,000K CHINESE AUTO SET 2

SINGAPORE -10,000 40,000 12,300K ENGLISH AUTO SET 3

MIDDLE EAST 30,000 20,000 18,000K ARABIC AUTO SET 4

AUSTRALIA -50,000 20,000 12.300K ENGLISH AUTO SET 8

RUSSIA 45,000 20,000 7,500K RUSSIAN AUTO SET 5

(1) Refer to below table (2.1) for setting of each destination.

Table 2.1

Table 2.2

(2) Refer to below table (2.2) for NORMAL setting of each AV mode.

(3) Refer to below note for *1 ~ *4.

(*1) : Only available for model with POWER SAVE function.

(*2) : Only available for model with COMFY VIEW function.

(*3) : Only available for model with SAFETY MODE function.

(*4) : Only available for model with GAME function.

OPTION MODE MENU

0001 Option Mode Picture Tube Used Type TUBE-TYPE

0002 PIF Frequency Setting PIF

0003 Sound M SND-M

0004 Sound DK SND-DK

0005 Sound I SND-I

0006 Sound BG SND-BG

0007 Colour System SECAM SECAM

0008 Colour System NTSC358 NTSC358

0009 Colour System NTSC443 NTSC443

0010 Game IC GAME-IC

0011 Picture In Picture PIP

0012 Headphone HEADPHONE

0013 Equalizer EQUALIZER

0014 Sub Woofer WOOFER

0015 BBE BBE

0016 SRS SRS

0017 DOLBY DOLBY

0018 Audio Confi

uration AUDIO-CFG

0019 Mono Bilingual BILINGUAL

0020 Hotel Mode HOTEL

0021 Hotel Volume HTL-VOL

0022 Hotel Program Number HTL-PRG

0023 HTL-USE-LAST HTL-USE-LAST

0024 OPC OPC

0025 Rotation Functionality ROTATION

0026 Childlock CHILD

0027 Wide Screen Signalling WSS

0028 Golden SCART GLD-SCART

0029 Thailand OSD Language THAI

0030 Arabic OSD Language ARABIC

0031 Iranian OSD Language IRANIAN

0032 Malay OSD Language MALAY

0033 Chinese OSD Language CHINESE

0034 French OSD Language FRENCH

0035 Russian OSD Language RUSSIAN

0036 Power On Last Status PW-LAST

0037 Background BACK-GND

0038 Tuner 2 TUNER2

0039 FM Radio FM-RADIO

0040 Curtain Effect CURTAIN

0041 Curtain Colour CURT-COLOUR

0042 AV1-IN AV1-IN

0043 AV1S-IN AV1S-IN

0044 AV2-IN AV2-IN

0045 Component Input DVD1-IN

0046 AV3-IN AV3-IN

0047 AV3S-IN AV3S-IN

0048 INCL-AV INCL-AV

0049 Reminder Timer TIM-REMINDER

0050 View Timer TIM-VIEW

0051 Switch Timer TIM-SWITCH

0052 Time Format TIME-FORMAT

0053 Off Timer TIM-OFF

0054 Commercial Skip Timer TIM-SKIP

0055 Teletext Pan-european TXT-EURO

0056 Teletext Western TXT-WEST

0057 Teletext On TXT-ON

0058 Teletext Split TXT-SPLIT

0059 Virgin Mode VIRGIN MODE

0060 ERR-1-8-SUP ERR-1-8-SUP

0061 ERR-XRAY ERR-XRAY

0062 ERR-SUPVOL ERR-SUPVOL

0063 ERR-VERTG ERR-VERTG

