Sharp EL-2901RH Manuel utilisateur

EL-2901RH

ELECTRONIC PRINTING CALCULATOR

DRUCKENDER TISCHRECHNER

CALCULATRICE IMPRIMANTE ÉLECTRONIQUE

CALCULADORA IMPRESORA ELECTRÓNICA

CALCOLATRICE ELETTRONICA STAMPANTE

ELEKTRONISK SKRIVANDE OCH VISANDE RÄKNARE

ELEKTRONISCHE REKENMACHINE MET AFDRUK

CALCULADORA ELETRÔNICA COM IMPRESSORA

ELEKTRONISESTI TULOSTAVA LASKIN

OPERATION MANUAL

BEDIENUNGSANLEITUNG

MODE D’EMPLOI

MANUAL DE MANEJO

MANUALE DI ISTRUZIONI

BRUKSANVISNING

GEBRUIKSAANWIJZING

MANUAL DE INSTRUÇÕES

KÄYTTÖOHJE

ENGLISH ............................................................... Page 1

CALCULATION EXAMPLES ................................. Page 73

DEUTSCH .............................................................. Seite 9

RECHNUNGSBEISPIELE ..................................... Seite 73

FRANÇAIS ............................................................. Page 17

EXEMPLES DE CALCULS .................................... Page 74

ESPAÑOL .............................................................. Página 25

EJEMPLOS DE CÁLCULOS ................................. Página 74

ITALIANO .............................................................. Pagina 33

ESEMPI DI CALCOLO ........................................... Pagina 75

SVENSKA .............................................................. Sida 41

RÄKNEEXEMPEL .................................................. Sida 75

NEDERLANDS ...................................................... Pagina 49

REKENVOORBEELDEN ....................................... Pagina 76

PORTUGUÊS ........................................................ Página 57

EXEMPLOS DE CÁLCULO ................................... Página 76

SUOMI ................................................................... Sivu 65

LASKENTAESIMERKKEJÄ ................................... Sivu 77

EL-2901RH(ACO)-Cover-1 03.4.4, 1:53 PM1

Caution!

The socket outlet shall be installed near the equipment and shall be easily accessible.

Vorsicht!

Die Netzsteckdose muß in der Nähe des Gerätes angebracht und leicht zugänglich sein.

Attention!

La prise de courant murale doit être installée à proximité de l’appareil et doit être

facilement accessible.

Aviso!

El tomacorriente debe estar instalado cerca del equipo y debe quedar bien accesible.

Attenzione!

La presa della corrente deve essere installata in prossimità dell’apparecchio ed essere

facilmente accessibile.

Observera!

Anslut till ett vägguttag som återfinns nära enheten och är lätt åtkomligt.

Let op!

Het stopcontact moet in de buurt van het apparaat zijn en ook gemakkelijk toegankelijk

zijn.

Atenção!

A tomada elétrica deve estar perto do equipamento e ser de fácil acesso.

Huomautus!

Pistorasia tulee asentaa laitteen lähelle paikkaan, jossa sen käyttöä on helppoa.

EL-2901RH(ACO)-IEC950 03.4.4, 1:54 PM2

CONTENTS

OPERATIONAL NOTES

ENGLISH

Page

• OPERATING CONTROLS ................................ 2

• INK ROLLER REPLACEMENT ......................... 4

• PAPER ROLL REPLACEMENT ........................ 5

• ERRORS ........................................................... 6

• SPECIFICATIONS ............................................. 7

• IN CASE OF ABNORMAL CONDITIONS ......... 8

• CALCULATION EXAMPLES ........................... 73

• TAX RATE CALCULATIONS ........................... 87

• COST / SELL / MARGIN CALCULATION ....... 89

To insure trouble-free operation of your SHARP

calculator, we recommend the following:

1. The calculator should be kept in areas free from

extreme temperature changes, moisture, and

dust.

2. A soft, dry cloth should be used to clean the

calculator. Do not use solvents or a wet cloth.

