Sharp SL-C1000 Manuel utilisateur

Important!

Please read the information in the section

"Unpacking / Startup", before unpacking any

further.

SHARP SL-C1000

SL-C3000 / SL-C3100

Linux

Personal Mobile Tool

Revision 3.0 4.7.2005

Table of contents

Welcome........................................5

The Zaurus SL-C1000/SL-C3000/SL-C3100 .....................6

ComparisonoftheSL-CSeriesZauris.....................6

Unpacking .......................................7

Startup .........................................8

Insertthebattery................................8

Chargingthebattery ..............................8

OpenandTurnOverDisplay..........................9

Ports / Controls ....................................10

Bottom ....................................10

Devicebackside ...............................11

Hard-Reset..................................12

One-HandedUse...............................12

Keyboard functions ..................................13

Japanesekeys ................................13

Quickstartkeys................................13

OK/Cancel(Esc)/Cursorkeys .......................14

Umlauts/Euro ................................15

Screenshots .................................15

Software for SL-5500(G) ...............................16

Software installation (Windows) ...........................16

USB-Driver..................................16

IntelliSync ..................................16

WorkaroundforIntelliSync ..........................17

CommunicationviaNeighborhood ......................17

Telnet-Access ................................17

The Zaurus USB port.................................18

AccessasUSB-MassStorage(Zaurusisclient) ...............18

Page 2SHARP SL-C1000/3000/3100

///TRIsoft OHG SL-C1000/3000/3100 Quickstart

ConnectingUSB-memorytotheZaurus(ZaurusisHost)...........19

USB-Keyboard(Zaurusishost) .......................20

Annotations about Software .............................20

Applications .................................20

MoviePlayer ...............................20

PIM-Applications(KO/Pi/KA/Pi) .......................20

Localisation after factory-reset ............................21

Reset(Flashmenu)..............................21

Firststart ...................................23

Runrestore..................................24

Japanese Leftovers..................................27

Addressbook .................................27

Network-Wizard ...............................27

OpenZaurus .....................................28

OpenZaurusforwhichdog?.........................28

Neededfiles .................................29

BacktotheSHARPROM...........................29

Diag / service menu .................................30

Accessingtheservicemenu: .........................30

Quitservicemenu: ..............................31

Backupwithservicemenu: ..........................31

Restorewithservicemenu:..........................33

Boot to command-line ................................34

The harddrive (SL-C3000/3100): ...........................35

Helpful links: .....................................35

Zaurusportals ................................35

Software ...................................35

Accessories for your Zaurus .............................36

SHARPaccessories .............................36

Thirdpartyaccessories............................36

Declaration of conformity ...............................37

SHARP SL-C1000/3000/3100 Page 3

SL-C1000/3000/3100 Quickstart ///TRIsoft OHG

In the USA: ......................................38

Page 4SHARP SL-C1000/3000/3100

///TRIsoft OHG SL-C1000/3000/3100 Quickstart

SL-C1000/3000/3100 Quickstart ///TRIsoft OHG

SHARP SL-C1000/3000/3100 Page 5

Welcome

Thank you for buying the SHARP SL-C1000 / SL-C3000 / SL-C3100.

This device is not sold from SHARP out of Japan. It is a Japanese device with English

user interface and English keyboard.

If you are mainly interested in a calendar, addressbook, etc., you are perhaps better off

with a simple organizer.

But if you are looking for a mobile Linux system with excellent performance, you have

made the right choice.

Each device is tested and localised by us in English in most aspects, before it is shipped.

So you can start at once, without navigating through Kanji characters.

The Zaurus will start in Japanese after a factory-reset. But do not be afraid, the steps for

localisation are described on page 21.

PleasenotethatSHARPElectronicsEurope/SHARPUSAdoesnotsupportthisdevice.

Forfurtherinformation,linksandquestionsvisitusintheinternetathttp://www.trisoft.de.

The largest german-speaking (sorry) Zaurus-Community is to be found at

http://www.z-portal.info. Tons of english information is available at

http://externe.net/zaurus/forum/ and on http://www.zaurususergroup.org .

In case of technical problems, you can reach us via electronic mail: [email protected] or

via telephone: +49 511 94294 0

US customers please contact [email protected]

Credits:

Thisenglish version ofthe quickstart guidewassupported bytheteam ofWernerHeuser

/ Xtops.de, Berlin.

Trademarks:

SHARP and Zaurus are registered trademarks of the SHARP Corporation.

Linux is a registered trademark of Linus Torvalds.

QT and QTopia are trademarks of Trolltech Inc.

All other products, brand names or in this manual mentioned company names are

property and trademark of the particular companies.