0064 LOGO ERR-VERTG

SETTING DATAITEM SERVICE MODE EEPROM ITEM OSD DATA INITIAL DATA

00/1 0

0/1

0..2

0/1

0..2

0..60

0..99

0/1

0..7

0/1

0..4

0/1

0..7

0/1

29H-FG3RU

7-1 7-2

Adjustment Mode Items

A001 RF-AGC 0...63 UOC-TV RF-AGC 32 19

A002 RF AGC PIP 0...63 PIP-IF RF AGC PIP 0 0

A003 V SLOPE 0...63 UOC-TV V SLOPE 40 35

A004 VER-AMP-N50 0...63 UOC-TV VER-AMP-N50 32 21

A005 VER-SHI-N50 0...63 UOC-TV VER-SHI-N50 25 25

A006 HOR-SHI-N50 0...63 UOC-TV HOR-SHI-N50 45 44

A007 EW-W-N50 0...63 UOC-TV EW-W-N50 40 40

A008 V-LIN 0...63 UOC-TV V-LIN 32 32

A009 S-COR 0...63 UOC-TV S-COR 30 32

A010 V SCROLL 0...63 UOC-TV V SCROLL 32 32

A011 VX-NORMAL 0...63 UOC-TV VX-NORMAL 32 32

A012 H-PAR 0...63 UOC-TV H-PAR 35 24

A013 H-BOW 0...63 UOC-TV H-BOW 25 28

A014 E/W-PAR 0...63 UOC-TV E/W-PAR 35 42

A015 UPCOR-PAR 0...63 UOC-TV UPCOR-PAR 45 47

A016 LOCOR-PAR 0...63 UOC-TV LOCOR-PAR 42 44

A017 E/W-TRAP 0...63 UOC-TV E/W-TRAP 32 32

A018 VER-AMP-N60 0...63 UOC-TV VER-AMP-N60 32 22

A019 VER-SHI-N60 0...63 UOC-TV VER-SHI-N60 25 24

A020 HOR-SHI-N60 0...63 UOC-TV HOR-SHI-N60 45 49

A021 EW-W-N60 0...63 UOC-TV EW-W-N60 40 41

A022 VER-AMP-P50 0...63 UOC-TV VER-AMP-P50 32 21

A023 VER-SHI-P50 0...63 UOC-TV VER-SHI-P50 32 25

A024 HOR-SHI-P50 0...63 UOC-TV HOR-SHI-P50 32 44

A025 EW-W-P50 0...63 UOC-TV EW-W-P50 32 40

A026 VX-43-COMPRESS 0...63 UOC-TV VX-43-COMPRESS 32 5

A027 VER-AMP-F50 0...63 UOC-TV VER-AMP-F50 32 32

A028 VER-SHI-F50 0...63 UOC-TV VER-SHI-F50 32 32

A029 HOR-SHI-F50 0...63 UOC-TV HOR-SHI-F50 32 32

A030 EW-W-F50 0...63 UOC-TV EW-W-F50 32 32

A031 VER-AMP-S50 0...63 UOC-TV VER-AMP-S50 32 32

A032 VER-SHI-S50 0...63 UOC-TV VER-SHI-S50 32 32

A033 HOR-SHI-S50 0...63 UOC-TV HOR-SHI-S50 32 32

SETTING DATA

OSD INITIAL DATAITEM EEPROM SETTING DATA RANGE IC

A034 EW-W-S50 0...63 UOC-TV EW-W-S50 32 32

A035 SUB-SLOPE-S 0...63 UOC-TV SUB-SLOPE-S 32 32

A036 SUB-VX-S 0...63 UOC-TV SUB-VX-S 32 32

A037 VER-AMP-C50 0...63 UOC-TV VER-AMP-C50 32 32

A038 VER-SHI-C50 0...63 UOC-TV VER-SHI-C50 32 32

A039 HOR-SHI-C50 0...63 UOC-TV HOR-SHI-C50 34 34

A040 EW-W-C50 0...63 UOC-TV EW-W-C50 32 32

A041 SUB-SLOPE-C 0...63 UOC-TV SUB-SLOPE-C 32 32

A042 SUB-VX-C 0...63 UOC-TV SUB-VX-C 32 32

A043 VER-AMP-P60 0...63 UOC-TV VER-AMP-P60 32 22

A044 VER-SHI-P60 0...63 UOC-TV VER-SHI-P60 32 24

A045 HOR-SHI-P60 0...63 UOC-TV HOR-SHI-P60 32 49

A046 EW-W-P60 0...63 UOC-TV EW-W-P60 32 41

A047 VER-AMP-F60 0...63 UOC-TV VER-AMP-F60 32 32