3. Since this product is not waterproof, do not use

it or store it where fluids, for example water, can

splash onto it. Raindrops, water spray, juice,

coffee, steam, perspiration, etc. will also cause

malfunction.

4. If service should be required, use only a SHARP

servicing dealer, a SHARP approved service

facility or SHARP repair service.

5. If you pull out the power cord to cut electricity

completely, the presently stored tax rate will be

cleared.

6. Do not wind the AC cord around the body or

otherwise forcibly bend or twist it.

SHARP will not be liable nor responsible for any

incidental or consequential economic or

property damage caused by misuse and/or

malfunctions of this product and its peripherals,

unless such liability is acknowledged by law.

EL-2901RH(ACO)-Eng 03.5.16, 10:23 AM1

OFF •P P•IC ON

POWER SWITCH; PRINT / ITEM

COUNT MODE SELECTOR:

“OFF”: Power OFF

“•”: Power ON. Set to the non print mode.

“P”: Power ON. Set to the print mode.

“P•IC”: Power ON. Set to the print and item count

mode.

For addition or subtraction, each time is

pressed, 1 is added to the item counter, and

each time is pressed, 1 is subtracted.

•The count is printed when the calculated

result is obtained.

•Pressing of , clears the

counter.

Note: The counter has a maximum capacity of 3

digits (up to ±999). If the count exceeds the

maximum, the counter will recount from zero.

ROUNDING SELECTOR:

Example: Set Decimal Selector to 2.

4 ÷9 = 0.444 ... , 5 ÷9 = 0.555 ...

OPERATING CONTROLS

Note: The decimal point floats during successive

calculation by the use of or .

If the decimal selector is set to “F”then the answer

is always rounded down ( ).

•

RATE

SET

GRAND TOTAL / RATE SETTING MODE

SELECTOR:

“GT”: Grand Total

“•”: Neutral

“RATE SET”: Rate setting

•Enter the adding tax rate, then press .

•A maximum of 4 digits can be stored (decimal point

is not counted as a digit).

•Only one rate can be stored. If you enter a new

rate, the previous rate will be cleared.

F 6 3 2 1 0 A

DECIMAL / ADD MODE SELECTOR:

“6 3 2 1 0”: Presets the number of decimal places

in the answer.

“F”: The answer is displayed in the floating decimal

system.

4 9 5 9

0.45 0.56

5/4 0.44 0.56

0.44 0.55

EL-2901RH(ACO)-Eng 03.5.16, 10:23 AM2

“A”: The decimal point in addition and subtraction

entries is automatically positioned to the 2nd

digit from the lowest digit of entry number. Use

of the add mode permits addition and

subtraction of numbers without entry of the

decimal point. Use of , and will

automatically override the add mode and

decimally correct answers will be printed.

PAPER FEED KEY

NON-ADD / SUBTOTAL KEY

CLEAR / CLEAR ENTRY KEY

TOTAL KEY

EQUAL KEY

CHANGE SIGN KEY:

Changes the algebraic sign of a number (i.e.,

positive to negative or negative to positive).

RECALL AND CLEAR MEMORY KEY

RECALL MEMORY KEY

TAX-INCLUDING KEY

PRE-TAX KEY

GRAND TOTAL KEY

COST PRICE ENTRY KEY:

Press this key to enter the cost price.

SELLING PRICE ENTRY KEY:

Press this key to enter the selling price.

MARGIN ENTRY KEY:

Press this key to enter the margin.

DISPLAY

Display format:

Symbols:

M: Appears when a number is in the memory.

–:Appears when a number is negative.

•:Appears when a number is in the grand total

memory.

E:Appears when an overflow or other error is

detected.

* Although all available symbols are shown here

for instruction purposes, these symbols will not

appear on the screen simultaneously.

EL-2901RH(ACO)-Eng 03.5.16, 10:23 AM3

Cleaning the printing mechanism

If the print becomes dull after long time usage,

clean the printing wheel according to the

following procedures:

1) Remove the printer cover and the ink roller.