Page 6SHARP SL-C1000/3000/3100

///TRIsoft OHG SL-C1000/3000/3100 Quickstart

The Zaurus SL-C1000/SL-C3000/SL-C3100

This manual is only for the SL-C1000 / SL-C3000 / SL-C31000 models which are

different in some important points compared to the previous SL-C series Zauris.

The essential difference is the bigger battery, the included 4 GB harddrive in the

SL-C3000 / SL-C3100 and the USB port with host capability.

Comparison of the SL-C Series Zauris

Attribute SL-C1000

SL-C3000/C3100 SL-C750 SL-C760

SL-C860

OS Lineo uLinux

Kernel 2.4.20 Linux OpenPDA

CPU Intel Xscale PXA

270, 416 MHz Intel Xscale PXA255 400 MHz

Memory

C1000:128MBFlash

C3000:16 MB Flash

C3100:128MBFlash

64 MB SDRAM

64 MB Flash

64 MB SDRAM 128 MB Flash

64 MB SDRAM

Harddrive C3000: 4 GB HD

C3100: 4 GB HD

C1000: not avail. not available

Display SHARP CG Silicon 640x480

I/O Ports USB Slave + Host

Infrared, Headphone

jack, AC adaptor

SHARP I/O-Port, Infrared, Headphone,

AC adaptor

Card slots 1 x SD, 1 x CompactFlash

Batteryincluded 3,7V LiIon

EA-BL11 1800mAh 3,7V LiIon

EA-BL06950mAh

3,7V LiIon

EA-BL08

1700mAh

Battery optional EA-BL08K, EA-BL06 EA-BL08K,

EA-BL11 EA-BL06,

EA-BL11

Power

consumption C1000: 2.3W

C3000/3100: 3.2W 2.7 W

SL-C1000/3000/3100 Quickstart ///TRIsoft OHG

SHARP SL-C1000/3000/3100 Page 7

Attribute SL-C1000

SL-C3000/C3100 SL-C750 SL-C760

SL-C860

Display cover

SL-C1000:

Cover : black

Body : black

SL-C3000:

Cover : white

Body : white

SL-C3100:

Cover : anthracite

Boddy : black

Cover black SL-C760: white

SL-C860: silver

Dimensions 124 x 87 x 25 mm 120x83x18,6mm 120x83x23,2mm

Weight C1000: Ca. 278 g

C3000: Ca. 298 g

C3100: Ca. 298 g Ca. 225 g Ca. 250 g

Unpacking

The package should contain the following items:

Item SL-C1000 SL-C3000 SL-C3100

Zaurus with stylus and covers for

CF and SD slot 1 1 1

Battery EA-BL11 1 1 1

PC-USB cable (long, black mini

USB plug) 1 1 1

ZHost USB host cable (short, white

mini USB plug) 1 1 1

Headphones - - 1

Zaurus Software CD 1 2 3

Manual (japanese) 1 1 1

This short manual (already found) 1 1 1

Page 8SHARP SL-C1000/3000/3100

///TRIsoft OHG SL-C1000/3000/3100 Quickstart

Startup

Insert the battery

Unlock the lower cover by sliding the the

switch for the interlock of the battery

compartment (1) to the left. Detach the

cover in direction (2).

Insert the battery as shown in the

picture.Forthe battery tofittightly,press

in direction of the arrow on the end

leading to the border of the enclosure.

Put the cover for the battery

compartment back onto the device.

Thereisamarking dash attheborderfor

orientation which should be aligned to

the border of the compartment.

Lock the cover by sliding the switch to

the right.

Charging the battery

You should now connect the power supply with the Zaurus (the AC-in is located on the

backside of the device).

The Zaurus will be charged and in the upper left corner should glow a yellow charging

LED.

Please charge the Zaurus for some time, before turning it on.

SL-C1000/3000/3100 Quickstart ///TRIsoft OHG

SHARP SL-C1000/3000/3100 Page 9

Open and Turn Over Display

The display can be opened

andturnednearlyhorizontal

to the keyboard. There it

snaps into the maximal

possible position.

When opened, the display

can also be turned

clock-wise and overback

onto the keyboard:

Attention: NEVER turn the

display using violence or in

opposite to the designated

direction. Such damages

(Zaurus in two parts) are

not warranted.

Please touch the device at

both sides when the display

is turned. Do not touch it at

the upper border.

Page 10 SHARP SL-C1000/3000/3100

///TRIsoft OHG SL-C1000/3000/3100 Quickstart

Ports / Controls

Bottom

1: Lug for fastening the Zaurus (for instance a chain).

2. Slot for CompactFlash cards with protective cover.

3. Stylus.

4. Slot for SD/MMC cards with protective cover.

5. Speaker.

6. Switch to lock / unlock the battery compartment.

7. Battery cover.

8. Infrared.

9. On- / Off switch.