A048 VER-SHI-F60 0...63 UOC-TV VER-SHI-F60 32 32

A049 HOR-SHI-F60 0...63 UOC-TV HOR-SHI-F60 32 32

A050 EW-W-F60 0...63 UOC-TV EW-W-F60 32 32

A051 VER-AMP-S60 0...63 UOC-TV VER-AMP-S60 32 32

A052 VER-SHI-S60 0...63 UOC-TV VER-SHI-S60 32 32

A053 HOR-SHI-S60 0...63 UOC-TV HOR-SHI-S60 32 32

A054 EW-W-S60 0...63 UOC-TV EW-W-S60 32 32

A055 VER-AMP-C60 0...63 UOC-TV VER-AMP-C60 32 32

A056 VER-SHI-C60 0...63 UOC-TV VER-SHI-C60 32 32

A057 HOR-SHI-C60 0...63 UOC-TV HOR-SHI-C60 32 32

A058 EW-W-C60 0...63 UOC-TV EW-W-C60 32 32

A059 OF-ROTATE 0...127 UOC-TV OF-ROTATE 63 0

A060 DRI-RS 0...63 UOC-TV DRI-RS 32 32

A061 DRI-GS 0...63 UOC-TV DRI-GS 32 32

A062 DRI-BS 0...63 UOC-TV DRI-BS 32 32

A063 CUT-RS 0...63 UOC-TV CUT-RS 32 32

A064 CUT-GS 0...63 UOC-TV CUT-GS 32 32

A065 DRI-RC 0...63 UOC-TV DRI-RC 32 32

A066 DRI-GC 0...63 UOC-TV DRI-GC 32 32

A067 DRI-BC 0...63 UOC-TV DRI-BC 32 32

A068 CUT-RC 0...63 UOC-TV CUT-RC 32 32

A069 CUT-GC 0...63 UOC-TV CUT-GC 32 32

SETTING DATA

OSD INITIAL DATAITEM EEPROM SETTING DATA RANGE IC

A070 DRI-RW 0...63 UOC-TV DRI-RW 32 32

A071 DRI-GW 0...63 UOC-TV DRI-GW 32 32

A072 DRI-BW 0...63 UOC-TV DRI-BW 32 32

29H-FG3RU

8-1 8-2

A073 CUT-RW 0...63 UOC-TV CUT-RW 32 32

A074 CUT-GW 0...63 UOC-TV CUT-GW 32 32

A075 DRI-RS-DVD 0...63 UOC-TV DRI-RS-DVD 32 32

A076 DRI-GS-DVD 0...63 UOC-TV DRI-GS-DVD 32 32

A077 DRI-BS-DVD 0...63 UOC-TV DRI-BS-DVD 32 32

A078 CUT-RS-DVD 0...63 UOC-TV CUT-RS-DVD 32 32

A079 CUT-GS-DVD 0...63 UOC-TV CUT-GS-DVD 32 32

A080 DRI-RC-DVD 0...63 UOC-TV DRI-RC-DVD 32 32

A081 DRI-GC-DVD 0...63 UOC-TV DRI-GC-DVD 32 32

A082 DRI-BC-DVD 0...63 UOC-TV DRI-BC-DVD 32 32

A083 CUT-RC-DVD 0...63 UOC-TV CUT-RC-DVD 32 32

A084 CUT-GC-DVD 0...63 UOC-TV CUT-GC-DVD 32 32

A085 DRI-RW-DVD 0...63 UOC-TV DRI-RW-DVD 32 32

A086 DRI-GW-DVD 0...63 UOC-TV DRI-GW-DVD 32 32

A087 DRI-BW-DVD 0...63 UOC-TV DRI-BW-DVD 32 32

A088 CUT-RW-DVD 0...63 UOC-TV CUT-RW-DVD 32 32

A089 CUT-GW-DVD 0...63 UOC-TV CUT-GW-DVD 32 32

A090 SUB-BRI 0...63 UOC-TV SUB-BRI 32 39

A091 SUB-BRI-DVD 0...63 UOC-TV SUB-BRI-DVD 32 38

A092 SUB-COL 0...63 UOC-TV SUB-COL 32 34

A093 SUB-CON 0...63 UOC-TV SUB-CON 32 48

A094 SUB-CON-DVD 0...63 UOC-TV SUB-CON-DVD 32 49

A095 SUB-TINT-DVD 0...63 UOC-TV SUB-TINT-DVD 32 34

A096 SUB-TINT 0...63 UOC-TV SUB-TINT 32 34

A097 SUB-SHARP 0...63 UOC-TV SUB-SHARP 32 12

A098 P-POSOFH-50 0...31 PIP P-POSOFH-50 0 15

A099 P-POSOFV-50 0...7 PIP P-POSOFV-50 0 4