2) Install the paper roll and feed it until it comes

out of the front of the printing mechanism.

3) Put a small brush (like a tooth brush) lightly to

INK ROLLER REPLACEMENT

If printing is blurry even when the ink roller is in the

proper position, replace the roller.

Ink roller: Type EA-772R

WARNING

APPLYING INK TO WORN INK ROLLER OR

USE OF UNAPPROVED INK ROLLER MAY

CAUSE SERIOUS DAMAGE TO PRINTER.

1) Set the power switch to OFF.

2) Remove the printer cover. (Fig. 1)

3) Hold the top of the ink roller and remove the roller

by pulling it toward you and then upward. (Fig.

4) Install the new ink roller in the correct position.

Make sure that the roller is securely in place.

(Fig. 3)

5) Put back the printer cover.

Fig. 1 Fig. 2

Fig. 3

EL-2901RH(ACO)-Eng 03.5.16, 10:23 AM4

Never insert paper roll if torn. Doing so will

cause paper to jam.

Always cut leading edge with scissors first.

1) Insert the leading edge of the paper roll into the

opening. (Fig. 1)

2) Turn the power on and feed the paper by

pressing . (Fig. 2)

3) Lift the attached metal paper holder up and insert

the paper roll to the paper holder. (Fig. 3)

PAPER ROLL REPLACEMENT

Fig. 1

the printing wheel and clean it by pressing .

4) Put back the ink roller and the printer cover.

Note: •Do not rotate the printing mechanism

manually, this may damage the printer.

EL-2901RH(ACO)-Eng 03.5.16, 10:23 AM5

DO NOT PULL PAPER BACKWARDS AS THIS

MAY CAUSE DAMAGE TO PRINTING

MECHANISM.

Fig. 2 Fig. 3

There are several situations which will cause an

overflow or an error condition. When this occurs,

“E”will be displayed. The contents of the memory

at the time of the error are retained.

If an “0䡠E”is displayed at the time of the error, “– –

–––––” will be printed in red and must be

used to clear the calculator.

Also, in rare cases, printing may stop midway and

the indication “E”appear on the display. This is not

a malfunction but is caused when the calculator is

exposed to strong electromagnetic noise or static

electricity from an external source. Should this

occur, press the key and then repeat the

calculation from the beginning.

Error conditions:

1. When the integer portion of an answer exceeds

12 digits.

2. When the integer portion of the contents of the

memory exceeds 12 digits.

(Ex. 999999999999 1 )

3. When any number is divided by zero.

(Ex. 5 0 )

ERRORS

EL-2901RH(ACO)-Eng 03.5.16, 10:23 AM6

SPECIFICATIONS

Operating capacity: 12 digits

Power source: AC: 220V–230V, 50Hz

PRINTING SECTION

Printer: Mechanical printer

Printing speed: Approx. 2.1 lines/sec.

(At temperature 25°C

(77°F), when “741.9 + ”is

printed. The printing speed

will vary with the number

of rows and the figure

types to be printed.)

Printing paper: 57 mm (2-1/4") - 58 mm (2-

9/32") wide

80 mm (3-5/32") in

diameter (max.)

Operating temperature: 0°C –40°C (32°F –104°F)

Power consumption: 41 mA

Dimensions: 193 mm (W) ×256 mm (D)

×62.5 mm (H)

(7-19/32" (W) ×10-3/32"

(D) ×2-15/32" (H))

Weight: Approx. 1.0 kg (2.20 Ib.)

Accessories: 1 paper roll, 1 ink roller

(installed), and operation

manual

WARNING

THE VOLTAGE USED MUST BE THE SAME

AS SPECIFIED ON THIS CALCULATOR.

USING THIS CALCULATOR WITH A HIGHER

VOLTAGE THAN THAT WHICH IS SPECIFIED

IS DANGEROUS AND MAY RESULT IN A FIRE

OR OTHER TYPE OF ACCIDENT CAUSING

DAMAGE. WE ARE NOT RESPONSIBLE FOR

ANY DAMAGE RESULTING FROM USE OF

THIS CALCULATOR WITH A VOLTAGE

OTHER THAN THAT WHICH IS SPECIFIED.

