Dismantle Instruction

LCD MONITOR

MODEL

PN-75TH1

Dismantle Instruction



Table of contents


Scope ............................................................................................................... 3
Tools for dismantling............................................................................................. 3
Dismantle Procedure ............................................................................................ 3
Back covers ........................................................................................................ 4
Printed circuit boards ........................................................................................... 5
Battery.............................................................................................................. 6
LCD Module ........................................................................................................ 7
Capacitors.......................................................................................................... 8
Parts List ........................................................................................................... 8




Dismantle Instruction

1. Scope

This document describes dismantling instruction according to Annex VII of Directive 2012/19/EU.

2. Tools for dismantling

Below tools are required to dismantle this product.

- Screw Driver

- Nipper

3. Dismantle Procedure

This product can be dismantled by below steps.

1. Remove Back covers (section 4)

2. Remove the shielding

3. Remove Printed circuit boards (section 5)

4. Remove Battery (section 6)

5. Dismantle LCD (section 7)

6. Remove Electrolyte Capacitors (section 8)

Dismantle Instruction

4. Back covers

Back covers can be removed by screw driver.

Dismantle Instruction

5. Printed circuit boards

All PWBs can be removed by screw driver.

Power board (1pcs) Video board (1pcs)

ARM board (1pcs) Touch panel board (1pcs)

Option board (1pcs) IR/Key board (1pcs)

Dismantle Instruction

6. Battery

This model uses CR2032 Lithium Coin battery on Main I/F PWB and AAA battery for remote control.

Battery can easily be removed from the battery holder.

Dismantle Instruction

7. LCD Module

LCD Dismantle procedure

1. Remove the Brackets for touch panel mounting

2. Remove the Touch panel

3. Remove the Rear cover

4. Remove the PWBs

5. Remove the Cables

LCD

Dismantle Instruction

8. Capacitors

Electrolyte Capacitors which diameter/height is larger than 25mm is installed on the Power PWB.

These capacitors can be removed by using nipper to cut the leads.

9. Parts List

Parts described in Annex VII of directive 2012/19/EU are as below.

Parts

Note

LCD

75inch LCD module

Batteries

Battery CR2032 of the main board

Battery(AAA) of remote control

Printed Circuit Boards

Power board

Video board

ARM board

Touch panel board

Option board

IR/Key board

Electrolyte capacitors

(height >25mm, diameter >25mm)

On the Power PWB

External electric cables

2 kinds of Power Cord

- CEE 7 (for EU)

- Type-BF (for UK)