A100 P-POSOFH-60 0...31 PIP P-POSOFH-60 0 16

A101 P-POSOFV-60 0...7 PIP P-POSOFV-60 0 4

A102 P-SUB-TINT 0...63 PIP P-SUB-TINT 0 38

A103 P-CON-CTM 0...15 PIP P-CON-CTM 0 4

A104 P-CON-DYN 0...15 PIP P-CON-DYN 0 9

A105 P-CON-STD 0...15 PIP P-CON-STD 0 4

SETTING DATA

ITEM EEPROM SETTING DATA RANGE IC OSD INITIAL DATA

A106 P-CON-SOFT 0...15 PIP P-CON-SOFT 0 4

A107 P-SUB-BRI 0...15 PIP P-SUB-BRI 0 2

A108 P-BKGD-R 0...15 PIP P-BKGD-R 0 0

A109 P-BKGD-G 0...15 PIP P-BKGD-G 0 0

A110 P-BKGD-B 0...15 PIP P-BKGD-B 0 0

A111 P-SUB-COL 0...15 PIP P-SUB-COL 0 8

A112 P-SHP-MAIN-TV 0...7 PIP P-SHP-MAIN-TV 73

A113 VSD 0/1 UOC-TV VSD 0 0

A114 CUT OFF 0...63 UOC-TV CUT OFF 6 6

A115 VG2 0/1 UOC-TV VG2 0 1

A116 DCXO 0...127 UOC-TV DCXO 79 57

A117 DCXO-AUTO 0/1 UOC-TV DCXO-AUTO 0 0

SETTING DATA

OSD INITIAL DATAITEM EEPROM SETTING DATA RANGE IC

29H-FG3RU

9-1 9-2

Setting Mode 1-1

ITEM IC

IC INITIAL DATA SETTING DATA

S001 UOC-TV 00

S002 UOC-TV 32 32

S003 UOC-TV 0 1

S004 UOC-TV 0 12

S005 UOC-TV 1 1

S006 UOC-TV 1 1

S007 UOC-TV 0 0

S008 UOC-TV 0 0

S009 UOC-TV 7 11

S010 UOC-TV 7 11

S011 UOC-TV 7 9

S012 UOC-TV 7 7

S013 UOC-TV 7 7

S014 UOC-TV 7 7

S015 UOC-TV 7 7

S016 UOC-TV 7 7

S017 UOC-TV 7 7

S018 UOC-TV 7 7

S019 UOC-TV 7 7

S020 UOC-TV 7 7

S021 UOC-TV 7 7

S022 UOC-TV 7 7

S023 UOC-TV 7 7

S024 UOC-TV 7 7

S025 UOC-TV 1 1

S026 UOC-TV 2 1

S027 UOC-TV 0 0

S028 UOC-TV 1 1

S029 UOC-TV 1 1

S030 UOC-TV 1 1

S031 UOC-TV 1 1

S032 UOC-TV 1 1

S033 UOC-TV 0 0

S034 UOC-TV 1 1

S035 UOC-TV 7 7

S036 UOC-TV 1 1

S037 UOC-TV 0 1

S038 UOC-TV 0 0

S039 UOC-TV 1 1

S040 UOC-TV 0 1

S041 UOC-TV 1 1

S042 UOC-TV 1 1

S043 UOC-TV 0 1

EEPROM SETTING

V-LINCTRL

IFPLL

SOC1-0

YD N443

WHITE LMT

AGC0-1

FFI

CFA0

YD PAL

YD SECAM

YD N358

YD AV-PAL

YD AV-SECAM

YD AV-N358

YD COMP-PAL

YD SAV-N443

YD AV-N443

YD SAV-PAL

YD SAV-SECAM

YD SAV-N358

YD COMP-SECAM

YD COMP-N358

YD COMP-N443

SBO1-0

CHSE1-0

FCO

OSO

DFL

EVG

HCO

SVMA

FBC

SLG1-0

CL3-0

GAM

TFR

BSD

CLD

BKS

AAS

DSK-EXT

BLS

DATA RANGE

0...2

0...63

0...3

0...15

0/1

0...3

0/1

V-LINCTRL

IFPLL

SOC1-0

WHITE LMT

AGC0-1

FFI

CFA0

YD PAL

YD SECAM

YD N358

YD N443

YD AV-PAL

YD AV-SECAM

YD AV-N358

YD AV-N443

YD SAV-PAL

YD SAV-SECAM

YD SAV-N358

YD SAV-N443

YD COMP-PAL

YD COMP-SECAM

YD COMP-N358

YD COMP-N443

SBO1-0

CHSE1-0

FCO

OSO

CL3-0

GAM

DFL

EVG

HCO

SVMA

AAS

DSK-EXT (DSK)