0 1 2 3 4 5 6 7 8 9 . ,

EL-2901RH(ACO)-Eng 03.5.16, 10:23 AM7

When this unit is exposed to strong RF noise and/

or extreme physical shock during the operation, or

when the power cord is plugged into the AC outlet,

the unit may start functioning abnormally which, in

some rare occasion all keys - including the power

key and the key - cease to respond.

If such abnormal conditions are observed, unplug

the AC cord from the socket. Keep the unit

unplugged for about 5 seconds, reconnect the AC

plug, then turn on the power.

IN CASE OF ABNORMAL CONDITIONS

0 1 2 3 4 5 6 7 8 9 . ,

EL-2901RH(ACO)-Eng 03.5.16, 10:23 AM8

Autres manuels pour EL-2901RH

Table des matières

Autres manuels Sharp Calculatrice

Sharp

Sharp EL-9650 Manuel utilisateur

Sharp

Sharp EL1801C - Semi-Desktop 2-Color Printing... Manuel utilisateur

Sharp

Sharp CS-2194H Manuel utilisateur

Sharp

Sharp CS-2635RH Manuel utilisateur

Sharp

Sharp EL-520V Manuel utilisateur

Sharp

Sharp EL1197PIII - Printing Calculator, 12-Digit Manuel utilisateur

Sharp

Sharp Elsi Mate EL-R297 Manuel utilisateur

Sharp

Sharp Elsimate EL-334F Manuel utilisateur

Sharp

Sharp EL-R277B-BK Manuel utilisateur

Sharp

Sharp ELSIMATE EL-2128V Manuel utilisateur

Sharp

Sharp QS-1760A Manuel utilisateur

Sharp

Sharp EL-738XTB Manuel utilisateur

Sharp

Sharp PC-E220 Manuel utilisateur

Sharp

Sharp EL-2910R Manuel utilisateur

Sharp

Sharp EL1197PIII - Printing Calculator, 12-Digit Manuel utilisateur

Sharp

Sharp ELSI MATE EL-244W Manuel utilisateur

Sharp

Sharp ELSI MATE EL-327S Manuel utilisateur

Sharp

Sharp EL1801C - Semi-Desktop 2-Color Printing... Manuel utilisateur

Sharp

Sharp ELSI MATE EL-326S Manuel utilisateur

Sharp

Sharp ELSIMATE EL-421M Manuel utilisateur

Sharp

Sharp CS-4194H Manuel utilisateur

Sharp

Sharp ESLIMATE EL-240S Manuel utilisateur

Sharp

Sharp EL-2630PII Manuel utilisateur

Sharp

Sharp EL-1607P Manuel utilisateur

Manuels Calculatrice populaires d'autres marques

HP 35s Manuel

Casio

Casio CFX-9970G Manuel utilisateur

LEXIBOOK

LEXIBOOK EL350 Manuel utilisateur

HP HP-97 Manuel utilisateur

Citizen

Citizen SDC-414N Manuel utilisateur

Casio

Casio fx-3800P Manuel utilisateur

Canon

Canon P26-DHIII Manuel utilisateur

Citizen

Citizen 520DPA Manuel utilisateur

Casio

Casio FX-9860GII - SOFTWARE VERSION 2-00 Manuel utilisateur

Casio

Casio MS-7UC Manuel utilisateur

Casio

Casio FC-200 Manuel utilisateur

Casio

Casio fx-CG50 Manuel utilisateur

HP HP-67 Guide de l'utilisateur

Royal

Royal CBC2000 Manuel utilisateur

Heathkit

Heathkit IC-2009 Manuel utilisateur

Universal

Universal UNV-15907 Manuel utilisateur

Casio

Casio ALGEBRA FX 2.0 Manuel utilisateur

Casio

Casio CLASSPad300 - ClassPad 300 Touch-Screen Graphing Scientific... Manuel utilisateur