BLS

OSD

TFR

CLD

BKS

BSD

FBC

SLG1-0

0/1

0...15

0...3

0/1

0...3

0...15

0/1

S044 UOC-TV 0 0

S045 UOC-TV 0 1

S046 UOC-TV 0 2

S047 UOC-TV 3 3

LLB

DSA

RPA1-0

RPO1-0

0/1

0...3

0...2

LLB

DSA

RPA1-0

RPO1-0

ITEM IC

IC INITIAL DATA SETTING DATA

S048 UOC-TV 2 1

S049 UOC-TV 0 0

S050 UOC-TV 0 5

S051 UOC-TV 5 3

S052 UOC-TV 3 3

S053 UOC-TV 0 1

S054 UOC-TV 0 0

S055 UOC-TV 0 0

S056 UOC-TV 0 1

S057 UOC-TV 0 0

S058 UOC-TV 0 0

S059 UOC-TV 0 3

S060 UOC-TV 31 45

S061 UOC-TV 31 46

S062 UOC-TV 31 45

S063 UOC-TV 31 40

S064 UOC-TV 31 31

S065 UOC-TV 31 31

S066 UOC-TV 31 46

S067 UOC-TV 36 23

S068 UOC-TV 36 49

S069 UOC-TV 31 35

S070 UOC-TV 31 35

S071 UOC-TV 31 31

S072 UOC-TV 31 31

S073 UOC-TV 31 40

S074 UOC-TV 31 31

S075 UOC-TV 31 34

S076 UOC-TV 31 32

S077 UOC-TV 31 31

S078 UOC-TV 32 32

S079 UOC-TV 0 0

S080 UOC-TV 0 1

S081 UOC-TV 1 1

S082 UOC-TV 1 1

S083 UOC-TV 3 2

S084 UOC-TV 3 1

S085 UOC-TV 2 2

S086 UOC-TV 2 1

S087 UOC-TV 26 25

S088 UOC-TV 31 31

S089 UOC-TV 36 36

EEPROM SETTING

COR1-0

CRA0

SPR2-0

SVM2-0

SMD1-0

PEAKFREQPAL443

PEAKFREQPALM

PEAKFREQPALN

PEAKFREQNTSC443

PEAKFREQNTSCM

PEAKFREQSECAM

PEAKFREQAV

OF-COL-TV

OF-COL-AV

OF-COL-DVD

OF-COL-P

OF-COL-S

OF-COL-N4

OF-COL-N3

OF-SHP-TV

OF-SHP-AV

OF-SHP-DVD

OF-SHP-P

OF-SHP-S

OF-SHP-N4

OF-SHP-N3

OF-TINT-TV

OF-TINT-AV

OF-TINT-DVD

OF-TINT-ADJ

BB-TINT

VMA-SOFT

WS-SOFT

VMA-STD

WS-STD

VMA-DYN

U-COL-STD

WS-DYN

VMA-CTM

WS-CTM

U-COL-SOFT

U-COL-DYN

0/1

0...3

0...6

0...7

0...3

0... 31...62

0...3

0...63

0... 31...62

0...3

COR1-0

CRA0

SPR2-0

SVM2-0

SMD1-0

PEAKFREQPAL443

PEAKFREQPALM

PEAKFREQPALN

PEAKFREQNTSC443

PEAKFREQNTSCM

PEAKFREQSECAM

PEAKFREQAV

OF-COL-TV

OF-COL-AV

OF-COL-DVD

OF-COL-P

OF-COL-S

OF-COL-N4

OF-COL-N3

OF-SHP-TV

OF-SHP-AV

OF-SHP-DVD

OF-SHP-P

OF-SHP-S

OF-SHP-N4

OF-SHP-N3

OF-TINT-TV

OF-TINT-AV

VMA-DYN

OF-TINT-DVD

OF-TINT-ADJ

BB-TINT

VMA-SOFT

U-COL-STD

OSDDATA RANGE

WS-DYN

VMA-CTM

WS-CTM

U-COL-SOFT

WS-SOFT

VMA-STD

WS-STD

0... 31...62 U-COL-DYN

Setting Mode 1-2

S090 UOC-TV 50 50

S091 UOC-TV 60 60

S092 UOC-TV 60 60

S093 UOC-TV 26 26

S094 UOC-TV 31 31

U-CON-SOFT

U-CON-STD

U-CON-DYN

U-SHP-SOFT

U-SHP-STD

0...63

0... 31...62

U-CON-SOFT

U-CON-STD

U-CON-DYN

U-SHP-SOFT

U-SHP-STD

29H-FG3RU

10-1 10-2

ITEM IC

IC INITIAL DATA SETTING DATA

S095 UOC-TV 36 36

S096 UOC-TV 32 35

S097 UOC-TV 2 0

S098 UOC-TV 10 10

S099 UOC-TV 23 23

S100 UOC-TV 16 25

S101 UOC-TV 63 3

S102 UOC-TV 63 63

S103 UOC-TV 1 1

S104 UOC-TV 2 2

S105 UOC-TV 73 73

S106 UOC-TV 32 32

S107 UOC-TV 0 0

S108 UOC-TV 0 0

S109 UOC-TV 1 0

S110 UOC-TV 1 1

S111 UOC-TV 1 1

S112 UOC-TV 0 3

S113 UOC-TV 0 0

S114 GAME IC 6 10

S115 GAME IC 23 27

S116 GAME IC 0 0

S117 GAME IC 192 192

S118 GAME IC 1 1

S119 UOC-TV 1 1

S120 UOC-TV 3 3

S121 UOC-TV 0 0

S122 UOC-TV 0 0

S123 UOC-TV 1 1

S124 UOC-TV 0 1

S125 UOC-TV 1 0

S126 UOC-TV 3 3

S127 UOC-TV 2 2

S128 UOC-TV 0 1

S129 UOC-TV 1 1

S130 UOC-TV 10 6

S131 UOC-TV 8 13

S132 UOC-TV 0 0

S133 UOC-TV 0 0

S134 UOC-TV 20 20

S135 UOC-TV 0 1

S136 UOC-TV 20 20

S137 UOC-TV 20 20

S138 UOC-TV 20 20

EEPROM SETTING

U-SHP-DYN

VOL5-0

HOP1-0

TAS5-0-NORM

TAS5-0-A

BRI3-0

HSD6-0

VSD6-0

HOPB1-0

TASB5-0

PGB5-0

VOLB5-0

SMTHB

SMTH

RANGE1-0

RANGEB1-0

PWR-SAVING

PWR-TIME

I-TIME

GAME-HON

GAME-VERT-1

GAME-VERT-2

GAME-ORIV

GAME-MODE

PHI FORCE

PHI

BPD

E2D

ACL

MUS

CUR_VPOS

HP2

WBR

SVM-OSD-PW

SMD-OSD-TM

XDT

HBL

WBF

FSL

DATA RANGE

0... 31...62

0...63

0...3

0...63

0...31

0...127

0/1

0...255

0...15

0..63

0/1

0...3

0...7

0/1

U-SHP-DYN

VOL5-0

HOP1-0

TAS5-0-NORM

TAS5-0-A

BRI3-0

HSD6-0

VSD6-0

HOPB1-0

TASB5-0

PGB5-0

VOLB5-0

SMTHB

SMTH

RANGE1-0

RANGEB1-0

PWR-SAVING

PWR-TIME

I-TIME

GAME-HON

GAME-VERT-1

GAME-VERT-2

GAME-ORIV

GAME-MODE

PHI FORCE

PHI

BPD

E2D

ACL

MUS

HP2

SVM-OSD-PW

SMD-OSD-TM

XDT

HBL

OSVE 0/1 OSVE

CUR_VPOS

OSD

WBF

WBR

FSL

GAIN-BLUE 0...127 GAIN-BLUE

GAIN-RED 0...127 GAIN-RED

GAIN-GREEN 0...127 GAIN-GREEN

Setting Mode 1-3

ITEM EEPROM SETTING DATA RANGE IC

IC OSD INITIAL DATA SETTING DATA

S201 P-POSHOR 0

...

255 PIP P-POSHOR 2C 28

S202 P-POSVER-50 0

...

255 PIP P-POSVER-50 1E 22

S203 P-POSVER-60 0

...

255 PIP P-POSVER-60 1A 23

S204 P-HFP 0

...

15 PIP P-HFP 0 7

S205 P-VFP 0

...

15 PIP P-VFP 0 8

S206 P-VSPDEL-50 0

...

31 PIP P-VSPDEL-50 0D 13

S207 P-VSPDEL-60 0

...

31 PIP P-VSPDEL-60 0D 13

S208 P-VERBLK 0/1 PIP P-VERBLK 0 0

S209 P-SELDEL 0

...

15 PIP P-SELDEL 8 8

S210 P-CLPDEL 0

...

31 PIP P-CLPDEL 6 6

S211 P-AGCMD 0

...

3PIP P-AGCMD 3 3

S212 P-AGCVAL 0

...

15 PIP P-AGCVAL 8 8

S213 P-CLMPID 0

...

3PIP P-CLMPID 3 3

S214 P-BLKVCHYS 0/1 PIP P-BLKVCHYS 0 0

S215 P-BLKCVAL 0/1 PIP P-BLKCVAL 0 0

S216 P-LMOFST 0

...

3PIP P-LMOFST 0 0

S217 P-PLLITC-TV 0

...

3PIP P-PLLITC-TV 2 2

S218 P-PLLITC-AV 0

...

3PIP P-PLLITC-AV 1 1

S219 P-BLKVCFIL 0/1 PIP P-BLKVCFIL 0 0

S220 P-YCD-TV-P 0

...

15 PIP P-YCD-TV-P 8 8

S221 P-YCD-TV-N3 0

...

15 PIP P-YCD-TV-N3 8 8

S222 P-YCD-TV-N4 0

...

15 PIP P-YCD-TV-N4 8 8

S223 P-YCD-TV-S 0

...

15 PIP P-YCD-TV-S 8 8

S224 P-YCD-AV-P 0

...

15 PIP P-YCD-AV-P 8 8

S225 P-YCD-AV-N3 0

...

15 PIP P-YCD-AV-N3 8 8

S226 P-YCD-AV-N4 0

...

15 PIP P-YCD-AV-N4 8 8

S227 P-YCD-AV-S 0

...

15 PIP P-YCD-AV-S 8 8

S228 P-LOCKSP 0/1 PIP P-LOCKSP 0 0

S229 P-CKILL 0

...

3PIP P-CKILL 0 0

S230 P-BGPOS 0/1 PIP P-BGPOS 1 1

S231 P-DEEMP 0

...

3PIP P-DEEMP 0 0

S232 P-COLON 0/1 PIP P-COLON 0 0

S233 P-CHRBW 0

...

3PIP P-CHRBW 0 0

S234 P-IFCOMP 0

...

3PIP P-IFCOMP 2 2

S235 P-SATNR 0/1 PIP P-SATNR 1 1

S236 P-SCADJ-P 0

...

31 PIP P-SCADJ-P 7 7

S237 P-SCADJ-N3 0

...

31 PIP P-SCADJ-N3 7 7

Setting Mode 2-1

Autres manuels pour 29H-FG3RU

Table des matières

Autres manuels Sharp TV

Sharp

Sharp LC-32LD164E Manuel utilisateur

Sharp

Sharp 28LF-96EC Manuel utilisateur

Sharp

Sharp LC-32FI6522E Manuel utilisateur

Sharp

Sharp LC-24CHG6001KF Manuel technique

Sharp

Sharp 40BJ2I Manuel technique

Sharp

Sharp 21SFX10L Manuel utilisateur

Sharp

Sharp Aquos 2T-C50BG1X Manuel utilisateur

Sharp

Sharp LC-32DH57E-BK Manuel utilisateur

Sharp

Sharp 21N52-E1 Manuel utilisateur

Sharp

Sharp LC-22CFF4011E Manuel utilisateur

Sharp

Sharp LC-40FG5241K Manuel utilisateur

Sharp

Sharp 70GS-62SDE Manuel utilisateur

Sharp

Sharp 26MR70 Manuel utilisateur

Sharp

Sharp 32C230 Manuel utilisateur

Sharp

Sharp 21V-FS700S Manuel utilisateur

Sharp

Sharp LC-43CUF8472ES Manuel utilisateur

Sharp

Sharp 66GS-62H Manuel utilisateur

Sharp

Sharp 29H-F200RU Manuel utilisateur

Sharp

Sharp 32F543 XFlat Manuel utilisateur

Sharp

Sharp 51GT-25S Manuel utilisateur

Sharp

Sharp LC-65D93U Manuel utilisateur

Sharp

Sharp Aquos LC-19SB280UT Manuel utilisateur

Sharp

Sharp 14V-L70M Manuel utilisateur

Sharp

Sharp XFlat 20F650 Manuel utilisateur

Manuels TV populaires d'autres marques

Philips

Philips Colour Television Manuel utilisateur

Toshiba

Toshiba 27A10 Manuel utilisateur

Philips

Philips 42PF9630A/37 Manuel utilisateur

Hitachi

Hitachi 32FX48B Manuel utilisateur

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur

Changhong Electric

Changhong Electric uhd55b6000is Manuel utilisateur

Philips

Philips Matchline 21CE7551 Manuel utilisateur

Panasonic

Panasonic Genus TX-G10 Manuel utilisateur

Toshiba

Toshiba 19A20 Manuel utilisateur

Philips

Philips 25PT4523-16 Manuel utilisateur

Sony

Sony XBR-100Z9D Manuel utilisateur

Philips

Philips PR0930X3 Manuel utilisateur

Philips

Philips Brilliance 231P4QPY Manuel utilisateur

Samsung

Samsung 55S9 B Series Manuel utilisateur

Philips

Philips 32HF9385D Guide de dépannage

Loewe

Loewe Table Stand Reference 55 Manuel utilisateur

Philips

Philips 32PFH5300 Manuel utilisateur

Sylvania

Sylvania 6427FB Manuel utilisateur
